Summary of Contents for EK Quantum Vector FTW3 RTX 3080
- Page 1 EK-Quantum Vector FTW3 RTX 3080/3090 Backplate BACKPLATE USER GUIDE...
- Page 2 This product is intended for installation only by expert users. Please consult with a qualified technician for installation. Improper installation may result in damage to your equipment. EK Water Blocks assumes no liability whatsoever, expressed or implied, for the use of these products, nor their installation.
-
Page 3: Table Of Contents
TABLE OF CONTENTS BOX CONTENTS BACKPLATE DIMENSIONS REQUIRED TOOLS INSTALLING THE BACKPLATE PREPARING THE GRAPHICS CARD CUTTING AND PLACING THERMAL PADS ATTACHING THE BACKPLATE TESTING THE LOOP WARRANTY SUPPORT AND SERVICE SOCIAL MEDIA - 3 -... -
Page 4: Box Contents
Mounting mechanism - You may not need all the screws, mounting mechanism is universal! M2.5x8 AX1 Screw - Black (8 pcs) EK-Quantum Vector FTW3 RTX 3080/3090 backplate M2.5x8 AX1 Screw - Nickel (8 pcs) Thermal PAD G 1.5 mm - (120x24mm) (1 pcs) Thermal PAD G 2.0 mm - (120x24mm) (4 pcs) -
Page 5: Backplate Dimensions
BACKPLATE DIMENSIONS 5.20 mm 302.60 mm REQUIRED TOOLS Phillips Head Screwdriver Scissors - 5 -... -
Page 6: Installing The Backplate
CUTTING AND PLACING THERMAL PADS Your backplate is supplied with thermal pads that needs to be cut into smaller pieces in order to cover all VRM components. EK made sure to provide customers with more than adequate quantity of 1 mm 120 mm thermal pads to complete this step. - Page 7 STEP 3 3080: Once cut to size thermal pads should be applied to the backplate as shown in the image. Thermal Pad G 1.0 mm Thermal Pad G 1.5 mm Thermal Pad G 2.0 mm 3090: Thermal Pad G 1.0 mm Thermal Pad G 1.5 mm Thermal Pad G 2.0 mm STEP 3...
-
Page 8: Attaching The Backplate
8 pcs STEP 4 TESTING THE LOOP To ensure the installation of EK components was successful, we recommend you perform a 24-hour leak test. When your loop is complete and filled with coolant, connect the pump to a PSU outside your system. Do not connect power to any of the other components. -
Page 9: Warranty
This warranty is voided if the product comes in contact with aggressive UV additives or other improper liquids. EK water blocks are sealed with a warranty-voiding circular label, proving the water block has withstood a pressure leak test. -
Page 10: Support And Service
SUPPORT AND SERVICE In case you need assistance, please contact: https://www.ekwb.com/customer-support/ EKWB d.o.o. Pod lipami 18 1218 Komenda Slovenia - EU SOCIAL MEDIA EKWaterBlocks @EKWaterBlocks ekwaterblocks EKWBofficial ekwaterblocks...
