Aiphone SP-5N Specifications

SP-5N
Flush Mount Ceiling Speaker
DESCRIPTION:
The SP-5N is a ceiling speaker used for
paging and background music. It is equipped
with a 70V transformer with five wattage taps
up to 4W. The speaker is mounted to a round
steel baffle, finished with a white powder-
coated epoxy. An optional ceiling support
bridge is available for installations in drop tile
ceilings.
Designed for indoor use only.
SP-5N
SPEAKER SPECIFICATIONS:
Size:
Magnet Weight:
Magnet Material:
Voice Coil Impedance: 8
DC Resistance, ohms: 7.4
Voice Coil Diameter:
Power Handling:
Frequency Response:
Depth:
Weight:
Cone:
Aiphone Communication Systems • 1700 130th Ave. NE • Bellevue, WA 98005
(425) 455-0510 • FAX: (425) 455-0071 • (800) 692-0200 • www.aiphone.com
8"
5 oz.
Ceramic
3/4"
8W RMS
65 to 17K Hz.
2-3/4"
1.75 lbs.
Dual
Accessories
FEATURES:
• 8" dual cone speaker, 8 ohms
• 70V transformer
• Five wattage taps from 1/4W to 4W
• Round white steel baffle
• Excellent sound reproduction for
music and paging
SSB-2
Mounting bracket for drop tile ceiling
TRANSFORMER WATTAGE TAPS:
Com: Black
1/4W: Green
1/2W: Yellow
BAFFLE SPECIFICATIONS:
Type:
Baffle Diameter:
Material:
Finish:
Depth Projection:
Weight:
- 74 -
1W: Orange
2W: Red
4W: Brown
One-step contour
12-7/8"
22 gauge steel
zincrometal
White semi-gloss
powdered epoxy
3/8" from surface
1.5 lbs.
