Vilter VSS 451-1801 Operation And Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
VPN 35391S
February 2006 Rev. 05
Price $ 60.00
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VSS 451-1801 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Vilter VSS 451-1801

  • Page 1 VPN 35391S February 2006 Rev. 05 Price $ 60.00...
  • Page 3 At the same time, the local Vilter representative or the home office should be notified of any claim made. All inquires should include the Vilter order number, compressor serial and model number. These can be found on the compressor name plate on the compressor.

  • Page 4: Table Of Contents

    LONG TERM STORAGE REQUIREMENTS ............................8 DOMESTIC TERMS and CONDITIONS .............................. 10 EXPORT TERMS and CONDITIONS ..............................12 STANDARD VILTER WARRANTY STATEMENT ..........................14 STANDARD VILTER 5/15 WARRANTY STATEMENT ........................15 DESCRIPTION ......................................16 SYMBOLS AND MEANINGS ................................18 Installation Section ......................
  • Page 5 Table of Contents Operation Section ......................OIL SYSTEM ......................................43 Non-Vilter Oil Notice ..................................42 Oil Charge ....................................... 43 Oil Filter ......................................43 Filter Removal and Installation, all VSR Units..........................43 Filter Removal, VSS and VSM Units .............................. 44 Filter Removal, VSS and VSM Units .
  • Page 6 Table of Contents Service Section Cont ................................GATE ROTOR BLADE REMOVAL ............................... 69 GATE ROTOR BLADE INSTALLATION .............................. 69 GATE ROTOR THRUST ..................................70 BEARING REMOVAL GATE ROTOR THRUST ..........................70 BEARING INSTALLATION GATE ROTOR ROLLER .......................... 71 GATE ROTOR ROLLER BEARING REMOVAL ..........................72 GATE ROTOR ROLLER BEARING INSTALLATION ..........................
  • Page 7 Table of Contents PLUG APPLICABILITY ..................................92 TORQUE SPECIFICATIONS .................................. 93 OIL FILTER ELEMENTS ..................................94 VSS, VSM and VSR SINGLE SCREW COMPRESSORS SERVICE INTERVAL REQUIREMENTS ......Recommended Spare Parts List ................VSS and VSR Replacement Parts Section ..............Gate Rotor ...................................... 104 Shaft Seal .......................................

  • Page 8: Long Term Storage Requirements

    We suggest using the accompanying Long Term Storage Log sheet for recording purposes to validate the appropriate procedures. Prior to start-up, Vilter recommends that a complete system pressure check be performed. Upon verification of the system integrity, a comprehensive evacuation procedure should be completed to ensure a dry system before refriger- ant is introduced.
  • Page 9 Long Term Storage Requirements Remove the condensation drain plugs from those units equipped with them and insert silica-gel into the openings. Insert one-half pound bags of silica-gel (or other desiccant material) into the air inlets and outlets of drip-proof type motors. NOTE: The bags must remain visible, and tagged, so they will be noticed and removed when the unit is prepared for service.

  • Page 10: Domestic Terms And Conditions

    DOMESTIC TERMS and CONDITIONS Exclusivity. Seller’s acceptance of Buyer’s order is expressly conditional upon Buyer’s agreement to these terms and conditions. All inconsistent or additional terms, modifications, or changes are deemed material, are expressly re- jected, and do not form a part of this Agreement unless Seller agrees to such terms in writing. Home Office Approval.
  • Page 11 DOMESTIC TERMS and CONDITIONS Changes, Cancellations, and Returns. Buyer will pay reasonable charges and all associated costs and damages arising from canceling or changing this Agreement. No returns shall be allowed other than with Seller’s express permission, and such returns shall include a reasonable restocking charge to the extent permitted by law. Resellers and Distributors.

  • Page 12: Export Terms And Conditions

    Upon acceptance, prices are firm for only three months and subject to reasonable escalation. Unless agreed otherwise in writing, all payments are due in full upon receipt of order or Vilter’s receipt of an acceptable letter of credit. All overdue amounts will incur finances charge of the lesser of (a) 1 ½ % per month and (b) the maximum allowed by law.
  • Page 13 EXPORT TERMS and CONDITIONS Products or parts for which a warranty claim is made are to be returned transportation prepaid to Seller’s factory. Any improper use, corrosion, neglect, accident, operation beyond rated capacity, substitution of parts not approved by Seller, or any alteration or repair by others which, in Seller’s judgment, adversely affects the Product, shall void all warranties and warranty obligations.

  • Page 14: Standard Vilter Warranty Statement

    STANDARD VILTER WARRANTY STATEMENT Seller warrants the products it manufactures to be free from defects in material and workmanship for a period of eighteen (18) months from the date of shipment from Seller’s manufacturing plant or twelve (12) months from date of installation at the initial end users location, whichever occurs first.

  • Page 15: Standard Vilter 5/15 Warranty Statement

    This includes the compressor inspections, completing periodic oil analysis and the change out of the oil and oil filters, and related components as required with only genuine Vilter parts. The customer is required to keep a maintenance log and receipts demonstrating the use of Genuine Vilter parts for validation of a warranty claim, if requested.

  • Page 16: Description

    Description COMPRESSOR ing is flooded with gas at suction pressure. The The Vilter Single Screw Compressor is a positive gas enters the open end of the main screw flutes at displacement, capacity and volume controlled, oil the driven end, and becomes trapped in the screw...
  • Page 17 Description continues until the screw rotates far enough for The Vilter compressors feature the exclusive the flute to pass the end of the volume ratio slide. Parallex™ Slide System, which consists of a pair At this point, the screw flute lines up with the of slides for each gate rotor assembly.

  • Page 18: Symbols And Meanings

    Symbols and Meanings Note: The symbols that appear on this page, are used throughout the manual to help identify any potential warnings, cautions or hazards and to assist in avoidance of any accidents or injuries. Electrical Hazards............Misc. Hazards............... Mechanical Hazards............. Fire Hazards..............

  • Page 19: Installation Section

    Installation Section Installation Section ...................... DELIVERY INSPECTION ..................................21 UNIT WEIGHTS ...................................... 21 FOUNDATIONS ...................................... 21 LOCATING UNIT - DRIVE COUPLING ALIGNMENT ........................21 SYSTEM PIPING ....................................21 ELECTRICAL CONNECTIONS ................................23 TESTING REFRIGERATION SYSTEM FOR LEAKS .......................... 23 Ammonia Systems ................................... 23 Halocarbon Refrigerant Systems ..............................

  • Page 21: Delivery Inspection

    At the same time, the crete pad, check both lengthwise and crosswise local Vilter representative or the home office to assure it is level. Use shims and wedges as should be notified of any claim made.
  • Page 22 Installation In making up joints for steel pipe, the following bon piping, only wrought copper fittings should procedures should be followed: be used. Cast fittings as used for water service are porous and will allow the refrigerant to es- For threaded connections, all threads on the pipe cape.

  • Page 23: Electrical Connections

    Repair all visible leaks. If possible, Vilter equipment is tested for leaks at the factory. leave the pressure on over night. A small pres- One the most important steps in putting a refrig- sure drop of 5 lbs.

  • Page 24: Halocarbon Refrigerant Systems

    Installation Charge a small amount of ammonia into the sys- condensables from the system before charging it tem and pressurize the system to its respective with refrigerant. A combination of moisture and design pressure. Pass a lit sulfur stick around all refrigerant, along with any oxygen in the sys- joints and connections.

  • Page 25: Unit Oil Charging

    This process should be repeated until all pockets of water have been boiled off, and the vacuum Due to the need for adequate lubrication, Vilter pump has had a chance to remove all the water recommends only the use of Vilter lubricants, vapor from the system.

  • Page 26: Low Side Equipment

    Installation the “low side”. High side charging is usually After the system is leak-free and evacuation has used for initial charging as filling of the system is been completed, it is ready for charging. Before much faster. Low side charging is usually reserved actual charging, however, the entire operation of for adding only small amounts of refrigerant after the refrigeration system should be inspected as...

  • Page 27: Maintenance Suggestions

    Installation mally. To check that enough refrigerant has replaced. been added, the liquid sight glass should show no bubbles, and there will be a liquid Check compressor sound for abnormal seal in the receiver. If these two conditions noises. are not satisfied, additional refrigerant must be added.

  • Page 28: System Leaks

    23. Drain and clean entire oil system at receiver rial standards are maintained throughout all drain. Recharge with new clean moisture Vilter compressors, continuous operation and any free oil. For proper procedure for changing presence of dirt may prove injurious to the ma- micronic oil filter and charging oil into the chine.

  • Page 29: Stop Check" Installation

    The drill fixture is designed so that the hole for the spring will always be drilled on the opposite side from the cast-in Vilter name on the bonnet. From the outside of the valve, the casting numbers must always be towards the top of the valve.

  • Page 30: Couplings Installation And Alignment

    Installation IIV . COUPLINGS INSTALLATION AND ALIGNMENT B. Straight Bore: These instructions are intended to help you to 1. Install key(s) in the shaft. If the hub is an installand align the coupling. Covered here will interference fit, heat the hub in an oil bath or be general information, hub mounting, alignment, oven until bore is sufficiently larger than the assembly, locknut torquing, discpack replacement,...

  • Page 31: Shaft Alignment

    Installation Coupling Total Indicator Dimension “E” Torque Size Reading (T.I.R.) Ft.-Lbs. Angle Parrallel (In.-Lbs.) .004 .003 1.36 1.37 (24) .005 .003 1.74 1.75 (36) .005 .003 1.77 1.78 (36) .006 .004 2.08 2.10 (96) .007 .005 2.46 2.48 (156) .009 .005 2.46 2.48...

  • Page 32: Final Assembly

    Installation a. If the coupling arrived assembled, the disc d. Parallel Offset. Rigidly mount a dial indi- packs are still attached to the center ring. Be- cator on one hubor shaft, reading the other hub fore taking the discs packs off, first install one flange outside diameter, as shown in Figure 3.
  • Page 33 Installation initial operation. E.For further help with the installa- tion or alignment, consult Rexnord. F. Disc Pack Replacement. If it becomes necessary to replace the disc pack, it can be done as follows: A. Remove all the long bolts and lower the cen- ter ring by sliding it our from between the two disc packs.

  • Page 34: Slide Valve Actuator

    INSTALLATIONS INSTRUCTIONS pletely. Caution If not already done, mount the slide valve actuator per (“Vilter Actuator set WHEN INSTALLING THE OPTICAL SLIDE up for Capacity and Volume Slide Mo- MOTOR, LOOSEN LOCKING COLLAR tors). Next, wire the actuator per the...
  • Page 35 Installation & Calibration stated earlier, the actuator voltage will during the calibration process. To prevent fluctuate during calibration. After the damage to the actuators, do not connect the actuator has been calibrated, 0V output yellow power cable or the gray position will correspond to the minimum position transmitter cable until instructed to do so and 5V to the maximum position.
  • Page 36 Installation now calibrated and knows the minimum calibration and exit the “Slide Calibration” and maximum positions of the slide valve screen. The controller will automatically it controls. Now the capacity or volume energize the actuator and drive it back to channel of the Vission/Vantage can be its minimum position (below 5%) for pre- calibrated.

  • Page 37: Slide Valve Trouble Shooting Guide

    Slide Valve Actuator Troubleshooting Guide Slide Valve Actuator Theory of Operation the saved motor position is read from EEPROM memory and the actuators resumes normal function The slide valve actuator is a gear-motor with a position sensor. The motor is powered in the for- This scheme is not foolproof.
  • Page 38 Slide Valve Actuator Troubleshooting Guide The actuator cannot be cali- Dirt or debris is blocking one or both Clean the optocoupler slots with optocoupler slots a Q-Tip and rubbing alcohol. brated The photochopper fence extends less Adjust the photochopper so that than about half way into the the fence extends further into the optocoupler slots...
  • Page 39 Slide Valve Actuator Troubleshooting Guide The actuator does not transmit The motor was manually moved Recalibrate. the correct position after a power while the position sensor was not loss powered. The motor brake is not working Get the motor brake to where it op- properly erates freely and then recalibrate.
  • Page 40 Slide Valve Actuator Troubleshooting Guide Replace the actuator. The motor runs sporadically Bad thermal switch See above. Any of the reasons listed in “The mo- tor will not move in either direction” The motor runs but output shaft Replace the actuator. Stripped gears inside the gear motor will not turn or the armature has come un-pressed...

  • Page 41: Operation Section

    Operation Section Operation Section ......................OIL SYSTEM ......................................43 Oil Charge ......................................43 Oil Filter ......................................43 Filter Removal and Installation, all VSR Units..........................43 Filter Removal, VSS and VSM Units .............................. 44 Filter Removal, VSS and VSM Units ............................44 Oil Pressure Regulating ...................................

  • Page 42: Non-Vilter Oil Notice

    We realize that customers may choose compressor lubricants other than Vilter branded oil. This is cer- tainly within the customers’ right as owners of the equipment. When this choice is made, however, Vilter is unable to accept responsibility for any detrimental affects those lubricants may have on the equipment or system performance and durability.

  • Page 43: Oil System

    Operation Filter Removal and installation, all OIL SYSTEM VSR Units. Oil Charge Release the pressure in the oil filter housing by opening the bleed valves at the stop valve in Charge the combination oil receiver/separator the block and bleed assembly, or at the bleed with the proper quantity of lubricating oil (see valve for the oil filter housing.

  • Page 44: Filter Removal, Vss And Vsm Units

    Du- plex (Vilter Part #3109A or 3110A), or Filter Removal, VSS and VSM Units through the stop valve for the oil filter hous- (after 5/1/00) when using Vilter Part ing.

  • Page 45: Oil Pressure Regulating

    Operation the cover assembly in place. On units to follow all Local, State and Federal ordinances re- equipped with dual element tanks, insert in- garding the recovery of refrigerants. ner element and make sure it fits onto the outlet connection. Put the centering piece Drain the filter bowl or housing in to an appropriate on the outer element and slide into tank mak- container and dispose of the oil in a appropriate...

  • Page 46: Liquid Injection Oil Cooling

    Operation 1/4” Fine Adjustment Valve FIGURE 4. TYPICAL WATER COOLED OIL COOLER FIGURE 5. DIAGRAM TYPICAL LIQUID INJECTION OIL COOLING SCHEMATIC DIAGRAM The solenoid valve provides positive water shut-off when the compressor is not in opera- Liquid injection cooling on booster compressors is tion.

  • Page 47: Thermosyphon Oil Cooling

    Operation sure transducers. To use the block and bleed the temperature controller adjusts the speed valves to recalibrate the pressure transducers, the of the pump/motor combination to maintain block valve is shut off at the unit and the pressure a constant oil temperature. is allowed to bleed off by opening the bleed valve near the pressure transducer enclosure.

  • Page 48: Slide Valve Control

    Operation COMMAND SHAFT ROTATION NO. OF TURNS / ROTATION ANGLE / SLIDE TRAVEL COMP. CAPACITY VOLUME CAPACITY VOLUME MODEL TURNS/ANGLE/TRAVEL TURNS/ANGLE/TRAVEL VSR 111 0.91 / 328 / 3.568" 0.52 / / 2.045" VSR 151 0.91 / / 3.568" 0.52 / / 2.045"...

  • Page 49: Slide Valve Motor Location

    Operation View Capacity Instruction Manual.) Note: Optical Oil Separator Heater Actuators CAN NOT be manually rotated. The oil separator heater keeps the oil in the ( VSM 501-701 will separator from becoming too viscous and have motor locations opposite of figure #6) helps to boil off refrigerant entrained in the oil in the receiver section of the separator.

  • Page 50: Suction Pressure

    Operation the valve to set it in the automatic position. Suction Pressure Manually open the oil isolating valve at the Low suction pressure cutout stops the oil separator outlet connection. compressor unit when the suction pres- sure drops below the setpoint. 5.

  • Page 51: V-Plus Oil Cooling

    “Stop Check” Operation AUTO In the “Auto Position”, the stop valve is operating as a check valve, allowing flow in the directions of the arrows. To set the valve to the automatic position, fully close the valve, and turn the stem out as indicated by the chart below.

  • Page 52: Stop Check Operation

    Pre-Start Up Check List...

  • Page 53: Pre-Start Up

    PRE START-UP CHECKLIST FIELD PIPING AND MECHANICAL REQUIREMENTS NOTE: If start-up service has been purchased, the following items should be completed before the start-up man arrives. This will help save time and money. _____ The unit should be leveled and secured to the mounting pad or floor. _____ The suction and Discharge line must be piped and properly supported, independent of the unit...

  • Page 54: Pre Start-Up Checklist - Field Piping And Mechanical Requirements

    PRE START-UP CHECKLIST FIELD WIRING REQUIREMENTS VILTER MANUFACTURING CORPORATION VRS SCREW COMPRESSOR, VSS/VSM SINGLE SCREW COMPRESSOR UNITS PRESTART-UP CHECKLIST ® FIELD WIRING REQUIREMENTS FOR UNITS WITH FACTORY WIRED VISSION MICROPROCESSORS NOTE: If startup service has been purchased, to save time and money, the following items should be completed before the startup technician arrives.

  • Page 55: Pre Start-Up Checklist - Field Wiring Requirements

    Service Section Service Section ......................GENERAL COMMENTS ..................................58 PREPARATION OF UNIT FOR SERVICING ............................58 REMOVAL OF COMPRESSOR FROM THE UNIT ..........................58 INSTALLATION OF THE COMPRESSOR ............................59 LEAK CHECKING UNIT ..................................59 ANNUAL INSPECTION ..................................60 NORD-LOCK WASHERS ..................................61 GATE ROTOR ASSEMBLY ..................................

  • Page 56: Service Section

    Service Section POTENTIOMETER REMOVAL ................................87 POTENTIOMETER INSTALLATION ..............................88 RETROFIT CAPACITY AND VOLUME RATIO CONTROL ....................... 88 ASSEMBLIES ON ALL VSS AND VSR COMPRESSORS MANUFACTURED BEFORE MAY 1, 1995................................88 REMOVAL ........................................... 88 INSTALLATION OF RETROFIT COMMAND SHAFT BEARING AND O-RING SEAL ....................................
  • Page 57 “Pre Start-Up Check List” must be verified. Time and money **9. Open the stop valve at the inlet of the will be saved before the Vilter start-up man ar- pressure regulator. rives. **10. Open the metering valve 1/8 to 1/4 of a turn.

  • Page 58: General Comments

    Service 0.00 GENERAL COMMENTS C) Isolate the unit by manually closing the dis- When working on the compressor, care must be charge Stop/Check valve. If the unit is taken to ensure that contaminants (i.e. water from ® equipped with a V-PLUS or liquid injection melting ice, dirt and dust) do not enter the com- pressor while it is being serviced.

  • Page 59: Installation Of The Compressor

    Service ance under the fourth compressor foot. If there is clearance, add the appropriate amount CAUTION of shims. Tighten down the fourth bolt and loosen either adjacent bolt and check again May cause an electrical shock! for clearance, adding shims accordingly. Align the compressor and motor.

  • Page 60: Annual Inspection

    Service 0.05 ANNUAL INSPECTION The Vilter Single Screw Compressor is designed for long periods of trouble free operation with a minimum of maintenance. However, a yearly in- spection is recommended so any irregular wear is noted and rectified. At this time, the bearing float is measured for the main rotor and gate rotors.

  • Page 61: Nord-Lock Washers

    0.030 over table tor blade to protect the blade. tolerance contact Vilter’s home office. 3) The maximum amount of bearing float should not exceed 0.002”. Inspect the main and gate rotors for signs of abnormal wear due to dirt or other contaminants.

  • Page 62: Gate Rotor Assembly

    Service 1.00 GATE ROTOR ASSEMBLY CAUTION Gate rotor removal and assembly is divided into distinct instructions, instructions for all VSS and VSR models and different instructions for all VSM models. Please follow the appropriate set of instructions. 1.01 A REMOVAL (All VSS and VSR Models) A) Prepare the compressor for servicing as out- lined in section 0.01.
  • Page 63 Service E) Remove the hex head and socket head bolts from the thrust bearing cover. Insert two of the bolts into the threaded jacking holes to assist in removing the cover. Retain the shim pack and keep it with the bearing housing cover.

  • Page 64: Removal (All Vsm Models)

    Service 1.01 B REMOVAL (ALL VSM MODELS) The removal of the gate rotor assembly for the VSM compressors is similar for the VSS/VSR compressors. However, the thrust bearing outer races are not secured in a stationary bearing hous- ing as on the VSS/VSR compressors. On VSM compressors the thrust bearings are located in the gate rotor support and rotate with the sup- port when the compressor is in operation.
  • Page 65 Service E) Remove plug on the thrust bearing housing. Loosen the socket head cap screw that is lo- cated underneath the plug. This secures the inner races of the thrust bearings to the spindle. F) Remove bolts that hold the thrust bearing housing to the compressor.

  • Page 66: Installation (All Vss And Vsr Models)

    Service 1.02 A INSTALLATION (All VSS and VSR Models) A) Install the gate rotor support by carefully tilt- ing the roller bearing end of the gate rotor support towards the suction end of the com- pressor. The compressor input shaft may have to be rotated to facilitate the installa- tion of the gate rotor support.
  • Page 67 Service D) Set the clearance between the gate rotor blade and the shelf. Place a piece of 0.003”-0.004” shim stock between the gate rotor blade and the shelf. Measure the depth from the top of the compressor case to the top of the thrust bearing housing.

  • Page 68: Installation (All Vsm Models)

    Service 1.02B INSTALLATION (All VSM Mod- els) A) Install the gate rotor support. Carefully tilt the roller bearing end of the gate rotor sup- port towards the suction end of the compres- sor. The compressor input shaft may have to be rotated to facilitate the installation of the gate rotor support.

  • Page 69: Gate Rotor Blade Removal

    Service 1.03 GATE ROTOR BLADE REMOVAL A) Remove the gate rotor assembly. Refer to section 1.01 or 1.01B on gate rotor assembly removal. B) Remove the snap ring and washer from the gate rotor assembly. Lift gate rotor blade assembly off the gate rotor support. C) Check damper pin and bushing for exces- sive wear.

  • Page 70: Gate Rotor Thrust

    Service B) Install damper pin bushing (120) in gate ro- tor blade (111) from the back side of the blade. Be sure the bushing is fully seated. C) Place the blade assembly on the gate rotor support. Locating Damper over pin. D) Install washer (119) and snap ring (130) on gate rotor assembly.

  • Page 71: Bearing Installation Gate Rotor Roller

    Service 1.06 GATE ROTOR THRUST BEARING INSTALLATION A) For installation of thrust bearings on VSS and VSR units: 1) Install bearings (126) in the housing so the bearings are face to face. The larger sides of the inner races are placed together.

  • Page 72: Gate Rotor Roller Bearing Removal

    Service 1.07 GATE ROTOR ROLLER BEARING REMOVAL A) Refer to section 1.01 for removal of the gate rotor bearing housings and gate rotor sup- ports. B) Remove the snap ring (131), which retains the roller bearing in the bearing housing. C) Remove the roller bearing (125) from the bearing housing (112).

  • Page 73: Input Shaft Seal Replacement

    219A 219C There are two types of shaft seals that have been used interchangeably in the Vilter VSS and VSR Single Screw Compressors. The first type has a stationary mirror face and rotating carbon. The second type has a stationary carbon and a rotat- ing mirror face.

  • Page 74: Shaft Seal Installation

    Service Stationary seal 2.02 SHAFT SEAL INSTALLATION NOTE: When replacing the stationary members of the seal on the VSR 111 thru VSR 301, and VSS 451 and VSS 601, the roll pin in the cover is used only with the seal assembly having a sta- tionary mirror face.

  • Page 75: Main Rotor Assembly

    Service D) Lubricate the inside area of the rotating seal with clean compressor lubricating oil, do not wipe or touch the face of the rotating portion of the seal. Align the slot in the rotating seal with the drive pin on the compressor input shaft.

  • Page 76: Inspection Of Slide Valve Assemblies In The Compressor

    Service 3.00 INSPECTION OF SLIDE VALVE ASSEMBLIES IN THE COMPRESSOR Prepare the compressor for servicing as outlined in section 0.01. A) Remove the gate rotor access covers. Using Check for excessive wear in these Check for wear in these areas. a mirror and flashlight, visually inspect the areas.

  • Page 77: Installation Of Slide Valve Carriage Assemblies

    Service shafts and the slide valve racks as outlined in section 4.10. D) Locate and remove the socket head plugs above the slide valve carriage attachment bolts. Remove the bolts located under the plugs. E) The slide valve carriage may now be re- moved.

  • Page 78: Capacity And Variable Volume Ratio Control Assembly

    Service 4.00 CAPACITY AND VARIABLE VOLUME RATIO CONTROL ASSEMBLY A) The following instructions are applicable for most units equipped with optical gear mo- tors built after 11-1-01. For units equipped with potentiometer feed back gear motor built after 5-1-95, see section 4.10. For units built before 5-1-95, see Section 4.11.

  • Page 79: Optical Slide Valve Actuator Installation

    Service 4.02 OPTICAL SLIDE VALVE ACTUATOR INSTALLATION A) Install the key in the command shaft keyway. B) Slide the actuator assembly on to the com- mand shaft. While aligning one of the two key slots in the actuator shaft with the key on the command shaft.

  • Page 80: Gear Motor To Optical Slide Valve Actuator

    Service GEAR MOTOR TO OPTICAL SLIDE C) The four #10 holes in the existing mounting VALVE ACTUATOR CONVERSION, plate that will be utilized to attach the actua- REMOV AL OF GEARMOTOR tor must be in good condition. A 10-24 N.C. tap can be utilized to clean out the threaded holes.

  • Page 81: Command Shaft Assembly Installation

    Service Old Style Motor Plate 457 477 C) The unit can now be leak checked as out- lined in section 0.03.] 4.07 COMMAND SHAFT BEARING AND O-RING SEAL REPLACEMENT A) Remove command shaft assembly as outlined in section 4.05. B) Remove snap ring retainer (451) from com- mand shaft housing (412).

  • Page 82: Command Shaft Bearing And O-Ring Seal Reassembly

    Service 4.08 COMMAND SHAFT BEARING Guide rods AND O-RING SEAL Discharge REASSEMBLY spool A) Install new O-ring seal in housing and lu- bricate the O-ring with clean compressor oil. A vent hole is provided in the command shaft bearing housing to allow any refrigerant and oil that may leak past the O-ring seal to vent to atmosphere and not into the slide valve motor housing.

  • Page 83: Slide Valve Gear And Rack Inspection

    Service F) Look for any excessive wear on all moving C) On VSM compressors install the bolts in the parts and replace the worn parts. discharge flange. Install the drain plug in the bottom of the discharge manifold. G) Reassemble the manifold and discharge el- bow as outlined in section 4.10.

  • Page 84: Installation Of Capacity Or Volume Cross Shafts

    Service VSS compressors cross shafts. 4.13 INSTALLATION OF CAPACITY OR VOLUME CROSS SHAFTS A) To reassemble either set of capacity or vol- ume ratio slide valve racks, install the cross shaft with the pinion gear onto the back plate, place the remaining pinion gear on the shaft and drive in the roll pins.

  • Page 85: Removal And Installation Of Capacity Or Volume Ratio Actuators

    Service 4.21 REMOVAL 4.20 REMOVAL AND INSTALLATION OF CAPACITY OR VOLUME RA A) Prepare the compressor for servicing as out- TIO ACTUATORS (PRIOR TO 11- lined in section 0.01. 01 AND AFTER 5-1-95 The capacity and volume ratio control assemblies with their potentiometers are not interchangeable and must not be switched when they are re-in- stalled on the compressor.
  • Page 86 Service B) Install the motor plate and the four socket D) Remove nut and Nord-Lock ® washers, secur- ® head bolts, and Nord-Lock washers secur- ing the potentiometer drive gear to the com- ing it. Tighten the bolts to the recom- mand shaft assembly.

  • Page 87: Potentiometer Removal

    Service gear. Install the spacer, potentiometer drive gear, Nord-Lock washers and nut on the command shaft and tighten the nut to the recommended torque value. D) Install the slide valve control motor assem- bly with the four hex head bolts and Nord- Lock washers that hold the slide valve con- trol motor assembly to the motor plate.

  • Page 88: Potentiometer Installation

    Service C) Loosely install only one of the two mounting ® screws and its set of Nord-Lock washers. Connect the wires to the potentiometer. Red potentiometer lead goes to the white wire, purple potentiometer lead goes to the red wire and brown potentiometer lead goes to the black wire.

  • Page 89: And O-Ring Seal

    Service ® Lock washers (477) securing it. Tighten the B) Remove the hex head cap screws (452) from bolts to the recommended torque value. the cover (418) for the slide valve control C) Install the drive key (427) in the command motor, and remove cover.

  • Page 90: Command Shaft Bearing And O-Ring Seal Reassembly

    Service align roll pin holes. Drive in roll pins. D) The command shaft bearing (435) is a press E) Install the command shaft assembly with a fit on the command shaft (413). Remove the new o-ring (446) on the manifold. Make sure command shaft bearing with a suitable press.

  • Page 91: Liquid Injection Plug Replacment

    Service 5.00 LIQUID INJECTION PLUG 5.02 INSTALLATION OF PLUG REPLACMENT A) Apply refrigerant grade thread sealant to the A) Electrically lock out and tag out the screw threads of the replacement plug. Install plug compressor package. into compressor frame. B) Isolate the screw compressor package B) Rotate the compressor input shaft by hand from the package.

  • Page 92: Plug Applicability

    Service TABLE 5.1 VSS AND VSR LIQUID INJECTION PLUG APPLICABILITY COMPRESSOR MODEL VSR 111/211 NONE VSR 151/301 25905BC VSS 451 25905BB VSS 451E NONE VSS 601 25905BA VSS 601E 25905BA VSS 751 25905CB VSS 751E 25905CB VSS 901 25905CA VSS 901E 25905CA VSS 1051 25905DB...

  • Page 93: Torque Specifications

    Service Torque Specifications HEAD OUTSIDE DIAMETER OF BOLT SHANK 1 / 4 " 5 / 16 " 3 / 8 " 7 / 16 " 1 / 2 " 9 / 16 " 5 / 8 " 3 / 4 " TYPE BOLT MARKINGS SAE GRADE 2...

  • Page 94: Oil Filter Elements

    OIL FILTER ELEMENTS The following is a description of the oil filter elements supplied on standard VSS, VSR and VSM single screw compressor units 6.01 1833C FILTER ELEMENTS Vilter Part Number 1833C Usage VSS451 to VSS 1801 Dates All units...
  • Page 95 Service 6.02 KT 721 FILTER ELEMENTS Vilter Part Number KT 721 Tank O-Ring 2176BU Usage VSR Compres- sors Dates 1992 to 8-1-96 Length 8” A) Characteristics; 1) Pleated type element with a screen cov- ering the surface of the element.
  • Page 96 Service 6.04 KT 773A & B FILTER ELEMENTS Vilter Part KT 773A KT 773B Number Tank O-Ring 2176BY 2176BZ Usage 3109A 3111A Duplex Simplex Housing Housing Usage VSM all models 4/1/00 to present. VSS 451 to 1201 models with 30” and smaller oil separators 3/...
  • Page 97 Service 6.05 KT 774 FILTER ELEMENTS Vilter Part KT 774 Number Tank O-Ring 2176BY Usage 3112A 3110A Simplex Duplex Housings Housings 1. VSS 1501 & 1801 3-1-00 to present. 2. All other VSS models with 30” and larger oil separators 3/1/00 to present.

  • Page 98: Vss, Vsm And Vsr Single Screw Compressors Service Interval Requirements

    VSS, VSM and VSR SINGLE SCREW COMPRESSORS SERVICE INTERVAL REQUIREMENTS FOR VILTER EXTENDED WARRANTY The following service intervals are based on the usage of Vilter Manufacturing Corporation Premium Grade refrigeration oil in VSS, VSM and VSR Single Screw Compressor units. Inspection...

  • Page 99: Recommended Spare Parts List

    Recommended Spare Parts List...

  • Page 103: Vss And Vsr Replacement Parts Section

    VSS and VSR Replacement Parts Section VSS and VSR Replacement Parts Section ..............Gate Rotor ...................................... 104 Shaft Seal ....................................... 108 Main Rotor ..................................... 110 Slide Valve Cross Shafts and End Plate ............................114 Slide Valve Cross Shafts Prior to 5-1-95 ............................ 115 Slide Valve Carriage Assembly ..............................

  • Page 104: Gate Rotor

    Gate Rotor...
  • Page 105 Gate Rotor MODEL NUMBER ITEM DESCRIPTION VSR 111 & VSR 221 VSR 151 & VSR 301 VSS 451 VSS 601 GATE ROTOR BLADE AND BEARING REPLACEMENT KIT, 111, 118, 120A, 120B, 121, 122, 123, 124, 125, 126, 130, 131, 141, 142 & 143. KT712A KT712B KT712A...
  • Page 106 Gate Rotor ITEM DESCRIPTION VSG 751 VSG 901 VSG 1051 VSG 1201 GATE ROTOR BLADE AND BEARING REPLACEMENT KIT, 111, 118, 120A, 120B, 121, 122, 123, 124, 125, 126, 130, 131, 141, 142 & 143. KT712C KT712D KT712E KT712F GATE ROTOR BLADE REPLACEMENT KIT, 111, 118, 120A, 120B, 121, 122, 123, 124, 130, 141, 142 &...
  • Page 107 Gate Rotor ITEM DESCRIPTION VSG 1501 VSG1801 GATE ROTOR BLADE AND BEARING REPLACEMENT KIT, 111, 118, 120A, 120B, 121, 122, 123, 124, 125, 126, 130, 131, 141, 142 & 143. KT712G KT712H GATE ROTOR BLADE REPLACEMENT KIT, 111, 118, 120A, 120B, 121, 122, 123, 124, 130, 141, 142 &...

  • Page 108: Shaft Seal

    Shaft Seal Shaft Seal With Stationary Carbon Face Important: Item # 244- Tappered ID Faces Outward. Shaft Seal Baffle Assemmbly...
  • Page 109 Shaft Seal MODEL NUMBER ITEM DESCRIPTION VSR 111 & VSR 151& VSS 751-1201 VSS 1501-1801 VSR 221 VSR 301 VSS 451 VSS 601 KT709A KT709A KT709B KT709C SHAFT SEAL AMMO KIT; 219, 230 & 260 KT781A KT781A KT781B KT781C SHAFT SEAL HALO KIT 219,230 & 230 BAFFLE SHAFT SEAL 25931A 25931A...

  • Page 110: Main Rotor

    Main Rotor...
  • Page 111 & Parts List...
  • Page 112 Main Rotor...
  • Page 113 Main Rotor MODEL NUMBER ITEM DESCRIPTION VSR 111-221 VSR 151-301 PART # PART # MAIN ROTOR ASSY A25168BD A25168BC SHIM PACK A25173C A25173C SHIM PACK A25177B A25177B BAFFLE, SHAFT SEAL A25931A A25931A SEAL 25630A 25630A SUPPORT BEARING 25649B 25630A OUTER BEARING RET 25001C 25001C INNER BEARING RET...

  • Page 114: Slide Valve Cross Shafts And End Plate

    Slide Valve Cross Shafts and End Plate...

  • Page 115: Slide Valve Cross Shafts Prior To 5-1-95

    Slide Valve Cross Shafts and End Plate ITEM DESCRIPTION MODEL NUMBER VSR111-221 VSR 151-301 VSS 451 VSS 601 END PLATE 25530A 25530A 25530A 25530A SHAFT. 25843A 25843A 25843A 25843A GEAR. 25027A 25027A 25027A 25027A RACK CLAMP. 25913A 25913A 25913A 25913A RACK CLAMP.
  • Page 116 Slide Valve Cross Shafts and End Plate MODEL NUMBER ITEM DESCRIPTION VSS 751 VSS901 VSS 1051 VSS 1201 END PLATE 25543A 25543A 25593A 25593A SHAFT. 25844A 25844A 25845A 25845A GEAR. 25027A 25027A 25027A 25027A RACK CLAMP. 25913C 25913C 25913C 25913C SPACER.
  • Page 117 Slide Valve Cross Shafts and End Plate MODEL NUMBER ITEM DESCRIPTION VSS 1501 VSS1801 END PLATE 25661A 25661A SHAFT. 25793A 25793A GEAR. 25027A 25027A RACK CLAMP. 25913C 25913C SPACER. 25033C 25033C DOWEL PIN. 2868B 2868B EXPANSION PIN. 1193D 1193D EXPANSION PIN. 2981AA 2981AA PIPE PLUG.
  • Page 118 Slide Valve Carriage Assembly...
  • Page 119 Slide Valve Carriage Assembly MODEL NUMBER ITEM DESCRIPTION VSR 111-221 VSR 151-301 VSS 451 VSS601 CARRIAGE ASSEMBLY. A25179B A25179B A25179B A25179B CAPACITY PISTON 340, 341, 350 & 355. 1 A25183B A25183B A25183B A25183B VOLUME PISTON 340, 342, 350 & 355. 1 A25184B A25184B A25184B...

  • Page 120: Slide Valve Carriage Assembly

    Slide Valve Carriage Assembly MODEL NUMBER ITEM DESCRIPTION VSS 751 VSS901 VSS 1051 VSS 1201 CARRIAGE ASSEMBLY. A25179C A25179C A25179D A25179D CAPACITY PISTON 340, 341, 350 & 355. 2 A25183C A25183C A25183D A25183D VOLUME PISTON 340, 342, 350 & 355. 2 A25184C A25184C A25184D...
  • Page 121 Slide Valve Carriage Assembly MODEL NUMBER ITEM DESCRIPTION VSS 1501 VSS 1801 CARRIAGE ASSEMBLY. A25179E A25179E CAPACITY PISTON 340, 341, 350 & 355. 2 A25183E A25183E VOLUME PISTON 340, 342, 350 & 355. 2 A25184E A25184E GASKET SET 345 & 378. A25200E A25200E RACK.

  • Page 122: Capacity Control Actuating Motor And Command Shaft

    Capacity Control Actuating Motor and Command Shaft Note: Steel Bushing until 10/25/04 then modified housing New housing design starting 10/25/04 for all command shaft assemblies. Optical Actuator See note above...
  • Page 123 Capacity Control Actuating Motor and Command Shaft MODEL NUMBER ITEM DESCRIPTION VSR 111-221 VSR 151-301 VSS 451 VSS601 QTY VPN QTY VPN QTY VPN QTY VPN GEAR MOTOR REPLACEMENT (410, 440, 455, 475). KT720A KT720A KT720A KT720A GEAR MOTOR REPLACEMENT (DIV.
  • Page 124 Capacity Control Actuating Motor and Command Shaft MODEL NUMBER ITEM DESCRIPTION VSS 751 VSS 901 VSS 1051 VSS 1201 GEAR MOTOR REPLACEMENT (410, 440, 455, 475). KT720A KT720A KT720A KT720A GEAR MOTOR REPLACEMENT (DIV. 2) (410, 440, 455, 475). KT720B KT720B KT720B KT720B...
  • Page 125 Capacity Control Actuating Motor and Command Shaft MODEL NUMBER ITEM DESCRIPTION VSS 1501 VSS 1801 GEAR MOTOR REPLACEMENT (410, 440, 455, 475). KT720A KT720A GEAR MOTOR REPLACEMENT (DIV. 2) (410, 440, 455, 475). KT720B KT720B GEAR MOTOR. 25380A 25380A 410A GEAR MOTOR (DIV.

  • Page 126: Slide Valve Actuating Motor And Command Shaft Before 5-1-95

    Slide Valve Actuating Motor and Command shaft Before 5-1-95 2 O-RINGS ONLY IF SPECIFIED.
  • Page 127 Slide Valve Actuating Motor and Command shaft Before 5-1-95 MODEL NUMBER ITEM DESCRIPTION VSR 111-301 VSS 451-601 VSS 751-901 VSS 1201 GEAR MOTOR. MOUNTING BLOCK. MOTOR BRACKET. CLIP. COLLAR. LOCKING TAB. BEARING HOUSING. SHAFT. COUPLING. 25032A 25032A 25032A 25032A PLATE. GEAR.

  • Page 128: Volume Ratio Control Actuating Motor And Command Shaft

    Volume Ratio Control Actuating Motor and Command Shaft Note: Steel Bushing until 10/25/04 then modified housing New housing design starting 10/25/04 for all command shaft assemblies. Optical Actuator See Note above See page 122 for assembly...
  • Page 129 Volume Ratio Control Actuating Motor and Command Shaft MODEL NUMBER ITEM DESCRIPTION VSR 111-221 VSR 151-301 VSS 451 VSS 601 GEAR MOTOR REPLACEMENT (410, 440, 455, 475). KT720C KT720C KT720C KT720C GEAR MOTOR REPLACEMENT (DIV. 2) (410, 440, 455, 475). KT720D KT720D KT720D...
  • Page 130 Volume Ratio Control Actuating Motor and Command Shaft MODEL NUMBER ITEM DESCRIPTION VSS 751 VSS 901 VSS 1051 VSS 1201 GEAR MOTOR REPLACEMENT (410, 440, 455, 475). KT720C KT720C KT720C KT720C GEAR MOTOR REPLACEMENT (DIV. 2) (410, 440, 455, 475). KT720D KT720D KT720D...
  • Page 131 Volume Ratio Control Actuating Motor and Command Shaft MODEL NUMBER ITEM DESCRIPTION VSS 1501 VSS 1801 GEAR MOTOR REPLACEMENT (410, 440, 455, 475). KT720C KT720C GEAR MOTOR REPLACEMENT (DIV. 2) (410, 440, 455, 475). KT720D KT720D GEAR MOTOR. 25379A 25379A 410A GEAR MOTOR (DIV.

  • Page 132: Miscellaneous Frame Components

    Miscellaneous Frame Components Tubing and Fittings Gate Rotor Bearing Supply Lines VSR 111&VSR 301 VSS 451-VSS 1801 Seal Chamber Oil Line VSS 1501&VSS 1801 VSS 451&VSS1201 559 560 559 560 Slide Valve Piston Equalizing Lines VSS 451&VSS 601 VSS 751&VSS 901 VSS 1051&VSS1201...
  • Page 133 Miscellaneous Frame Components Tubing and Fittings MODEL NUMBER ITEM DESCRIPTION VSR 111-VSR 221 VSR 151-VSR 301 VSS 451 VSS 601 ELBOW . 13375D 13375D 13375D 13375D STRAIGHT. 13229D 13229D TEE, RUNNING. 1509A 1509A HEX BUSHING. 13231AA 13231AA 13231AA 13231AA ELBOW. 13375Z 13375Z ELBOW.

  • Page 134: Miscellaneous Frame Components

    Miscellaneous Frame Components VSR Mini Screw Compressor VSS Screw Compressor...
  • Page 135 Miscellaneous Frame Components MODEL NUMBER ITEM DESCRIPTION VSR 111-221 VSR 151-301 VSS 451 VSS601 GASKET AND O-RING KIT; KT710A KT710A FLANGE SET 513, 514 & 547A. A25190A A25190A A25190A A25190A ECON-O-MIZER PORT. A25190B A25190B ECON-O-MIZER PLUG. A25243BD A25243BC DISCHARGE MANIFOLD. 25634A 25634A 25502A...
  • Page 136 Miscellaneous Frame Components MODEL NUMBER ITEM DESCRIPTION VSS 751 VSS901 VSS 1051 VSS 1201 GASKET AND O-RING KIT; KT710B KT710B KT710C KT710C FLANGE SET 513, 514 & 547. A25190A A25190A A25190B A25190B FLANGE SET 513A, 514A & 547 ECON-O-MIZER PORT. A25190B A25190B A25190B...
  • Page 137 Miscellaneous Frame Components MODEL NUMBER ITEM DESCRIPTION VSS 1501 VSS 1801 GASKET AND O-RING KIT; KT710D KT710D FLANGE SET 513, 514 & 547. A25190C A25190C FLANGE SET 513A, 514A & 547 ECON-O-MIZER PORT. A25190D A25190D DISCHARGE MANIFOLD. 25663A 25663A MANIFOLD GASKET. 25676A 25676A FLANGE OIL.

  • Page 138: C-Flange Adapter Components

    C-Flange Adapter Components...
  • Page 139 C-Flange Adapter Components MODEL NUMBER ITEM DESCRIPTION VSR 111 & VSR 221 VSR 151 & VSR 301 C-FLANGE ADAPTER. KEY. 25039AA 25039AA HEX HEAD CAP SCREW. 2796C 2796C LOCKWASHER (PAIR). 3004H 3004H CONNECTOR. 13229C 13229C TUBE 1/4" O.D. x 6" LONG. 0.5 Ft.

  • Page 140: Replacement Parts Tools

    Replacement Parts Tools...
  • Page 141 Replacement Parts Tools MODEL NUMBER ITEM DESCRIPTION VSR 111-221 VSR 151-301 VSS 451 VSS 601 GATEROTOR TOOLS (901, 910, 911, 912, 913, 914, 915, 916 & 917). A25205B A25205B A25205B A25205B GATEROTOR STABILIZER SET (901A, 901B & 901C). A25698A A25698A A25698A A25698A 901A...
  • Page 142 Replacement Parts Tools MODEL NUMBER ITEM DESCRIPTION VSS 1501 VSS 1801 GATEROTOR TOOLS (901, 910, 911, 912, 913, 914, 915, 916 & 917). A25205E A25205E GATEROTOR STABILIZER SET ( 901A, 901B, 901C & 901D). A25699A A25699A 901A GATEROTOR STABILIZER. A25699B A25699B 901B HEX HEAD CAP SCREW.

  • Page 143: Vsm Replacement Parts Section

    VSM Replacement Parts Section VSM Replacement Parts Section ................Gaterotor Assembly ..................................144 Shaft Seal ....................................... 147 Main Rotor, Slide Valve Cross Shafts and End Plate (Models 71-401) ..................148 Main Rotor, Slide Valve Cross Shafts and End Plate (Models 501-701 ..................152 Slide Valve Carriage Assembly ..............................

  • Page 144: Gaterotor Assembly

    Gaterotor Assembly...
  • Page 145 Gaterotor Assembly Part totals indicated are for one gate rotor assembly, machines with two gate rotors will require double the components listed below. MODEL NUMBER ITEM DESCRIPTION VSM-71, 151, 301 VSM-91, 181, 361 VSM-101, 201, 401 SUPPORT ASSEMBLY 110 & 135B. A25222AB 1 A25222AA 1 A25222AC...
  • Page 146 Gaterotor Assembly Part totals indicated are for one gate rotor assembly, dual gate machines will require double the components. MODEL NUMBER ITEM DESCRIPTION VSM-501 VSM-601 VSM-701 SUPPORT ASSEMBLY 110 & 135B. A26011BB A26011BA A26011BA GATE ROTOR & DAMPER ASSEMBLY 111,120. A26002BB A26002BA 1 A26002BC...

  • Page 147: Shaft Seal

    Shaft Seal MODEL NUMBER ITEM DESCRIPTION ALL VSM 71- 401 ALL VSM 501-701 SHAFT SEAL KIT Ammon Kit KT709D KT709A 219, 230, & 260. SHAFT SEAL KIT Halo Kit KT781D KT781A 219, 230 & 260. SEAL HOUSING. 25410B 25269A SHAFT SEAL. OIL SEAL.

  • Page 148: Main Rotor, Slide Valve Cross Shafts And End Plate (Models 71-401)

    Main Rotor, Slide Valve Cross Shafts and End Plate (Models 71-401 Only Counter-clockwise)
  • Page 149 Main Rotor, Slide Valve Cross Shafts and End Plate (Models 71-201 Only CounterClockwise) MODEL NUMBER ITEM DESCRIPTION VSM 71 AND 151 VSM 91 AND 181 VSM 101 AND 201 MAIN ROTOR ASSEMBLY. A25266AB 1 A25266AA 1 A25266AC OIL BAFFLE ASSEMBLY (1) 217, (1) 244, (1) 248, (1) 249, (1) 252.
  • Page 150 Main Rotor, Slide Valve Cross Shafts and End Plate (Models 301-401 Only Counter-clockwise) MODEL NUMBER ITEM DESCRIPTION VSM 301 VSM 361 VSM 401 MAIN ROTOR ASSEMBLY. A25226AB 1 A25226AA 1 A25226AC OIL BAFFLE ASSEMBLY (1) 217, (1) 244, (1) 248, (1) 249, (1) 252. A25942AA 1 A25942AA 1 A25942AA...
  • Page 151 See Next Page for Models 501-701 Main Rotor, Slide Valve Cross Shafts and End Plate Parts List...

  • Page 152: Main Rotor, Slide Valve Cross Shafts And End Plate

    Main Rotor, Slide Valve Cross Shafts and End Plate (Model 501-701 Only Clockwise)
  • Page 153 Main Rotor, Slide Valve Cross Shafts and End Plate (Model 501-701 Only Clockwise) MODEL NUMBER ITEM DESCRIPTION VSM 501 VSM 601 VSM 701 MAIN ROTOR ASSEMBLY. A26010BB 1 A26010BA 1 A26010BC OIL BAFFLE ASSEMBLY (1) 217, (1) 244, (1) 248, (1) 249, (1) 252. A26034B A26034B A26034B...

  • Page 154: Slide Valve Carriage Assembly

    Slide Valve Carriage Assembly...
  • Page 155 Slide Valve Carriage Assembly MODEL NUMBER ITEM DESCRIPTION ALL VSM 71 - 401 ALL VSM 501 - 701 CARRIAGE ASSEMBLY. A25179A A26012B CAPACITY PISTON 340, 341, 350 & 355. 1 A25183A A25183B VOLUME PISTON 340, 342, 350 & 355. 1 A25184A A25184B CAPACITY RACK.

  • Page 156: Actuating Motor With Optical Sensor And Command Shaft

    Actuating Motor with Optical Sensor and Command Shaft Kit assemblies are as follows: A25975A VSM71-401 A25975B VSM 501-701...
  • Page 157 Actuating Motor with Optical Sensor and Command Shaft MODEL NUMBER ITEM DESCRIPTION ALL VSM 71 - 401 ALL VSM 501- 701 BEARING HOUSING. 25364A 25364A COMMAND SHAFT. 25417A 25375A MOUNTING PLATE. 25805B 25805B COVER. 15653E 15653E KEY. 25039BC 25039BC BUSHING. 25853A 25853A BALL BEARING.

  • Page 158: Miscellaneous Frame Components

    Miscellaneous Frame Components Model VSM 71-401 Model VSM 501-701...
  • Page 159 Miscellaneous Frame Components MODEL NUMBER ITEM DESCRIPTION ALL VSM 71-401 ALL VSM 501 - 701 DISCHARGE MANIFOLD. 25734B 240 mm DISCHARGE MANIFOLD WITH DOWN DISCHARGE. 25024BC 240 mm DISCHARGE MANIFOLD WITH HORIZONTAL DISCHARGE. 25024BB 240 mm DISCHARGE MANIFOLD WITH UP DISCHARGE. 25024BA MANIFOLD GASKET.

  • Page 160: Replacement Parts Accessories

    Replacement Parts Accessories...
  • Page 161 Replacement Parts Accessories Housing Accessories MODEL NUMBER ITEM DESCRIPTION VSM 71 - 701 GATE ROTOR COVER. 25416B COVER GASKET. 25259B SUCTION TEE. 25735B BLIND FLANGE WITH TAP. 25967A GASKET. 11323T HEX HEAD CAP SCREW. 2796DC HEX HEAD CAP SCREW. 1139BE LOCKWASHER (PAIR).

  • Page 162: Replacement Tools

    Replacement Tools MODEL NUMBER ITEM DESCRIPTION ALL VSM 71 - 401 ALL VSM 501 - 701 GATEROTOR STABILIZER. 25742A 25742B SEAL INSTALLATION TOOL 25455A 25455B...

  • Page 163: Vendor Assessories Section

    CARTRIDGE HEATERS ..................................... SPORLAN Strainers ....................................VIKING PUMP Pumps and Pressure Relief Valves ..........................FLUID POWER ENERGY Thermostatic Valves ............................. SPORLAN Solenoid Valve and Thermostatic Expansion Valve ......................HANSEN HA4AOAS INLET/OUTLET REGULATOR ..........................Note: See spare parts lists for Vilter’s Part numbers.
  • Page 164 Haight Pumps 10-80 GPM OIL PUMPS face of the seal will need to be inspected for crack- VILTER PART NUMBER ing or excessive wear. If they are damaged the seal 3022UB, EU and HU must be replaced at this time.
  • Page 165 When placing an order for a new pump and had the “D” (old) series pump you will be required to upgrade to an “U” and a new Hub will also need to be purchased. Vilter Part # 3022BU ,EU,and HU Vilter Shaft Seal Part # 3022C...
  • Page 166 Haight Pumps...
  • Page 167 10U through 40U Haight Pump w/o Relief Valve 10U through 40U Haight Pump with Relief Valve Item Qty. Item Qty. Number Description Required Number Description Required Shaft Screw on O-ring gland O-Ring -Buna Rotor -C.I. Standard -Viton® Case -Neoprene -1" ports -Kalrez®...
  • Page 168 CHECK VALVE BULLETIN 50-16C Type CK4A Port Size 13 - 100mm (1/2” - 4”) FOR AMMONIA, R12, R22, R502 AND OTHER COMMON REFRIGERANTS FEATURES • UL Listed (Thru 3" Size) September 1990 • Installs in any position Installation, Service and Parts Information •...
  • Page 169 Repair Kits for Type CK4A Check Valves PORT SIZE T SIZE T SIZE T SIZE T SIZE ITEM ITEM ITEM ITEM ITEM DESCRIPTION DESCRIPTION 50mm (2") 50mm (2") 65mm (2-1/2") 65mm (2-1/2") 75mm (3") 75mm (3") 100mm (4") 100mm (4") DESCRIPTION DESCRIPTION DESCRIPTION...
  • Page 170 Refrigerating Specialties Division...
  • Page 171 Service factory. Warranty does not cover products which have been altered, or repaired in the field; damaged in transit, or have Dirt or other foreign material in the system is the greatest suffered accidents, misuse, or abuse. Products disabled by single cause of valve malfunction.
  • Page 172 INLET PRESSURE BULLETIN 23-05B Type A4A, A4AK, A4AE, A4AR REGULATORS Type A4A, A4AK, A4AE, A4AR Port Size 20 - 100 mm (3/4" - 4") FOR AMMONIA, R-12, R-22, R-502 OTHER REFRIGERANTS AND OIL FEATURES • Pilot operated characterized Modulating Plug for precise control •...
  • Page 173 The A4A Series of Regulators will give optimum Principles of Operation (See Fig. 1) performance if mounted in a horizontal line in a vertical The inlet pressure enters the space under the diaphragm position with the manual opening stem on bottom. Where through passage N.
  • Page 174 Disassembly - Take care when removing Seal Caps 1 Remove seat from valve body and clean, lap on a flat and 44 in case some refrigerant may be trapped inside. plate or replace as necessary. Examine the diaphragm Back the Adjusting Stem 6 all the way out to remove any region which contacts the seat surface, look for dirt, heavy pressure from Range Spring 13 otherwise damage to scratches or corrosion.
  • Page 175 Repair Kits for A4A, A4AE, A4AK and A4AR 20mm (3/4") 25mm (1 “) Item No. Description Kit No. Kit No. Seal Cap Only Avail. with Kit Only Avail with Kit Seal Cap Gasket Only Avail with Kit Only Avail. with Kit Cap Kit, Seal 202110 202110...
  • Page 176 Repair Kits for A4A, A4AE, A4AK and A4AR 32mm (1-1/4") 40mm (1-5/8") 50mm (2") 65mm (2-1/2") 75mm (3") 100mm (4") Item No. Kit No. Kit No. Kit No. Kit No. Kit No. Kit No. Only Avail. with Kit Only Avail. with Kit Only Avail.
  • Page 177 Repair Kits for A4A, A4AE, A4AK and A4AR 20mm (3/4") 25mm (1") Item No. Description Kit No. Kit No. O-Ring/Gasket Only Avail. with Kit Only Avail. with Kit Cover, Bottom Only Avail. with Kit Only Avail with Kit Washer, Flat Only Avail.
  • Page 178 Repair Kits for A4A, A4AE, A4AK and A4AR 32mm (1-1/4") 40mm (1-5/8") 50mm (2") 65mm (2-1/2") 75mm (31) 100mm (4") Item No. Kit No. Kit No. Kit No. Kit No. Kit No. Kit No. Only Avail. with Kit Only Avail. with Kit Only Avail.
  • Page 179 A4AK Reseating Relief Regulator strainers are used, maintain according to instructions in Bulletin 00-10. Moisture in halocarbon systems in This regulator is adjusted at the factory for a given inlet particular can cause corrosion or form ice, causing the pressure. The seal cap is wired to a bonnet cap screw piston to freeze in position.
  • Page 180 SERVICE POINTERS (Check General Procedure) SYMPTOM PROBABLE REASON CORRECTION Regulator does not Diaphragm or seat dirty, damaged or frozen. Clean or replace. Clean strainer. shut off flow. Diaphragm follower stuck or damaged. Clean or replace. Install follower carefully. Piston jammed with excess dirt. Remove and polish piston and bore with crocus cloth.
  • Page 181 Allow 25mm (1”) below valve to operate manual opening stem. A4A, A4AE Fig. 3 PIPING AND LAYOUT FOR STANDARD A4A BACK PRESSURE REGULATOR PORT SOCKET (E) WELD (F) PIPE F.P.T. (D) WELD NECK SIZE INCHES INCHES INCHES SIZE INCHES INCHES INCHES ¾”...
  • Page 182 Allow 25mm (1”) below valve to operate manual opening stem. A4AR Fig. 4 PIPING AND LAYOUT FOR STANDARD A4A BACK PRESSURE REGULATOR PORT SOLDER O.D. SOLDER (G) TUBE O.D.S. SIZE INCHES INCHES INCHES INCHES INCHES INCHES INCHES ¾" 28.57 1-1/8" 11.3"...
  • Page 183 FLANGES À Ã VALVE FPT FLANGES WELDING FLANGES FLANGES SIZE Nominal Sock Weld Weld Neck Flange Package Tubing Fitting Nom. Flange Pipe Size Sock t I.D. Neck O.D. Number(2/Pkg) O.D. I.D. Flge Pkg. Pipe Size Pkg. No. Socket Weld No. (2/Pkg) Á...
  • Page 184 C A R T R I D G E H E A T E R S Hi-Temp Cartridge heaters are designed for optimum performance above and beyond the norm. ®...
  • Page 185 CARTRIDGE HEATERS HI-TEMP OPEN AIR TEST WATT DENSITY CALCULATIONS: The subtraction of ” from the overall length in the above equations is a general This test was conducted using a ” dia. x 6” Watt density of a Hi-Temp Cartridge is allowance for the watt density calculations (15.8 mm x 152 mm) long, 750 watt 240 volt simply the total heater wattage divided by...
  • Page 186 STANDARD CARTRIDGE HEATERS STANDARD CARTRIDGES MATERIAL AND CONSTRUCTION • U.L. approved and C.S.A. certified flexible nickel conductor with fiberglass insulated Our Standard Cartridge heaters are • Computer designed specifications. lead wire 482º F, (250º C) is standard. designed as an economical, quality heater •...
  • Page 187 STANDARD CARTRIDGE HEATERS SPECIFICATIONS DIAMETER TOLERANCE There may be applications where, due to the wattage requirement, it would be Wattage Tolerances: +5% – 10% based on ENGLISH SIZES METRIC EQUIVALENT appropriate to specify a Standard Cartridge Nema standards. ” (0.1875) = .183 ± .001 4.6 mm ±...
  • Page 188 HI-TEMP/STANDARD CARTRIDGE HEATERS FLEXIBLE LEADS Internally connected leads. Hi-Temp For applications requiring maximum Overall length flexibility at lead exit. 10” (25.4 cm) leads standard, other lengths are available. Standard EXTERNALLY CONNECTED LEADS Hi-Temp Cartridges are provided with approx. 1” (25.4 mm) sleeving over lead Hi-Temp Overall length junction as standard.
  • Page 189 HI-TEMP/STANDARD CARTRIDGE HEATERS STRAIGHT STRAIN RELIEF SPRING Straight strain relief spring minimizes bending strain on lead wires. Hi-Temp Overall length Spring extends approximately 3” (76.2 mm) beyond end of sheath. Standard BRAID OVER PAIR OF LEADS Stainless steel braid over lead wires. For applications requiring small radius Hi-Temp Overall length...
  • Page 190 HI-TEMP/STANDARD CARTRIDGE HEATERS N.P.T. BUSHING Hex head N.P.T. bushing attached. Must specify insert length and bushing Hi-Temp Insert length material. Sheath material types: stainless steel, cold rolled or galvanized. Bushing material types: brass, stainless steel or steel. 10” (25.4 cm) leads standard, other lengths are available.
  • Page 191 HI-TEMP/STANDARD CARTRIDGE HEATERS ARMOR WITH PLUG Armor cable with power plug attached. Must specify armor length and Hubbell® Insert length Hi-Temp power plug number. Moisture-resistant armor available. Other Plugs are available, contact Fast Heat or see page 26 of our QuickShip catalog. Armor length Standard BUSHING, ARMOR AND PLUG...
  • Page 192 HI-TEMP/STANDARD CARTRIDGE HEATERS RIGHT ANGLE ELBOW Hi-Temp Right angle copper elbow for applications requiring right angle lead exit. Insert length Moisture-resistant seal is optional. 10” (25.4 cm) leads standard, other lengths are available. Both Hi-Temp and Standard Cartridges are also available with stainless steel braid over the leads (See Standard at left).
  • Page 193 HI-TEMP/STANDARD CARTRIDGE HEATERS 90º LEADS W/CLIP Hi-Temp Clip support helps to minimize lead breakage where leads exit heater. Insert length 10” (25.4 cm) leads standard, other lengths are available. Standard 90º LEADS Hi-Temp Leads exit at 90º angle for applications requiring small radius bends, lead wire protection and where space is limited.
  • Page 194 HI-TEMP/STANDARD CARTRIDGE HEATERS SCREW TERMINALS Screw terminals for applications with high Hi-Temp amps and requiring universal connection capability. Screw terminals are attached to Overall length 1“ external pins. Standard Cartridge 10-32 screw terminal on ⁄ ” to ⁄ ” (9.5 mm - 23.8 mm) dia. Hi-Temp ⁄...
  • Page 195 THERMOCOUPLE LOCATION CARTRIDGE HEATERS T/C AT BOTTOM BOTTOM GROUNDED For fast response, heater is positioned in a blind hole or where material flows past or encompasses the heater. The end disk is always welded in place. Machined flat up to ⁄...
  • Page 196 SQUARE CARTRIDGE HEATERS FLEXIBLE LEADS Internally connected leads. For applications requiring maximum flexibility at lead exit. Overall length 10” (25.4 cm) leads standard, other lengths are available. BRAID Stainless steel braid over lead wires. For applications requiring small radius bending and lead wire abrasion protection. Overall length 10”...
  • Page 197 SQUARE CARTRIDGE HEATERS STRAIGHT CLIP SUPPORT Clip support helps to minimize lead breakage where leads exit heater. 10” (25.4 cm) leads standard, other lengths Overall length are available. 90º CLIP SUPPORT Clip support helps to minimize lead breakage where leads exit heater. 10”...
  • Page 198 CARTRIDGE HEATERS PRECISION STANDARD SQUARE APPLICATIONS APPLICATION FOR SELECTION OF CARTRIDGE HEATERS CARTRIDGE HEATERS IN PLATENS Square Cartridge heaters can be used in Our Square Cartridge heaters, ” (9.5 mm), virtually any application involving average Whether round or square cartridges are ”...
  • Page 199 HI-TEMP/STANDARD CARTRIDGE IMMERSION HEATERS CARTRIDGE IMMERSION HEATER SPECIFICATIONS Attention must be given to selecting the proper watts per square inch for the Immersion cartridge heaters may be TOLERANCES: material to be heated. Refer to the watt selected when a tubular style heater may density chart on page 150.
  • Page 200 HI-TEMP/STANDARD CARTRIDGE IMMERSION HEATERS ” (15.9 MM) DIA. OIL/WATER FIBERGLASS LEADS ⁄ " (15.9 mm) dia. 10" (25.4 cm) fiberglass leads inside Insert Length octagonal terminal box. ⁄ " (12.7 mm) N. P. T. brass bushing. ” (19.1 MM) DIA. OIL/WATER FIBERGLASS LEADS ⁄...
  • Page 201 STOP / STRAINER VALVE BULLETIN 86-00 Port Size 13-100mm (1/2”- 4”) FOR AMMONIA, R12, R22, R502 AND OTHER COMMON REFRIGERANTS FEATURES • Handwheel or Seal Cap • Replaceable PTFE seat disc • Full-ported angular seat allows washing action • Positive shut-off •...
  • Page 202 SPARE PARTS ITEM DESCRIPTION PORT SIZE 1/2 & 3/4 * 1/2 & 3/4 1-1/4 1-1/2 2-1/2 20-24 Handwheel 204268 204268 204268 204268 204269 204269 204269 204269 204270 Seal Cap 204273 204273 204273 204273 204274 204274 204274 204274 204275 10-13 Packing Kit 204471 204471 204471...
  • Page 203 June 2000 / BULLETIN 50-10 TYPE 6000 SERIES STRAINERS TYPE 8000 SERIES REFRIGERANTS / BRINE / WATER / OIL All cleanable strainers have an access for easy re- moval of the screen assembly. This facilitates clean- TYPE XD ing and inspection, without breaking the line con- nections.
  • Page 204 Page 2 / Bulletin 50-10 SPECIAL PURPOSE STRAINER TYPE XD STRAINER is for use with Ammonia and other liquids where a steel construction is suitable. May be used with companion flange or can be bolted di- rectly to Type D Thermostatic Expansion Valves and Type MA5A3 Solenoid Valves.

  • Page 205: Introduction

    Bulletin C401d March, 2002 HANSEN TECHNOLOGIES CORPORATION Specifications, Applications, Service Instructions & Parts HCK4 IN-LINE CHECK VALVES " thru 4" PORT (16 thru 100 mm) Flanged " thru 4" FPT, SW, WN, ODS for refrigerants HCK4-4 Check Valve INTRODUCTION KEY FEATURES The HCK4 series of dependable, compact, rugged in-line check valves (disc type non-return valves) is ideally suited for refrigerant flow control applications.
  • Page 206 MATERIAL SPECIFICATIONS INSTALLATION Body: Valve may be located in any position. Arrow on " thru 1¼": Steel, ASTM A108, zinc chromate valve body should match direction of flow. Secure plated valve with gaskets between flanges and tighten 1½" thru 4": Ductile iron, ASTM A536, zinc bolts evenly.
  • Page 207 PARTS LIST HCK4-2 (2-BOLT) HCK4-2 (2-BOLT) Above Kit Consists of: Seat Disc 72-0069 Closing Spring 72-0070 Seat Cartridge 72-0068 Seat Cartridge O-ring 72-0071 Flange Gasket 70-0065 Body, HCK4-2 72-0067 " - 14 x 3.25") Bolt 70-0225 " - 14) 70-0055 Flange (FPT, SW, WN, ODS) FACTORY Socket weld shown.
  • Page 208 OPERATION WARRANTY HCK4 check valves are normally closed valves. As Hansen valves are guaranteed against defective inlet pressure increases, it overcomes the closing materials or workmanship for one year F.O.B. our spring force. As the seat disc is pushed back and plant.
  • Page 209 TECHNICAL SERVICE MANUAL SECTION TSM 144 HEAVY DUTY PUMPS PAGE 1 OF 9 SERIES 4195 and 495 ISSUE SERIES GG - AL CONTENTS Introduction Special Information Special Mechanical Seals Maintenance Disassembly Assembly Thrust Bearing Adjustment Installation of Carbon Graphite Bushings FIGURE 1 GG.

  • Page 210: Maintenance

    SPECIAL MECHANICAL SEALS SPECIAL INFORMATION This bulletin illustrates the mechanical seal which is standard in the catalog pump. A Seal Installation DANGER Drawing will be furnished with a pump fitted with a non- standard mechanical seal. Consult this Seal Installation BEFORE OPENING ANY VIKING PUMP LIQUID Drawing before disassembling pump.

  • Page 211: Disassembly

    1. Refer to figures 7 & 8 page 4 for model to be DISASSEMBLY disassembled and name of parts. Models 4195 & 495 are disassembled and assembled the same. The difference between these models is the casings. DANGER 2. Mark head and casing before disassembly to insure BEFORE OPENING ANY VIKING PUMP LIQUID proper reassembly.
  • Page 212 Modifications to pump casing and rotor are required for installation of optional Teflon® Mechanical Seal. Consult the factory. FIGURE 7 – EXPLODED VIEW MODELS GG, HJ and HL 4195 and 495 ITEM NAME OF PART ITEM NAME OF PART ITEM NAME OF PART ITEM NAME OF PART...
  • Page 213 INNER BALL BEARING BALL BEARING INNER SNAP RING OUTER SNAP RING LOCKNUT SHAFT SHAFT SNAP RING BEARING HOUSING BALL BEARING FIGURE 9 – THRUST BEARING ASSEMBLY GG, HJ and HL SIZES BEARING RETAINER WASHER BALL BEARING INNER BALL BEARING SETSCREW NYLON INSERT END CAP LIP SEAL...

  • Page 214: Assembly

    SPRING The casing should be examined for wear, particularly in the MECHANICAL SEAL (ROTARY MEMBER) area between ports. All parts should be checked for wear before pump is put together. When making major repairs, such as replacing a rotor and shaft;...

  • Page 215: Thrust Bearing Adjustment

    THRUST BEARING ADJUSTMENT 12. Pack inner ball bearing with multi-purpose grease, NLGI #2. See Figures 9 and 10. GG, HJ, HL: Install bearing in casing with sealed side Loosen two screws in face of thrust bearing assembly. towards head end of pump. Drive the bearing into the bore.
  • Page 216 PRESSURE RELIEF VALVE DISASSEMBLY INSTRUCTIONS DANGER BEFORE OPENING ANY VIKING PUMP LIQUID CHAMBER (PUMPING CHAMBER, RESERVOIR, RELIEF VALVE ADJUSTING CAP FITTING ETC.) BE SURE: 1. THAT ANY PRESSURE IN CHAMBER BEEN COMPLETELY VENTED THROUGH SUCTION OR DISCHARGE LINES OTHER APPROPRIATE OPENINGS OR CONNECTIONS.
  • Page 217 TECHNICAL SERVICE MANUAL SECTION TSM144 HEAVY DUTY PUMPS PAGE 9 OF 9 SERIES 4195 and 495 ISSUE SERIES GG - AL DANGER BEFORE STARTING PUMP, BE SURE ALL DRIVE EQUIPMENT GUARDS ARE IN PLACE. FAILURE TO PROPERLY MOUNT GUARDS WARRANTY MAY RESULT IN SERIOUS INJURY OR DEATH.
  • Page 218 Model 2010 Three-Way Thermostatic Valve 2010 2” NPT 2010-1 1 1/2” NPT 2010J24 1 1/2” SAE O-Ring A2010J32 2” SAE O-Ring F2010 2” 125# FF Flange SF2010 2” 150# RF Flange SF2010X 2” 300# RF Flange Fluid Power Energy (FPE) Thermostatic Valves utilize the principle of Features expanding wax, which in the semi-liquid state undergoes large expansion rates within a relatively narrow temperature range.
  • Page 219 Model 2010 * (Replace * with body material type; A=Cast Iron, B=Bronze, D=Ductile, S=Steel, SS=Stainless Steel) PRESSURE RATINGS MATERIAL A, B S, SS SF, SSF SFX, SSFX *2010-1, *2010, *2010J *F2010, *F2010X PART # DESCRIPTION Flow vs. Pressure Drop *2010 VALVE BODY (*See table for material) 1 1/2”...
  • Page 220 August 2003 / BULLETIN 30-11 SOLENOID VALVES I n s t a l l a t i o n a n d S e r v i c i n g I n s t r u c t i o n s N O T F O R U S E O N H A Z A R D O U S O R C O R R O S I V E F L U I D S ■...
  • Page 221 Page 2 / BULLETIN 30-11 RECOMMENDED TORQUE (ft.–lbs.) 1 1 1 1 1 5 5 5 5 5 3 3 3 3 3 3 3 3 3 3 - - - - - - - - - - - - - - - - - - - - -...
  • Page 222 BULLETIN 30-11 / Page 3 Wiring — Check the electrical specifications of the coil to be sure operating conditions are such that the reduced MOPD causes they correspond to the available electrical service. stalling of the plunger, which results in excessive current draw. 4.
  • Page 223 Page 4 / BULLETIN 30-11 Screw Lock Nut (normally Enclosing Tube Screw ■ Figure 5 ■ Figure 5a open & rapid cycle) (normally Assembly closed) Spacer Cup (normally open & Typical View of B6, E6,W6, B9, Nameplate rapid cycle only) E9, OB9, OE9, B10, E10, OB10, OE10, B14, E14, W14, OB14, OE14, B19, E19, W19, OB19,...
  • Page 224 October 2003 / BULLETIN 10-11 Thermostatic Expansion Valves Installation, Field Service, and Assembly See Bulletin 20-10 for application and selection information on Table of Contents refrigerant distributors. Installation While not always convenient or possible, valve Types BI, F, FB, and O are easier to service if mounted in a vertical and upright position.
  • Page 225 Page 2 / BULLETIN 10-11 Liquid subcooling is provided by the following methods: 1. In the condenser 2. Suction – liquid heat exchanger 3. Special devices Method 1 – will provide sufficient subcooling for the simple short- coupled system that has only moderate liquid line pressure drop. Method 2 –...
  • Page 226 BULLETIN 10-11 / Page 3 insures individual control for each valve without the influence of refrigerant and oil flow from other evaporators. Compressor ABOVE For recommended suction line piping when the compressor is located below the evaporator see Figure 5. The vertical riser extending to the Evaporator height of the evaporator prevents refrigerant from draining by gravity into the compressor during the off-cycle.
  • Page 227 Page 4 / BULLETIN 10-11 Test Pressures and Dehydration External Equalizer Temperatures Connection Inert dry gases such as nitrogen, helium or CO 2 are often used for leak detection. CAUTION: Inert gases must be added to the system carefully through a pressure regulator. Unregulated gas pressure can seriously damage the system and endanger human life.
  • Page 228 BULLETIN 10-11 / Page 5 Factors which affect valve performance and may make it necessary the estimated pressure drop will equal the approximate to adjust the valve are: suction line pressure at the bulb. 1. Low temperature difference (TDs) between the refrigerant and 3.
  • Page 229 Page 6 / BULLETIN 10-11 If in doubt about the correct superheat setting for a particular system, The primary cause of difficulty with either the BP or RPB feature is consult the equipment manufacturer. As a general rule, the proper dirt and other foreign materials that restrict or plug them.
  • Page 230 BULLETIN 10-11 / Page 7 3. Wax — Certain systems are contaminated with small amounts 7. Insufficient pressure drop across valve — One of the of wax which will precipitate at low temperatures in systems factors that influence expansion valve capacity is the pressure with Refrigerants 22 or 502.
  • Page 231 Page 8 / BULLETIN 10-11 flowing through the evaporator, check the piping for possible Disassemble the valve to be certain that dirt or foreign material refrigerant flow from another evaporator affecting the bulb. Re- is not responsible (see B-2). If the pin and seat are worn or pipe if necessary.
  • Page 232 BULLETIN 10-11 / Page 9 for this purpose. Another corrective measure is to install a suction 3. Low load— Low evaporator load may be caused by insuffi- line solenoid valve that is de-energized during the off-cycle. cient air over the coil as a result of an undersized blower, dirty air filters, or an obstruction in the air stream.
  • Page 233 Page 10 / BULLETIN 10-11 tions are not necessary. If hunting is severe with floodback to 5. System is hunting or cycling. See Section E on Page 9. the compressor, check the possible remedies shown in paragraphs below. 6. The TEV has been physically abused in an effort to make the valve work properly.
  • Page 234 BULLETIN 10-11 / Page 11 Note: These Field Assembly Instructions apply in part to all Sporlan exerting too much pressure in tightening the element or in clamping the body in the vise. Also, do not use a wrench on the TEVs.
  • Page 235 Page 12 / BULLETIN 10-11 upon request. (Since the internal parts of the Type (E)BF/SBF and EBS valves cannot be replaced, it is not necessary to check the pushrod height of these valves.) The appropriate gauge numbers for the various TEV’s are given - - - in Table 3.
  • Page 239 Vilter Mfg. Corp. Drwn By: SDP Date: 11/27/02 3186 R0 Cudahy Wi. 53110 Redrwn By: Approv. By: STRAINER ST HANSEN (FILTERS) STRAINERS HANSEN VALVE VILTER CATALOG SIZE FLANGE STYLE AND SIZE DESCRIPTION PART (INCHES) ½ FPT FLANGE CONNECTIONS 3186AF ST050 ½...
  • Page 240 Approved By: RPK Cudahy, WI 53110 DANFOSS REGULATING/MIXING VALVES NOTE: PORT A IS FOR THE OUTLET PORT B IS FOR THE HOT INLET PORT C IS FOR THE COLD INLET VILTER BODY OIL FLOW NOMINAL NO OF DANFOSS PART HOUSING...
  • Page 241 HA4AOAS - Inlet/Outlet Economizer Port / Side Load Pressure Regulator Purpose: To maintain an operating pressure in the economizer or side load vessel, while providing a means of protecting the compressor motor from overloading from high economizer loads during start-up, or from high side loads.
  • Page 242 Hansen HA4AOAS Inlet/Outlet Regulator for Screw Compressor Economizer (Controls Pressure of accumulator or other types of vessels that is economized and controls outlet pressure to economizer port on screw compressor) Inlet Module Range A Turn CW to increase back pressure Turn CCW to decrease back pressure Electric Shutoff Outlet Module Range B...

This manual is also suitable for:

Vsr 111-301Vsm 71-701

Table of Contents

Save PDF
