ffelectronics Sidus EL Quick Start Manual

S S S S idus idus EL EL
idus idus EL EL
energy limiter for FAI F1Q class
This device complies with the latest FAI F1Q rules and is compatible with most current F1Q e-
Timers. It monitors the energy consumed by the motor and, if the set energy limit is reached,
issues a motor cutoff signal that is handled by the e-Timer.
female 3.5mm bullet connector (to ESC)
e-Timer connector

Features

•
built-in 3.5mm bullet standard connectors for energy metering
•
built-in 4-digit LED display. Directly shows the consumed or programmed energy amount
•
built-in energy limit programming pushbutton. Maximum allowed energy amount is user-
programmable without any external devices

Technical data

•
Size .............................. 27.5 x 38.0 x 6.0 mm
•
Weight ........................
•
Voltage range ............... 7.4 to 25.2Vdc (2s to 6s LiPo)
•
Current range ............... 3.0 to 65.0 Amps
•
Energy range ............... 500 to 2750 Joule in steps of 1 Joule
•
Sample rate .................. 100 samples/s
•
Internal resistance ......
•
Output signal ............... open-drain negative going 20mS pulse

HOW IT WORKS

Assuming the limiter is wired as shown in the following, on battery connection it will display
CA CA CAL L L L CA self-calibration) for about 5 seconds. During this period the unit evaluates the amount of the
(
current flow to the ESC, e-Timer and servo(s) system in idle state and with motor off.
On self-calibration completion the unit briefly flashes the programmed energy limit (e.g.
then the display switches to the current value (
ready.
The unit starts counting the consumed energy as soon as the e-Timer start-switch is released
while the motor is running. During energy counting the limiter displays the current value for the
consumed energy while it gets incremented.
When the programmed energy limit is reached, the limiter issues the motor cut-off signal for the e-
Timer and alternately displays the energy amount and the motor cut-off time (e.g.
This visualization remains until the battery is disconnected or if the motor is started again.
6.0 gr
500µΩ
Quick Reference Guide - V1.0 May 2012
male 3.5mm bullet connector (from battery)
programming pushbutton
0000 0000 ) for the consumed energy. The limiter is
0000 0000
2750 2750 2750 2750 ),
2750 2750 09 09 46 46
2750 2750 09 09 . 46 46 ).
/
Page 1 of 2
