RealTrace V8Mobile Basic User Manual

Electronic chip reader

Advertisement

V8Mobile
Electronic chip reader
In compliance with ISO 14223 and
11784/85
Basic User Manual
Congratulations, you have just purchased your V8Mobile reader. This reader can read all FDX-B-type electronic chips (in compliance with ISO 11784), as
well as all FDX A and HDX chips.
This reader is one of a kind. I It is the expression of a new concept, which associates an RFID reader to any mobile phone that runs on ANDROID. Given
that it has a battery of its own, the reader is completely independent from the phone. The communication between the reader and the mobile phone is
done via a Bluetooth connection.
The mobile can be secured to the V8Mobile reader as a separate attachment or it can be used detached (albeit at a maximum distance of fifteen metres).
This new concept not only allows you to read and record numbers of transponders but also to associate information, such as the date, time, location and
photos.
This data can be stored in the memory of the mobile phone but also stored in the "cloud".
As you will be able to confirm, its use is extremely simple.
Description of the V8Mobile reader
On the rear part of the casing, there is a button that allows for the commissioning of a reader. By pressing this button, you will be activating the reader
and the Bluetooth function. Activation of the reader results in the blinking of a blue "LED" light on the right side of the device.
On the same right side of the device is a micro USB connector that is used to charge the device, as well as a button that is used to trigger the reading of
transponders. The read request can also be made from the phone screen
Power button
Purpose of the mobile
camera

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V8Mobile and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for RealTrace V8Mobile

  • Page 1 Bluetooth connection. The mobile can be secured to the V8Mobile reader as a separate attachment or it can be used detached (albeit at a maximum distance of fifteen metres). This new concept not only allows you to read and record numbers of transponders but also to associate information, such as the date, time, location and photos.
  • Page 2 Battery charging The reader is powered by its own Lithium / ion battery. This is provided so as to allow for thousands of readings. It is charged when connected to the V8 Mobile reader via a USB port. On the left side of the reader is a red "LED" light, which indicates that charging. This turns to green when charging is complete.
