IR7-TIR
* UL certification only refers to the power converter and the power module.
* Please use an independent power supply for the IR LED Illuminator.
FEATURES
7 Super Power IR LED, 4pc x 25
IR Distance up to 150~200ft / 45~70m
IP66 Rating
User Adjustable IR LED Intensity (VR), Factory Default 80%
Uses professional rust-proof stainless steel screws
Includes 1 side and 1 underneath mounting plate
24V AC, 40VA
Please see page 6
Please read the Operational Manual
before attempting to use this product.
Operational Manual
7 Super Power IR LED Illuminator
o
o
/ 3pc x 45
1
IR7-TIR_rev03242008
Advertisement
Table of Contents
Related Manuals for O.K.I. usa IR7-TIR
Summary of Contents for O.K.I. usa IR7-TIR
- Page 1 Please read the Operational Manual before attempting to use this product. IR7-TIR Operational Manual 7 Super Power IR LED Illuminator * UL certification only refers to the power converter and the power module. * Please use an independent power supply for the IR LED Illuminator.
- Page 2 PART DESCRIPTION IR7-TIR_rev03242008...
- Page 3 1. Temper Glass 2. IR LED: 7pcs Super Power IR LED with refractor 3. IR Board and IR Board Bracket 4. IR Control Board 5. Power Supply Unit: 24V AC, 40VA 6. Blower and Blower Bracket 7. Cable Conduit 8. Live (L): Brown wire 9.
- Page 4 WIRING INSTRUCTION 1. Underneath Mounting Plate (Included) 2. One-Side Mounting Plate (Only 1 Included) One-Side Mounting Plate IR7-TIR_rev03242008...
- Page 5 Underneath Mounting Plate included Use with any O.K.I.USA PRO Series housing and Double Side Mounting Plate IRM-TDP DIMENSIONS (mm) IR7-TIR: Optional IRB-TBT Semi-Cable Managed Bracket (Not Included): Max Load: 3500g Material: Die-cast aluminum alloy with light ivory powder coated and stove finish Scan Angle: 200 °...
- Page 6 NOTE 2: Factory default for the IR LED activation level is 80%. If there is not enough IR light, adjust the VR level to maximum 100%. Please see #17 in the Part Description section on page 1. LIST OF COMPONENTS One (1) IR7-TIR IR Illuminator with power cable One (1) Underneath Mounting Plate One (1) One-Side Mounting Plate...
- Page 7 WARRANTY O.K.I.USA Products are covered under warranty for one year from the date of purchase. The warranty will automatically be voided if any of the following occurs: 1. Product sticker is removed If the product sticker is removed, we will not be able to confirm any information regarding when and where the product was purchased.
- Page 8 IR7-TIR_rev03242008...
