CONFIDENTIAL — PRIVATE PREPRODUCTION STATUS
SONETICS APEX CONNECT
BETA UNIT
OVERVIEW
The Sonetics Apex Connect allows users in low noise environments to connect with their teams in high noise
environments without having to wear a hearing protection headset. Users simply leverage their existing corded
wired headset or Bluetooth® headset to plug or pair to the Sonetics Apex Connect to communicate with their
team up to 800 feet line of sight, hands-free. The Sonetics Apex Connect is rugged and rated at IP67, so it's
waterproof and portable to different environments.
CONTENTS
•
Sonetics Apex Connect
•
Belt clip w/magnet
•
USB-C Charging Cable
•
AC Wall Adapter
•
Either corded headset or Bluetooth ear buds or Bluetooth speaker
FEATURES
DECT7 — Hands-free communication over a secure and encrypted frequency
Bluetooth — Pairing to headsets
Mute — Blocks all outbound communication
Light Weight — 6.7 ounces and a mere 3" x 3" x 1"
Adjustable Volume Control
Rugged Design — IP-67 dust and water ingress rating - waterproof
Flexible Charging — AC adapter and DC automotive charging adapter
POWERING ON/OFF
•
Apply a 1 second short Power Button
•
Apply a 1 second short Power Button
Note: Using a 3-second-long Power Button
indicated by a fast blinking Red LED light below the power button. If this happens, let the Red LED fast blink time
out (about 1 minute). Then proceed to turn Off or On the device with a 1 second Power Button
is not connected to a base station it will power down after 10 minutes.
CHARGING
1. Use the provided USB-C charging cable to connect into the Apex Connect and into the AC wall adapter.
2. The Power LED (far right) will turn red and slow blink while charging. When charge completes, light turns
steady green.
QUICK START GUIDE
press to turn ON the device
press to tun OFF the device
press puts the Apex Connect in Safe Mode (aka Boot Loader mode),
press. If device
Advertisement
Table of Contents
Related Manuals for Sonetics APEX CONNECT
Summary of Contents for Sonetics APEX CONNECT
- Page 1 Bluetooth® headset to plug or pair to the Sonetics Apex Connect to communicate with their team up to 800 feet line of sight, hands-free. The Sonetics Apex Connect is rugged and rated at IP67, so it’s waterproof and portable to different environments.
- Page 2 2. Press and hold the PTT buttons simultaneously until Blue LED blinks slow. 3. Put your Bluetooth headset or ear buds into pairing mode and place within 3" of the Apex Connect (pairing can take up to 1 minute). Notes: •...
- Page 3 (minus) button again or press and release the “PTT” button to turn OFF the Device Mute feature. PTT BUTTON • Large square button on front of the Apex Connect allows for communication over two-way radios via PTT (and intercom operation in Intercom PTT and Intercom Toggle modes). • Simply press and hold the PTT button on the Apex Connect to communicate over the two-way radio frequency connected to your ComHub.
- Page 4 PRIVATE ALPHA AND BETA DRAFT DOCUMENTATION NOTICE This Sonetics Apex Connect Alpha Unit and document is in private preproduction status. The unit itself, and the information contained in this document are for informational sharing purposes for customer evaluation and should be considered in your capacity as a beta customer only.
- Page 5 IMPORTANT SAFETY INFORMATION CAUTION! Follow all warnings and instructions marked on the product or contained in the owner’s manual. When using this product, always follow basic safety precautions to reduce the risk of fire, electric shock and injury to persons, including the following: The Headset water and dust egress IP rating does not apply when the battery door or Auxiliary input door is open.
- Page 6 (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. Modifications not expressly approved by Sonetics Corporation could void the user’s authority to operate the equipment.
- Page 7 FCC/IC RF Exposure Warning • This product complies with FCC radiation exposure limits set forth for an uncontrolled environment. • The Headset is designed for body-worn operation and meets FCC RF exposure guidelines when used with accessories supplied with this product. (All necessary accessories are included in the package; any additional or optional accessories are not required for compliance with the guidelines.) Use of other accessories might not comply with FCC or IC RF exposure guidelines.
- Page 8 Contact your local waste management officials for information and regulations on the proper collection, recycling, and disposal of batteries. Use only the replacement batteries approved by Sonetics Corporation which have internal protection circuit, use of non-approved battery replacements may cause fire, injury or damage product.
