Summary of Contents for anko KJM-301

  • Page 2 WIFI DVD PROJECTOR Model number: KJM-301 Key code: 42816827 PLEASE READ CAREFULLY BEFORE OPERATING THIS EQUIPMENT KEEP IT IN A SAFE PLACE FOR FUTURE REFERENCE...

  • Page 3: Caution

    CAUTION: Usage of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. This unit should not be adjusted or repaired by anyone except qualified service personnel. PRECAUTIONS BEFORE USE KEEP THESE INSTRUCTIONS IN MIND: 1.
  • Page 4 your home, consult your dealer or local power company. 15. The socket outlet must be installed near the equipment and must be easily accessible. 16. Do not overload ac outlets or extension cords. Overloading can cause fire or electric shock. 17.

  • Page 5: Packing Included

    safety. 33. This product is intended for indoor, household use only and not for commercial or industrial use. 34. Make sure the unit is adjusted to a stable position. Damage caused by using this product in an unstable position or by failure to follow any other warning or precaution contained within this user manual will not be covered by warranty.

  • Page 6: Table Of Contents

    Table of Contents Caution - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P1 Precautions before use - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - P1...

  • Page 7: Remove & Close The Lens Cover

    Remove & Close The Lens Cover Remove the lens cover before using Close the lens cover when unit not in use REMOVE CLOSE LENS COVER LENS COVER Placing Your Projector Your projector can be installed in four different configurations ( see picture below): Front Table: Select this location with the projector placed...

  • Page 8: Distance Between The Projector And Screen

    Square /Rectangle It is recommended to move the projector as close to center of screen. Distance Between The Projector And Screen Measure the distance between the projector and where you want to position the screen. This is the projection distance. "...

  • Page 9: Adjust The Vertical Location

    Follow below picture to adjust the vertical location. SCREEN SCREEN VERTICAL PROJECTOR VERTICAL DIMENSION DIMENSION ROJECTOR SCREEN VERTICAL DIMENSION PROJECTOR Adjust this knob ( ANGLE ADJ. knob) to fine- tune the display angle to higher. Adjust The Focus And Keystone Follow below picture to adjust the focus and trapezoidal screen.

  • Page 10: Controls Of Remote

    Controls Of Remote POWER Press to power ON. Mute MUTE Mute the audio of the player.Press it again to activate the sound. RANDOM RANDOM ANGLE SUBTITLE Press to random playing for the loaded disc. REPEAT TITLE MENU Press to display the information of the current video/ audio. Angle PROG SLOW...

  • Page 11: Controls Of Projector

    AAA / UM4 AAA / UM4 BATTERY DOOR Remove the battery compartment cover on the back of your remote by carefully sliding to open. The battery cover can then be lifted away. Fit the correct batteries (not included), referring to the polarity markings. Finally, replace the cover.

  • Page 12: Install Power Adapter

    Install Power Adapter Follow below picture to connect power adapter Connect small end of adapter FIRST. Plug the adapter body to power outlet. The socket-outlet shall be installed near the equipment and shall be easily accessible. - Press the button to turn on unit, press again to turn off. / SOURCE - Press the button to select input source.

  • Page 13: Wifi Connection

    WiFi Connection Step1: Step2: Find “WiFi”. Step3: Choose “Scan”. Select your wireless network from list and type in the password. Step4: connection. iOS Cast Step1: Select “iOS Cast” on the home page. Step2: iOS devices and projectors must be connected to the same network. Step3: Open the control center of iOS device, Choose “Screen Mirroring”.
  • Page 14 Connect HDMI Show The Image On Projector Screen Follow below picture to connect HDMI cable and device. Turn off the unit before connect HDMI cable. light GREEN / SOURCE Press the device will show on projector screen. There are 2 HDMI input, HDMI1 interface corresponds to HDMI 1 in SOURCE mode , and HDMI2 interface corresponds to HDMI 2 in SOURCE mode.

  • Page 15: Connect Vga Show The Image On Projector Screen

    Connect VGA Show The Image On Projector Screen Follow below picture to connect HDMI cable and device. Turn off the unit before connect VGA cable. Press the button to turn off power of your projector before connection. light GREEN / SOURCE Press the will show on projector screen.

  • Page 16: Connect Audio Output (Aux Out / Line Out / Earphones)

    Connect Audio Output ( Aux Out / Line Out / Earphones) Follow below picture to connect audio cable and device. Press the button to turn off projector power before connecting. Use an audio cable as shown below to connect the external device to the projector. Turn on the projector and the external device.
  • Page 17 MicroSD Card And USB Playback (Media Player) Install USB / microSD device: 1. Turn off the unit before inserting USB/ microSD card. 2. Install the USB device into USB port. 3. After connecting, press the button to turn on unit and the power indicator lights up GREEN.

  • Page 18: Using Dvd Playback

    Sub-Menu on Photo screen 1. During photo playback, press the Figure 1. screens show up (figure 1). Next Prev. Pause background Stop Re... PL... Info music 2. Use the button to select icon and press Zo... M... Zo... Rotate Rotate Sub-Menu on Music screen 3.

  • Page 19: Using Projector Menu 1.0

    select it. 3. When successfully paired, it will show ' Bluetooth Connected' on the menu. Exit the menu, the sound will come out from the bluetooth speaker. 4. The projector connects to the last bluetooth speaker automatically when the unit is powered on again. Note: The automatic pairing happens only if the last connected Bluetooth speaker is turned on.

  • Page 20: Using Projector Menu 2.0

    Using Projector Menu 2.0 Press source of the home page to enter projector sound setup. buttons to select manual page. 1. Sound Mode 2. Bass 3. Treble 4. Balance 5. Equalizer Sound Mode - User Parameter Treble 0-100 Bass 0-100...

  • Page 21: Using Projector Menu 3.0

    Language/Boot Source/Sleep Timer/Local update/Online update/Restore Factory Default English Chinese German Russian French Korean Dutch Japanese Spanish Italian Portuguese Vietnamese Chinese_TW Hungarian Polish Croatian Thai INFO Display the unit information as below. Model: 42816827 SN:EV0386-1 LOGO ANKO Bluetooth BT V5.0 Software Version: KJ-3A017:2019-XX-XX...

  • Page 22: Specifications

    Specifications Light Source Type Brightness Output 2800 lumens 800 x 480 Display Native Resolution 1080p , 1080i , 720p, 576i , 480p, and 480i HDMI Input Supported Video Resolution. Operating 48W; Standby 0.8W Power Consumption Power Input DC 12V , 4A Connect Included Adapter Input AC100-240V,50/60Hz Included Adapter...

  • Page 23: Troubleshooting

    TROUBLESHOOTING Before resorting the maintenance service, please kindly check by yourself with the following chart. 1.Power light is on. If it is not on, check the projector is plugged into the mains, that the socket is switched on, and then press the power button on the projector.
