Warning
This equipment should be installed by a qualified individual.
This equipment should only be used by one person at a time, under the supervision of a qualified individual.
Using this equipment for purposes other than those originally intended is prohibited.
Recommendations
As set out in French Standard NF S52-400 the following is recommended:
- keep these instructions for subsequent reference (inspection, maintenance, etc.).
- periodically carry out predictive maintenance.
- depending on how much it is used have the equipment serviced yearly or every few years.
Pack list
1 Pack (Ref: 3652)
I. Assembly of the cover
1
Wipe over the existing body with a dry cloth to remove any unwanted particles (fragments of magnesium, etc.).
2
Use the end caps (4) provided if necessary (end caps damaged or non-existent) for Gymnova beam bodies. Refer to
instructions NM135.
3
Fit the new cover (1) over the existing body: start with one end then fit the other end.
FRAGILE
Constantly aiming to improve our products, we reserve the right to make changes to the equipment and dimensions without further discussion.
A
R
EMOVABLE
Dimensions: 610 x 410 x 240 mm
1
I
SSEMBLY
NSTRUCTIONS
B
C
EAM
M'16
Weight: 6 kg
1
1
NM272B-GB
OVER
Volume: 0.06 m
1
06/07/17
3652
