Thank you for selecting Chevrolet vehicle
Please read through the Manual, because you can understand how to correctly control the vehicle from the information, and
obtain the greatest driving enjoyment.
Chevrolet Sales (Thailand)
Owner Manual of Captiva CN202SR
"The Owner Manual" and "Maintenance and Warranty
Manual" define the agreements of
(Thailand)
and users on establishment and termination of
responsibility of quality guarantee of relevant products and
rights and obligations of after-sales service. Please carefully
read Owner Manual and Maintenance and Warranty Manual
before using the products of the Company.
Notice
Chevrolet Sales

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Captiva CN202SR and is the answer not in the manual?

Questions and answers

Related Manuals for Chevrolet Captiva CN202SR

Summary of Contents for Chevrolet Captiva CN202SR

  • Page 1 Owner Manual and Maintenance and Warranty Manual before using the products of the Company. Owner Manual of Captiva CN202SR Thank you for selecting Chevrolet vehicle Please read through the Manual, because you can understand how to correctly control the vehicle from the information, and obtain the greatest driving enjoyment.

  • Page 3: Table Of Contents

    Content 1 Introduction ....... 2 Content Key, doors and windows ... 7 Seat and safety equipment ..27 Storage........49 Instrument and control device . 55 Lighting........92 Temperature control system . 102 Driving and operation .... 115 Vehicle maintenance ..... 143 Maintenance procedure ..

  • Page 4: Introduction

    The contents marked with Manual. are different according to different “Warning” indicate the risk of function configurations of model. Chevrolet Sales (Thailand) ensures accident or harm. The driver  The Manual includes the latest that all staff of Authorized Workshop...
  • Page 5 “Caution” indicate that the you buy is uncertain to be equipped. vehicle may be damaged. The This book is copyright by Chevrolet Sales vehicle may be damaged in (Thailand), all rights reserved. case ignoring information.
  • Page 7 Index Remote control door lock system * ......9 Lighting ..............71 Central door locking system * ......13 Fast cooling ............89 Exterior rearview mirror ........15 Fuel filling ............102 Interior overview mirror ........16 Replace the tire ..........127 Window ..............

  • Page 9: Key, Doors And Windows

    Key, doors and windows 7 External/Internal Door Opening12 Adjusting Outside Rearview Key, doors Mirror ........18 windows Door Locking Method in Case of Vehicle Outage ......12 Electrically Folding Outside Key ..........8 Rearview Mirror ..... 19 Child Safety Lock ..... 13 Remote Control Door Lock Automatically Folding Outside Central Door Lock System ..

  • Page 10: Key

    8 Key, doors and windows Note Remote Control Door Lock If the key is lost, please System contact with the Aftersales Service Center. Detachable key Each new vehicle is provided with two The effective distance of remote keys. Please reserve one key for control about without...

  • Page 11: Vehicle Locating

    Key, doors and windows 9 hazard warning lamp will flash once, Remote Opening/Closing Note and the anti-theft state is released. Panoramic Sunroof The anti-theft mode must be activated with the transmitter. : liftgate unlock button. Press and If the vehicle is configured with a hold for about 2s;...

  • Page 12: Door Unlock And Release Of Anti-Theft Mode

    10 Key, doors and windows Door Unlock and Release of 1. There is a door not closed (including Door Lock liftgate); Anti-theft Mode External Door Locking 2. The door lock is under thermal 1. Press the unlock button on the Unlocking protection;...

  • Page 13: Internal Door Locking And Unlocking

    Key, doors and windows 11 Note Internal Door Locking Unlocking When you leave the vehicle unattended, you must lock all doors and liftgate and take the key with you. If the doors and liftgate unlocked, vehicle may be stolen. Please park your vehicle...

  • Page 14: External/Internal Door Opening12

    12 Key, doors and windows External/Internal Door Opening When the doors are locked, pulling the internal door handle twice can open the doors. A child shall sit on the rear seat, and the door shall be locked with the child safety lock.

  • Page 15: Child Safety Lock

    Key, doors and windows 13 Child Safety Lock To activate the child safety lock: Note rear doors equipped with a child safety lock respectively. They function separately and must be activated manually and respectively. Note When the child safety lock is The rear doors are equipped with child 1.

  • Page 16: Door Lock Thermal Protection

    14 Key, doors and windows Liftgate Opening Door Lock Thermal Protection Doors The liftgate can be opened in 3 ways: If the doors are unlocked/locked for Liftgate over 10 times within 8s, the locks will 1. Unlock doors first, and then press Liftgate Release Switch be prohibited for 10s to protect them.

  • Page 17: Passive Entry Passive Start (Peps) System

    Key, doors and windows 15 Liftgate Opening from Inside of Passive Entry Passive Start certify with the key. Once certified Luggage Compartment successfully, the system will unlock all (PEPS) System doors. The hazard warning lamp flashes once. High-configured models are equipped with PEPS system.

  • Page 18: Passive Unlocking/Locking Of Liftgate

    16 Key, doors and windows Passive Unlocking Passive Locking The system will send warning prompt, the horn will buzz thrice and the When the doors are locked and the If the doors are locked, when the hazard warning lamp will flash thrice ignition switch is Passive Unlocking liftgate is closed, the system will to indicate that the doors are not...

  • Page 19: Engine Hood

    Key, doors and windows 17 2. After the engine hood is opened 2. Make sure that your or other Engine Hood persons’ hands or other body slightly, stretch out the hand to the Opening Engine Hood lower side of the engine hood front parts are away from the engine edge.

  • Page 20: Outside Rearview Mirror

    18 Key, doors and windows 2. Press the buttons (△) around the Outside Rearview Mirror Caution setting pan to adjust the selected ● Pull the engine hood front Please check the visual field of all rearview mirror upward, rearview mirrors before driving. edge before driving downward, leftward...

  • Page 21: Electrically Folding Outside Rearview Mirror

    Key, doors and windows 19 Electrically Folding Outside If the electric folding button is pressed, Inside Rearview Mirror the outside rearview mirror will not be Rearview Mirror unfolded automatically when the doors are unlocked. Folding To ensure the pedestrian's safety, the outside rearview mirror can be folded forward or backward from its normal mounting...

  • Page 22: Windows

    20 Key, doors and windows Windows Power Window Switch Note Power Window The anti-dazzling mode will reduce vision clarity When the ignition switch is at ON behind the vehicle. Please position, you can control the power drive carefully. window with the power window switch on the door armrest panel.
  • Page 23 Key, doors and windows 21 One-button Lowering of Driver’s lowered automatically for a distance in Power Window Lock Button Side Power Window case of any obstruction in its one-button rising process. The driver’s side power window has the one-button lowering function. Remote Lowering of Power Window Press the switch to the bottom and Press and hold the unlock button on the...

  • Page 24: Sunshade

    22 Key, doors and windows Sunshade Caution Children may operate the power window and may get stuck by the window when they operate it or may get out vehicle from window, leading severe causalities. Please use the power window lock when there is a child in the vehicle.

  • Page 25: Auxiliary Handrail

    Key, doors and windows 23 Auxiliary Handrail Panoramic Sunroof Sunroof Tilting The panoramic sunroof is composed of two parts—the front part is tiltable and slidable and the rear part is fixed. Sun Blind The front part of the sunroof can be Above the front passenger’s side door tilted.

  • Page 26: Sunroof Sliding

    24 Key, doors and windows To close the titled sunroof, push the Sunroof Sliding push the sunroof switch forward once sunroof switch forward, and release quickly (short press), and the sunroof the switch when the sunroof reaches will be slided close automatically. the desired position.
  • Page 27 Key, doors and windows 25 Remote Sunroof Opening Shutdown Delay Function open position) or return to the half- Closing open position (exceeding the half- Within 30s upon vehicle shutdown, the open position). Press the unlock button/lock button of sunroof and sun blind can be closed with the remote control for about 2s, the buttons but cannot be opened.
  • Page 28 26 Key, doors and windows...

  • Page 29: Seat And Safety Equipment

    Seat and safety equipment 27 Height Adjustment ....35 Headrest Seat safety equipment Unbuckle ........35 Position Rear Row Seat Belt ....35 Headrest ........27 Seat Belt Use during Pregnancy Position ........27 ..........36 Height Adjustment ....28 Child Seat ........37 Front Seat........

  • Page 30: Height Adjustment

    28 Seat and safety equipment Warning Height Adjustment Front Seat Before driving, make sure that Seat Position and Backrest headrest adjusted Normal Condition properly. Removal improper adjustment of the headrest will cause severe injuries to the head and neck in collision accidents.

  • Page 31: Seat Position Adjustment

    Seat and safety equipment 29 slightly bending the arm. Keep the Seat Position Adjustment Note shoulders leaning against the Electric Adjustment Type backrest while turning the steering If the seat does not move wheel. The backrest shall not when the switch is pushed, incline excessively backward.

  • Page 32: Seat Backrest Adjustment

    30 Seat and safety equipment Driver’s Seat Height Seat Backrest Adjustment Note Adjustment Electric Adjustment Type If the backrest does not move Electric Adjustment Type when the switch is turned, the backrest may be already at its limit position, or the vehicle battery is out of power.

  • Page 37: Seat Belt

    Seat and safety equipment 33 front passenger’s seat belt is also Warning Seat Belt configured with a force limiter. Improper operation (for example removal The force limiter can reduce the stress installation of seat belt or seat applied on the body through the seat belt damping release in case of a collision belt anchor buckle) will trigger accident.

  • Page 38: Wearing

    34 Seat and safety equipment Warning Wearing 2. Put the latch plate in the buckle for fixing. Pull the shoulder belt The seat belt shall not be forcibly to adjust the tightness buckled against a hard or degree of hip belt. fragile object in your pocket.

  • Page 39: Height Adjustment

    Seat and safety equipment 35 Height Adjustment Unbuckle Rear Row Seat Belt Left and Right Seat Belt For buckling and unbuckling of the left and right seat belts of the middle row, please refer to that of the front seat belt.

  • Page 40: Seat Belt Use During Pregnancy

    36 Seat and safety equipment Middle Seat Belt of Second Row 3. Plug the other latch plate (movable) Seat Belt Use during Pregnancy into the buckle on the right side of Wearing: the seat. 1. Pull out the seat belt from the recoiler on the roof first and sit well.

  • Page 41: Child Seat

    Seat and safety equipment 37 is the key to exert the best protection Child Seat Caution effect of the seat belt. An unfixed child seat may be The vehicle is not equipped with a child Warning seat. If you want to add one, a child seat thrown out of the vehicle in that is applicable to ISOFIX “general”...

  • Page 42: Child Restraint System Type

    38 Seat and safety equipment Child Restraint System Type Please select a suitable child seat Caution according to the child body weight and The size and configuration body figure. range of the child seat is very For infants under one year old, their wide.

  • Page 43: Isofix

    Seat and safety equipment 39 ISOFIX 5. Connect the upper strap of the child seat to the corresponding fixing point of the vehicle. Refer to the child seat instructions to get to know when and how to strain the upper strap. As shown in the figure, the ISOFIX upper fixing point is on the roof above the rear seat.

  • Page 44: Air Bag System

    40 Seat and safety equipment Warning Air Bag System to reduce the injury risks caused by the impact force when the air bag is inflated, It is forbidden to let a child, Depending vehicle all air bags must be inflated rapidly to infant, pregnant woman and configuration, the system includes the exert its effect.

  • Page 45: Air Bag Indicator

    Seat and safety equipment 41 Side Air Bag Air Bag Indicator Air Bag Position Frontal Air Bag As shown in the Figure C, the front On the instrument panel, there is an seat side air bag is installed on the air bag indicator which displays the air As shown in the Figure A above, the backrest side near to the door.

  • Page 46: When Shall The Air Bag Be Inflated

    42 Seat and safety equipment Side Curtain Air Bag When Shall the Air Bag Be Warning Inflated? If there is any other object between the occupant and the The frontal air bag is designed to be air bag, the air bag may not be inflated in moderate to severe head- able to be inflated normally or collision...

  • Page 47: How Is The Air Bag Inflated

    Seat and safety equipment 43 air bag may not be inflated in slight bag should be inflated according to the the impact force more evenly to the occupant’s body. However, some head-on or nearly head-on collisions, causalities, vehicle damage or repair occupants’...

  • Page 48: Air Bag System Repair

    44 Seat and safety equipment  The air bag can only be inflated Aftersales Service Center for repair Warning once as per its design. After the air and maintenance of the air bag When the air bag is inflated, bag is inflated, some parts of the air system.
  • Page 49 Seat and safety equipment 45 Other Situations Where the Air Bag The Frontal Air Bag May not Be May Be Inflated (Deployed) Except Inflated in the Following Collisions for Collision The frontal air bag will usually not be If the vehicle bottom is impacted inflated in case of side collisions, rear- seriously, the air bag may also be end collisions, turnover or low-speed...
  • Page 50 46 Seat and safety equipment  Side collision  Overturn, falling from high place,  Hit into front vehicle bottom, rolling especially truck bottom  Rear-end collision  Hit deformable objects, such as sandpile, guard bar, column and tree...
  • Page 51 Seat and safety equipment 47 Side Air Bag/Side Curtain Air Bag (If Equipped) May not Be Inflated in the Following Collisions In case of side collisions with certain angle or collisions to vehicle body side (not passenger compartment), the side air bag/side curtain air bag system may not be activated.
  • Page 52 48 Seat and safety equipment Important Note  Side collision to truck during drifting...

  • Page 53: Storage

    Instrument and control device 49 Roof Rack ........54 Storage box Storage Load Information ...... 54 Right instrument panel storage Storage box ......49 Right instrument panel storage box .........49 Central instrument panel storage box ......50 Armrest storage box ....50 Glasses box ......50 Console Storage Box .....51 Glove Box ......51...

  • Page 54: Storage Box

    50 Seat and safety equipment Central instrument panel Armrest storage box Glasses box storage box It is located between the front seats. Pull If equipped, the glasses box is located The storage box is under the air- up the storage box cover to open it. on the roof.

  • Page 55: Console Storage Box

    Instrument and control device 51 Console Storage Box Glove Box Map Pocket The map pocket is located on the backside of the front seat backrest. Pull the handle outward to open it. To It is behind the armrest box. close, push and fasten the glove box door inward.

  • Page 56: Armrest

    52 Seat and safety equipment Cup Holder Door Storage Groove Backrest Hook Armrest The cup holder is located on the On the junction of each seat backrest console between the front seats. and headrest, there is a hook. You can The door storage groove and armrest There are 2 cup holders on the rear hang a shopping bag or other suitable...

  • Page 57: Luggage Compartment Cargo Cover

    Instrument and control device 53 Luggage Compartment Cargo Packing Up Luggage Cover Luggage Cover Removal Cover As shown in the figure, release the As shown in the figure, press the caps on both ends of the luggage cover luggage cover plates from th、e guide The cover is used to shield the objects recoiler toward the middle to remove slots on both sides of the luggage...
  • Page 58 54 Seat and safety equipment Warning Roof Rack parking brake and shift lever nor limit the free movement of the Do not place any object on The roof rack is an external trim item. To driver. Do not put any object not luggage compartment avoid damaging the vehicle, please do...
  • Page 59 Instrument and control device 55 Tripmeter ......... 63 Gear display ......72 Instrument control device Engine coolant temperature The Door is not closed gauge ........63 warning ........72 Instrument panel ..... 57 Multi indicator display (MID) Combination instrument Control device ......59 screen ........
  • Page 60 56 Seat and safety equipment ABS fault warning lamp ..80 ESC OFF Indicator ....86 EPS fault warning lamp ..80 Transmission failure warning light ..........87 Airbag warning lamp ....81 Constant speed cruise work status Brake system fault warning indicator ........87 lamp/EBD warning lamp ..82 Tire Pressure Monitoring System Engine anti-theft system...

  • Page 61: Instrument And Control Device 57

    Instrument and control device 57 Instrument panel Front side vents Side vents ESC OFF switch Central vents Front window defroster vents Power ON/OFF Audio Headunit display Hazard lamp Wiper and washer switch Audio control switch Instrument cluster Horn / Driver airbag Headlamp, Turning signal...
  • Page 62 58 Instrument and control device AUX port / USB port Home button Front windshield defroster button Glove box...

  • Page 63: Control Device

    Instrument and control device 59 adjusting Steering wheel Caution Control device The driver must maintain fully Horn control of the steering wheel while the vehicle is running. It has been prohibited to adjust the steering wheel position during the vehicle is running. Adjusting the steering wheel during driving may result in loss of control of the vehicle.

  • Page 64: Front Windshield Wiper And Washer

    60 Instrument and control device Front windshield wiper and HI: pull the lever down to the LO position Caution and wipe the windshield continously with washer driver's blurred  high speed. vision can cause an accident, resulting in personal injury and The speed of the intermittent wiper (INT) is adjustable.

  • Page 65: Rear Windshield Wiper And Washer

    Instrument and control device 61 Rear windshield wiper Entertainment system Rear power USB port washer external interface The entertainment system interface is To use the rear windshield wiper, first located below the air conditioning panel. The second row of USB power jacks turn on the ignition switch ON, make (5V/2A) are located at the rear of the sure the tailgate is closed, then turn...

  • Page 66: Warning Lamp, Meter And Indicator

    62 Instrument and control device Warning lamp, meter and Tachometer Fuel gauge indicator Speedometer Display engine RPM per minute. Display the fuel level in the fuel tank. Control indicator will be turned on in case of low fuel level in the tank. Display the vehicle speed.

  • Page 67: Odometer

    Instrument and control device 63 Hazard Tripmeter Engine coolant temperature Must stop vehicle and turn off gauge the engine before refueling. Odometer Displays the distance traveled since the last reset. In this mode, long press the lever to clear the travel mileage. Display the temperature of the engine The mileage can be cleared when the coolant.

  • Page 68: Multi Indicator Display (Mid) Screen

    64 Instrument and control device Multi indicator display (MID) Average fuel consumption When the vehicle is driving on a long- distance ramp (upper and lower screen slopes), or encountering a long-term traffic jam, average fuel consumption table may indicate that the fuel consumption value may be higher or lower than usual.

  • Page 69: Instantaneous Fuel Consumption

    Instrument and control device 65 Instantaneous fuel consumption Cruising range Instantaneous fuel consumption is the cruising range indicates reference fuel consumption under reference mileage current current throttle control under the remaining fuel consumption, which current driving cycle, expressed in varies with the fuel consumption of the L/100km.

  • Page 70: Multi Indicator Display (Mid) Screen Type I

    66 Instrument and control device Multi indicator display (MID) screen Type I Driving Information Display Vehicle information Settings Multimedia information display TAB Bluetooth phone information display TAB Navigation Information Display TAB Display Area Temperature Display Gear display Total odometer...

  • Page 71: Combination Instrument Control Key

    Instrument and control device 67 modes of operation: short press (<2S) reference average fuel Combination Instrument consumption is in L/100km, which can and long press (≥2S). Control Key help the driver to form good driving Driving Information Display habits. The Type II MID is controlled by the control keys on the steering wheel.
  • Page 72 68 Instrument and control device Interface 4 – Driving Time / mileage Interface 2 - mileage subtotal 2 / Interface current speed mileage total instantaneous fuel consumption Travel time from the vehicle after the Show Subtotal Mileage 2 and Total The current vehicle speed is used to start of the cumulative, stop the Mileage.

  • Page 73: Vehicle Information Setting Tab

    Instrument and control device 69 alarm light is on, the mileage will show standard pressure tire Vehicle Information Setting Tab "Please Refuel". described in the section "Technical data". Press the "OK" button under the current interface, the driving time will When the tire temperature is too high, be cleared, but the mileage can not be such as long slope and frequent braking,...
  • Page 74 70 Instrument and control device Interface 1 - fault information query Interface Fatigue Driving When the tab icon changes to the above Reminder Settings image, you should be alert to contact the service center in time to repair the car, to eliminate security risks.

  • Page 75: Multimedia Information Tab

    Instrument and control device 71 Interface 4 - Display language Under this tab, the instrument cluster will corresponding information according settings display the real-time display according to the status of the Bluetooth phone. received audio Navigation information display information, etc. If the combination meter fails to establish a connection with relevant system,...

  • Page 76: Gear Display

    72 Instrument and control device Gear display Combination instrument upshift, the right side of the arrow (↑) icon lights up. brightness adjustment section "Automatic Transmission” for details on driving and handling. The Door is not closed warning The high-profile model has a backlight brightness adjustment button for the The control types of the automatic instrument cluster on the left side of...
  • Page 77 Instrument and control device 73 As shown in the figure, during the adjustment process, the LCD shows the current backlight brightness. If there is no action in seconds, save the settings and back to the previous interface. When the small light is on, backlight brightness will automatically reduced.

  • Page 78: Instrument Control Indicator

    74 Instrument and control device Instrument control indicator...
  • Page 79 Instrument and Control 75 Tachometer Electronic Stability Control When the ignition is turned on, as a Engine anti-theft system (ESC) off indicator function test, most of the control indicator Airbag warning lamp indicators will light up briefly. Electric power steering (EPS) ABS warning lamp Control indicator color means: warning lamp...

  • Page 80: Turn Signal Lamp/Hazard Warning Indicator

    76 Instrument and control device Caution Turn signal lamp/hazard engine pressure warning indicator warning lamp These indicators are essential conditions for safe driving. If turn signal or hazard warning flasher indicates bulb burnout, please immediately replace. In the event of failure to keep these indicators good...

  • Page 81: Warning Lamp Of Door Open

    Instrument and Control 77 visit nearest Authorized Charging system warning lamp Suggest going nearest Workshop to inspect the lubrication Authorized Workshop for repair as system of the vehicle. soon as possible. Caution Note Don’t drive the vehicle when Charging system warning engine oil pressure warning lamp indicates that charging...

  • Page 82: Overheat Water Temperature Warning Lamp

    78 Instrument and control device Overheat water temperature Front fog indicator lamp Working indicator of headlamp warning lamp high beam When the front fog lamps are on, the indicator is on. Refer to “Front Fog Temperature indicator will turn off When headlamp high...

  • Page 83: Position Lamp Indicator

    Instrument and Control 79 Position lamp indicator Engine fault warning lamp the fault in the nearest Authorized Workshop as soon as possible at this time. If indicator flashes once suddenly and turns off, it is normal and it does not indicate that the system has fault.

  • Page 84: Abs Fault Warning Lamp

    80 Instrument and control device ABS fault warning lamp If ABS warning lamp is illuminated while EPS fault warning lamp driving, it indicates that your ABS system may be faulted. Although your vehicle can normally run under the condition of no ABS function, please go to the nearest Authorized Workshop for system inspection and necessary repair as soon as possible.

  • Page 85: Airbag Warning Lamp

    Instrument and Control 81  Caution The lamp is not lighted up when Airbag warning lamp the ignition switch is switched on. If the airbag warning lamp  It stays on after it is lighted up. flashes or keeps on during ...

  • Page 86: Brake System Fault Warning

    82 Instrument and control device  Brake system fault warning If brake system warning lamp is lighted Brake system warning lamp is up when park brake is fully released, it lighted up continuously. lamp/EBD warning lamp  indicates that brake fluid level of the fluid The brake works abnormally.

  • Page 87: Engine Anti-Theft System

    Instrument and Control 83 Caution Engine anti-theft system Driver seat belt warning lamp indicator Don’t drive the vehicle if brake system warning lamp is not lighted up when park brake is engaged and ignition switch is switched on. Ensure that warning lamp LED works normally.

  • Page 88: Front Passenger Seat Belt

    84 Instrument and control device Front passenger seat belt Fuel level indicator warning lamp Electronic Parking Brake (EPB) warning lamp Status indicator The warning lamp will be lighted up When the Electronic Parking Brake This warning lamp is lighted up when momently when the ignition switch is (EPB) pulled...

  • Page 89: Electronic Parking Brake (Epb) Fault Warning Light

    Instrument and Control 85 Electronic Parking Brake (EPB) When the Electronic Parking Brake Automatic Vehicle Holding (EPB) fault warning light appears above fault warning light (AVH) Status Indicator the above exception, please contact the service center. If the electronic hand brake failure may occur the risk of slip car.

  • Page 90: Automatic Vehicle Holding (Avh) Fault Indicator

    86 Instrument and control device Automatic Vehicle Holding ESC fault warning light ESC OFF Indicator (AVH) Fault Indicator When the ignition switch is turned on, When the ignition switch is turned on, the indicator light will light briefly, the indicator light will light briefly, When the automatic vehicle holding indicating that the indicator is working indicating that the indicator is working...

  • Page 91: Transmission Failure Warning Light

    Instrument and Control 87 Transmission failure warning Tire Pressure Monitoring Constant speed cruise work light System (TPMS) Fault Warning status indicator Light When intelligent manual This indicator lights when the cruise transmission system failure, control function is enabled. Refer to the When the ignition switch is turned on, warning light is lit, please contact the section "Speed Control Cruise System"...

  • Page 92: Reversing Radar

    88 Instrument and control device Note Reversing Radar you will hear a reverse intermittent warning tone. When the vehicle is within  The following occasions are Intelligent reversing radar through the a range of approximately 0.4 meters easy to cause the system to rear of the vehicle installed in the from the rear of the vehicle, you will hear detect, please note:...

  • Page 93: Reversing Video Display

    Instrument and Control 89 Note Reversing video display the yellow line for the obstacles from the rear of the cable 1.0 meters  In the following cases, the warning line, the top of the green line operation is often caused for the obstacles from the rear 2.0 by an error sensor.

  • Page 94: Parking Assistant System

    90 Instrument and control device the buzzer issued a long warning parking assistance system turn into Parking Assistant System sound. For the left rear, right rear working condition. The parking assist system determines sector indication area: If the front and rear of the vehicle are the distance between the front and rear When the distance of about 0.6 to 1.0 close to the obstacle, the auxiliary...

  • Page 95: Parking Assistant System Display

    Instrument and Control 91 Parking assistant system automatically closed. When you press the close button ( X ) of the window, the display window closes immediately. Still continue to pop up when an obstacle is detected. Caution Reversing radar and parking assistant system can only assist the driver in the reverse or parking to avoid accidents, the...

  • Page 96: Lighting

    92 Lighting Front Reading Lamp ....97 Exterior lighting Lighting Rear Reading Lamp ....97 Lighting Switches Exterior lighting ....... 92 Luggage Compartment Lighting Switches ....92 Illumination Lamp ....97 High Beam ......93 Headlamp Flashing ....93 Hazard Flasher ......94 Turn and Lane Change Signal Lamp ........94 Steering Assist Lighting Function .........95...

  • Page 97: Headlamp Flashing

    Lighting 93 High Beam the control lever towards the opposite = The low beam lamp and all lamps direction until it returns to the normal mentioned above illuminate under the position. precondition that the ignition switch is turned to ON position. Warning When approaching the on- coming vehicle or the vehicle...

  • Page 98: Hazard Flasher

    94 Lighting Hazard Flasher Turn and Lane Change Signal reaching the turn signal lamp position) and keep pulling it. After lane change, Lamp release the control lever and it will return normal position automatically. A rear turn signal lamp is integrated on the rear combination lamp and the rear bumper...

  • Page 99: Steering Assist Lighting

    Lighting 95 Steering Assist Lighting 3. The vehicle speed is > 40 Km/h; Front Fog Lamp Function 4. The low beam lamp is turned off. During steering, the two front fog lamp will illuminate to provide auxiliary lighting if certain conditions are satisfied.

  • Page 100: Backup Lamp

    96 Lighting Backup Lamp Headlamp Leveling Headlamp OFF Delay The backup lamp illuminates after you To trigger off headlamp OFF delay turn on the ignition switch and shift to function, turn off the headlamp and reverse gear. pull the light control lever towards the steering wheel within one second for Stop Lamp twice after you shut down the engine...

  • Page 101: Interior Lighting

    Lighting 97 Warning Interior Lighting Luggage Compartment Illumination Lamp Please avoid usage of the Front Reading Lamp inside lamps during driving in darkness. A bright passenger compartment can reduce the visibility outside and cause collision as a result. Rear Reading Lamp luggage compartment illumination lamp illuminates as the...
  • Page 102 98 Audio and enterteinment system Audio and entertainment system Audio control button on steering wheel ........99 Navigator upgrading....99 Audio and enterteinment system .........100 Inspection before repair ..100...

  • Page 103: Audio Control Button On Steering Wheel

    Audio and entertainment system 99 Audio Control Buttons on 4. Song Selection/Station Switch Navigator Upgrading Thumbwheel Steering Wheel When the navigator cannot display Pull the thumbwheel up and down to comparatively new main roads, it is select the station or song. time to update and upgrade the map data.

  • Page 104: Audio And Enterteinment System

    100 Audio and entertainment system Audio and entertainment system As the model configuration or the supporting manufacturers are different, the audio entertainment system function, the display interface and the operation method may be different, such as video and entertainment, navigation, reverse camera, Bluetooth and telephone calls.
  • Page 105 Audio and entertainment system 101 Phenomenon Possible causes and solutions Certain audio files cannot be played Please confirm whether the device supports such audio files. Refer to the vehicle audio via USB connection. system instructions. As MP3 songs are of wide sources and no uniform standard applies. The reason can be The sound volume fluctuates as MP3 that the volumes of MP3 songs are different as they are compressed.

  • Page 106: Temperature Control System

    102 Audio and entertainment system Rapid Defrosting and Defogging Temperature control ..........113 system Vent ........103 Air Conditioning ..... 105 Electronic Air Conditioning ..105 Temperature Control Button 106 Fan Control Button ....106 Air Distribution Mode Button 106 Internal Circulation Mode Button ........108 Front Windshield Defroster Button ........109...

  • Page 107: Temperature

    Temperature control system 103 Vent 1. Side air outlet 2. Front door window defogger air outlet 3. Central air outlet 4. Front windshield defogger air outlet 5. Floor air outlet 6. Front seat lower air outlet 7. Console air outlet...
  • Page 108 104 Temperature control system Side Air Outlet Floor Air Outlet You can divert the air to both sides of The floor air outlet is used to divert the the front riding area or the side door air to the front foot area. windows operating Console Air Outlet...

  • Page 109: Air Conditioning

    Temperature control system 105 Air Conditioning Electronic Air Conditioning Air Conditioning Control Panel 1. Fan control thumbwheel 2. Display 3. Temperature control thumbwheel 4. Front windshield defroster button 5. Air conditioning (A/C) button 6. Mode selection button (backward) 7. Mode selection button (forward) 8.

  • Page 110: Temperature Control Button

    106 Temperature control system Temperature Control Button Fan Control Button Air Distribution Mode Button Tombol Tombol pengaturan pengaturan suhu kecepatan kipas Mode distribusi udara Push and hold temperature adjuster Push fan icon on the screen to increase Press desired mode selection button icon on the left of the screen and then or reduce the air volume by one range.
  • Page 111 Temperature control system 107 Foot Mode ( Face Mode ( Dual Mode ( Most of the air flows out from the floor In this mode, the air flows out from the In this mode, the air flows in two air outlet and the front seat lower air central air outlet, the side air outlet directions.

  • Page 112: Internal Circulation Mode Button

    108 Temperature control system Internal Circulation Mode Button Caution Foot/Defroster Mode ( You may feel tired and sleepy after long-time driving in the internal circulation mode. Please switch to external circulation mode on a regular basis to acquire fresh air. In this mode, air flows out from the front windshield defroster air outlet, You can press this button during driving...

  • Page 113: Front Windshield Defroster

    Temperature control system 109 Front Windshield Defroster The air circulation mode switches to Caution external circulation. Button Lack of proper maintenance Press the button again to turn off the may cause damage to the front defroster mode and the system defroster or scratches on restore to the state before defrosting.

  • Page 114: Air Conditioning System

    110 Temperature control system Air Conditioning System Caution Note Usage of the rear windshield conditioning Refrigerating device conditioning system is used to cool defroster prohibited compressor works, down the inside air and remove the under following consumes certain engine moisture and dust contained in the air. circumstances: power.

  • Page 115: Air Conditioning (A/C) Button

    Temperature control system 111 To turn off the air conditioning Air Conditioning (A/C) Button Cool Air system: Fast Cooling Press the air conditioning (A/C) button To cool down fast in scorching hot again. The button indicator goes out, days or after the vehicle is kept under indicating that the air conditioning the blazing sun for a long time: system has stopped refrigeration.

  • Page 116: Warm Air

    112 Temperature control system Normal Cooling Normal Heating Warm Air 1. Turn on the air conditioning (A/C) 1. Turn off the air conditioning (A/C) Rapid Heating button. (The indicator illuminates system. (The indicator goes out at Activate the rapid heating mode to at this time.) this time.) increase...

  • Page 117: Ventilation

    Temperature control system 113 Ventilation Ventilation Rapid Defrosting Defogging To control the air to flow out from the Dual Mode central air outlet and the side air outlet: Please operate in the following steps This mode is applicable to cool and in cold weather: 1.
  • Page 118 114 Temperature control system Please operate in the following steps if not in cold weather:  Air conditioning switch (A/C): ON  Air inlet mode: internal circulation switch external circulation after the fog has lift.  Air distribution mode:  Temperature switch: to the area that ensures passenger comfort.

  • Page 119: Driving And Operation

    Driving and operation 115 Shift lever operation ....127 Fuel ........140 Driving and operation Gears ........127 Fuel Suggestions ....140 Driving Instructions ....116 Gear display ......128 Do not Use Methyl Alcohol .. 140 Vehicle Control ....116 Brake ........

  • Page 120: Driving Instructions

    116 Driving and operation One Tire is Punctured When the One Fault Exists When the Vehicle Driving Instructions Vehicle is Running is Running Vehicle Control If one tire is punctured when the vehicle If one fault exists when the vehicle is is running, the driver shall hold the running, the driver shall turn on the Do not slide in case that the engine...
  • Page 121 Driving and operation 117  After taking provisional measures, If the Engine Does Not Work Measures Taken in Case of Engine Overheat immediately send the vehicle to In case that the ignition switch is at the the Aftersales Service Center for START position, if the starter motor When the vehicle is running, if the output inspection.

  • Page 122: Start And Operation

    118 Driving and operation Start and Operation Caution Note Please do not use such electric When engine gets Trial Run of New Vehicle equipment as audio and head heated, uncovering Following measures can be taken within lamp for a long time under the coolant reservoir will get the initial mileage of 500 km, which can condition that the engine is off.

  • Page 123: Engine Start Stop Switch Position

    Driving and operation 119 ENGINE START STOP Switch When the power is switched from the If no operation is conducted, the low voltage to the high voltage, the system will automatically return to the Position system must be able to detect the legal LOCK position 1h later, so as to key.

  • Page 124: Electronic Steering Column Lock

    120 Driving and operation ● START Electronic Steering Column Note Lock position, turn Never release the brake pedal transmission at the neutral or P As the electronic steering column lock in the process of starting the position, and depress the clutch pedal is used to lock the steering wheel, the engine;...
  • Page 125 Driving and operation 121  Adjust If unlocking the steering wheel is rearview mirrors 5. Do not depress the accelerator required, you can just enter the inside/outside the vehicle. pedal, turn the ignition-switch key vehicle with the legal key and press to the ON position, and release ...

  • Page 126: Turbocharged Engine Shutdown

    122 Driving and operation start in the normal procedures. Note Note You can firstly turn the ignition Do not keep the starter running Avoid the turbocharged engine switch at the ACC position, continuously for over 10s. from idling for a long time; the confirm that the transmission is at ●...

  • Page 127: Cruise Control System

    Driving and operation 123 you can long press the ENGINE Cruise Control System control system is 48 Km/h. Specific START STOP switch for 2s or application method: continuously press for 3 times within First Step: Cruise Start Based on the cruise control system Caution switch type, press the “...
  • Page 128 124 Driving and operation recover the speed to the original Then cruise control is carried out at the The speed will reduce by 2 km/h every cruising speed. previously-saved speed recovered. For time you pull down the switch once. If example, the cruising speed is 60 Km/h the toggle button is kept pressed, the Second Step: How to Deactivate...

  • Page 129: Engine Immobilizer System

    Driving and operation 125 Engine Immobilizer System Caution Note If the vehicle is equipped with The vehicle with the engine immobilizer In principle, the cruise control system has the extra anti-theft capacity, one steering wheel mechanical system can be used on one system prevent lock again, a better anti-theft...

  • Page 130: Transmisi Cvt

    126 Driving and operation Transmisi CVT 2. After starting the engine, put on Caution the brake pedal and then hang the Do not park and drive the Your vehicle may be equipped with a gear. CVT automatic transmission, which is a 3.

  • Page 131: Shifting

    Driving and operation 127 Shifting Shift lever operation Gears Lock button P: Parking gear transmission locked mechanically at the parking gear. Engage the parking (P) gear when the vehicle is motionless and the hand brake is drawn back. Note When the vehicle is parked on the ramp, it should first step down the brake pedal and pull handbrake...

  • Page 132: Gear Display

    128 Driving and operation D: forward (conventional mode) Danger Move the gear lever once toward (-) position, and lower one ratio. If the normal operation, speed is too high, the system will not In the process of driving, it is transmission will maintain the best forbidden to change the gear lever execute the down instruction and the...
  • Page 133 Driving and operation 129 Vehicle start condition, automatic transmission Caution may become very hot. After the engine is started and When stopping on a ramp (in replaced with the required stop, To avoid transmission damage, the case of a traffic jam), do not release the hand brake and brake system will...
  • Page 134 130 Driving and operation If this happens to the transmission, Caution please contact the special service When the transmission fault center for repair as soon as possible. indicator light Caution combined instrument is on, it indicates some functional When transmission fault of the transmission.

  • Page 135: Brake

    Driving and operation 131 Brake the Aftersales Service Center. This may Warning indicate a faulty brake system. Please check whether the The brake system is designed for the Note stop lamp is normal before braking performance under the driving conditions in wide range. In the driving your vehicle.

  • Page 136: Anti-Lock Brake System (Abs)132

    132 Driving and operation If the brake is unable to brake Anti-lock Brake System (ABS) Warning temporarily due to overheat. As one advanced electric braking If the ABS gets faulted, it may Engage a lower gear when driving system, the anti-lock brake system be unable to function, wheels downhill and use the engine to brake.

  • Page 137: Electric Brake Force Distribution (Ebd) System

    Driving and operation 133 Electric Brake Force vehicle. When the driver operates the ABS+EBD system functions vehicle beyond the limit values, in case normally, lamp Distribution (EBD) System of turning at high speed, the ESC normally on, indicating that the The EBD system uses the high-speed system automatically...

  • Page 138: Esc Off Switch

    134 Driving and operation will be enabled again. If the ESC OFF Switch Hill-start Hold Control (HHC) pressed time of ESC switch System exceeds 10s, the ESC system will The ESC system has the HHC consider it as one incorrect function.

  • Page 139: Parking Brake

    Driving and operation 135 may start sliding a slope. At the time, Parking Brake Warning you can depress the brake pedal to The HHC function may fail to Electronic Parking Brake (EPB) make the vehicle come to a complete prevent the vehicle from sliding stop, and the system will still help you a slope on a very slippery or to conduct the next start (when...
  • Page 140 136 Driving and operation Manually Apply Parking Brake If the brake pedal has not been Note depressed, the instrument will give a In the process of applying or hint “Please depress the brake pedal releasing parking brake, it is and then release the EPB switch”. normal that you will feel that When you are operating the EPB the brake pedal lifts or lowers.
  • Page 141 Driving and operation 137 met, the parking brake will be vehicle stops. If the EPB switch is while killing the engine. Try to move released automatically. released halfway, braking is released. the vehicle to confirm that EPB is not in the clamped state. To smoothly start and avoid sliding In case of dynamic braking, if the ESC backwards on one uphill pavement,...

  • Page 142: Automatic Vehicle Hold (Avh)138

    138 Driving and operation Automatic Vehicle Hold (AVH) Start and shutdown of AVH can be Note memorized. If AVH is in the on/off The professional equipment The vehicle provided with EPB has the state when the power is off last time, technologies automatic parking function.

  • Page 143: Automatic Vehicle Hold (Avh) Switch

    Driving and operation 139 Conditions (AVH Function Automatic Release After AVH Automatic Vehicle Hold (AVH) Activated Firstly): Switch You do not have to manually press the 1. The vehicle is motionless and the EPB switch to release when starting engine is running. the vehicle next time after AVH.

  • Page 144: Electric Power Steering (Eps) System

    140 Driving and operation Electric Power Steering The system will reduce the power assist Fuel after it enters the thermal protection (EPS) System Fuel Suggestions state, and at the time you have to steer the wheel with great force. If the normal The EPS system provides the steering Fill GB 92# gasoline for vehicle or power assist need be recovered, you...
  • Page 145 Driving and operation 141 Caution Danger Caution If you use any incorrect fuel, The fuel is one of flammables Using fuel with the engine and the catalytic or explosives. extremely low octane value will converter will get seriously Smoking is prohibited. Keep lead to uncontrolled burning damaged.

  • Page 146: Fuel Filling

    142 Driving and operation Fuel Filling Danger Shut down the engine and heating devices provided outside combustion chamber before refueling. Turn off all mobile phones. Follow operation and safety instructions gasoline station when refueling. 3. Slowly turn filler anticlockwise. If you hear the hissing sound, wait till the sound 1.
  • Page 147 Vehicle maintenance 143 Brake Fluid filling ....151 Fog inside lamp ..... 159 Vehicle maintenance Oil of transmission ....152 Bulb specification ....160 General information ....145 Check whether oil in transmission Wheels and tires ....164 Modification of accessories and leaks ........
  • Page 148 144 Vehicle maintenance Tow your vehicle with wheel lifting equipment....174 Emergency trailing ....174 Front towing hook ....175 Get rid of the tripping condition ........ 176 Vehicle maintenance ..... 177 Detergent ......177 Maintenance and cleaning inside the vehicle ....178 Maintenance and cleaning outside the vehicle ....179 Anticorrosion ......180...

  • Page 149: Vehicle Maintenance 145

    Vehicle maintenance 145 General information When the vehicle is to be stored Please notice that all systems do not work after disconnecting the for a long time: Modification of accessories and connection battery, If the vehicle is to be stored for several example, theft alarm system.

  • Page 150: Interior

    146 Vehicle maintenance  There are no foreign materials in Interior the thread. Steering Lamp  Check whether the steering wheel  Whether turning lamps, is too loosened (free travel). headlamps, tail lamps, steering Parking brake signal lamps, stop lamps and fog lamps work normally.

  • Page 151: Engine Compartment - 1.5 L (N15T)

    Vehicle maintenance 147 Engine Compartment – 1.5 L (N15T) Brake fluid reservoir Engine oil dipstick Engne oil filling hole Engine coolant reservoir Washer reservoir...

  • Page 152: Engine Oil

    148 Vehicle maintenance Engine oil Check the engine oil level 7. Check the engine oil on the oil level indicator, and confirm engine 1. Park the vehicle on the horizontal Maintain the engine oil in a suitable oil. It is not polluted. ground.

  • Page 153: Replacement Of Engine Oil And Oil Filter

    Vehicle maintenance 149 Note Replacement of engine oil and oil Caution filter It is forbidden to exceed the The engine oil should be upper limit mark of the oil replaced by special skills, After the engine oil is polluted, it will lose level indicator.

  • Page 154: Cooling Liquid

    150 Vehicle maintenance Note Caution Cooling liquid The old engine oil and filter The coolant is a dangerous The engine cooling system is filled by contain harmful ingredients, substance. ethylene glycol coolant. Under correct so it is not beneficial to health, ...

  • Page 155: Oil Of Brake And Clutch

    Vehicle maintenance 151 Brake Fluid filling Note Oil of brake and clutch Before opening the filler cap, oil of brake/clutch absorbs you must wipe up the filler cap moisture. Excessive oil moisture will of oil of brake/clutch. reduce the efficiency of the hydraulic system brake/clutch system.

  • Page 156: Oil Of Transmission

    152 Vehicle maintenance Caution Windshield washer fluid Oil of transmission The oil of brake/clutch has You must ensure there are sufficient Check whether irritation for skin and eyes. sanitizers in the washer fluid reservoir transmission leaks The oil of brake/clutch cannot of windshield before driving.

  • Page 157: Windshield Wiper

    Vehicle maintenance 153 Note Note Windshield wiper It is suggested to use ready- It is suggested to fill correct Normal function of windshield wiper is to-use special washer fluid. If washer fluid in Authorized the precondition of ensuring clear the concentrated washer fluid Workshop.

  • Page 158: Clear The Air Filter

    154 Vehicle maintenance It is not allowed to start wiper when the Air filter Drive belt glass surface is dry; You should place You should regularly check and replace In order to make the engine and air the vehicle in the shade place to the element of air filter according to the conditioning compressor...

  • Page 159: Check Brake Pedal Stroke

    Vehicle maintenance 155 Brake pedal Fuse Fuse box Check brake pedal stroke Internal fuse box Replace fuse: Open the fuse box cover. The travel from starting to apply brake Internal fuse box is located at the right Observe whether fuse is blown out pedal for acting is known as the free bottom position of instrument panel.

  • Page 160: Engine Compartment Fuse Box156

    156 Vehicle maintenance Engine compartment fuse box The fuse box is located at the right side of engine compartment. Caution Fuse substitute or fuse with incorrect model and rated value can damage electrical system or cause fire disaster. Be sure to use the fuse that model and rated current are up to specification.

  • Page 161: Layout Of Internal Fuse Box

    Vehicle maintenance 157 Layout of internal fuse box Different vehicle models may have different internal element layouts inside the fuse box, it shall be based on the actual vehicles.

  • Page 162: Layout Of Engine Compartment Fuse Box

    158 Vehicle maintenance Layout of engine compartment fuse box Different vehicle models may have different internal element layouts inside the fuse box, it shall be based on the actual vehicle.

  • Page 163: Fog Inside Lamp

    Vehicle maintenance 159 Caution Caution Bulb replacement There is gas pressure existing Prohibit children from  Bulb replaced with in the halogen bulb. Be sure to contacting with bulb. professional skills and dedicated carefully and gently place and  Carefully dispose the used equipment.

  • Page 164: Bulb Specification

    160 Vehicle maintenance Bulb specification Serial No. Bulb Powerd X Quantity Remarks Front turn signal lamp/front position lamp/daytime running lamp Low-beam lamp/high-beam lamp Front fog lamp 55W X 2 Side turn signal lamp Front Reading Lamp...
  • Page 165 Vehicle maintenance 161 Serial No. Bulb Powerd X Quantity Remarks Rear Reading Lamp High mount stop lamp Rear brake lamp/position lamp 21W/5W X 2 P21W/W5W Rear turn signal lamp Rear license plate lamp Rear turn signal lamp...
  • Page 166 162 Vehicle maintenance Serial No. Bulb Powerd X Quantity Remarks Backup Lamp 16W X 2 W16W Rear position lamp 5W X 2 Luggage compartment lamp...
  • Page 167 Vehicle maintenance 163...

  • Page 168: Wheels And Tires

    164 Vehicle maintenance Note Check tire pressure at the time of Wheels and tires refueling or check at least once every Prohibit vehicle overload. Your vehicle’s original tires make month. Incorrect tire pressure will: Be sure to keep appropriate riding comfort, lifetime of tread pattern ...

  • Page 169: Tires And Wheels Protection

    Vehicle maintenance 165 Note Regular inspection of tire Built-in tread wear indication mark Be sure to check tire pressure Regularly inspect the following items: after tire being cooled to  Appearance damage, including: ambient temperature. Tire foreign materials, puncture, cuts, pressure measured after tire crack and lateral ridges.

  • Page 170: Tire Rotation

    166 Vehicle maintenance Note Caution Tire rotation Be sure to dispose the worn sure tire according local recommended wheel provisions on environmental wheel nuts / bolts. protection. Otherwise, it may cause the vehicle out of control and crash accident which cause personal injury or damage Caution your...

  • Page 171: Spare Tire, Jack, Tools And Triangle Warning Sign

    Vehicle maintenance 167 Spare tire, jack, tools and chapter of technical data for correct Failure follow these safety inflation pressure. precautions may cause your vehicle to triangle warning sign slip away from the jack, which may Do not use spare tires on other vehicles. cause serious injury.

  • Page 172: Jack Supporting Point

    168 Vehicle maintenance Jack supporting point Replacement of tires: 3. Place the jack directly below the lift point closest to the tire to be Front axle replaced. 1. Remove tools, jacks and spare tires. Check that the diagonal tires have As shown in the above figure, the jack been secured with blocks or stones.
  • Page 173 Vehicle maintenance 169 Caution Connect the jack rocker to the jack as shown above. Make sure to use proper nuts Turn the rocker clockwise to and bolts and tighten them to raise the jack slowly to ensure proper torque. that the jack head is firmly The used incorrect parts or pushed into the lift position.
  • Page 174 170 Vehicle maintenance Note Caution Caution Ensure that bracket is closely Don’t place jack and tools in Vehicle may become unstable fit with the side plane of passenger compartment and move, resulting in vehicle wheel. without any fixation. damage and personal injury Unfixed device may fly up and while using jack.

  • Page 175: Jumper Startup (Battery Died)

    Vehicle maintenance 171 of charged battery. (“-” mark on Caution Note battery case or terminal). Align jack Audio system is firstly closed  Connect the other end of this supporting position prior to starting vehicle by cable to body bonding of vehicle closest to wheel to be jumper method.
  • Page 176 172 Vehicle maintenance Note Caution Caution If it is unable to smoothly start Explosion hazard exists in  Prohibit disconnecting the vehicle without electricity, battery. You may be burned by battery without it is necessary to try starting acid battery liquor, electricity on vehicle.

  • Page 177: Towing Vehicle

    Vehicle maintenance 173 Caution Caution Towing vehicle Determine proper Don’t connect the negative (-) It is suggested to contact Authorized position of jumper cable, and terminal of battery while finally Workshop or professional trailing don’t wind the rotating units connecting to the vehicle to be service company if you intend to tow engine compartment.

  • Page 178: Tow Your Vehicle With Wheel Lifting Equipment

    174 Vehicle maintenance Tow your vehicle with wheel Tow your vehicle with wheel lifting Emergency trailing equipment. lifting equipment. When the tractor is not at the site under the emergency situation, the rope can be fixed at the front towing hook of the vehicle;...

  • Page 179: Front Towing Hook

    Vehicle maintenance 175 Caution Front towing hook after towing, place the towing hook back into the toolkit. The trailing speed shall not exceed 30Km/h, Note trailing speed shall When towing with rope, the exceed 40Km. For the long- towed vehicle may be out of distance trailing, you should control.

  • Page 180: Get Rid Of The Tripping Condition

    176 Vehicle maintenance Note Caution Get rid of the tripping When towing with rope, the When the vehicle is trapped in condition vehicle may be damaged. In the snow, mud pit and sandy When the vehicle is trapped in the snow, order to reduce the damage: soil, shall...

  • Page 181: Vehicle Maintenance

    Vehicle maintenance 177 Note Do not use the following materials for Vehicle maintenance cleaning: In order to avoid damaging Detergent transmission and other parts,  Carbon tetrachloride. following precautions When using the detergent or other  Gasoline. must followed when chemical products inside or outside the vehicle, suggestions...

  • Page 182: Inside The Vehicle

    178 Vehicle maintenance  Newspaper decorative Maintenance and cleaning inside Maintenance of seat belt. paper the vehicle The seat belts shall be kept clean and dry. Avoid the seat belt being polluted Appropriate cleaning methods by polishing agent, oil and chemical materials must be used for cleaning the Caution products, especially the battery fluid,...

  • Page 183: Maintenance And Cleaning Outside The Vehicle

    Vehicle maintenance 179 Glass surface Clean the outside of the front Maintenance cleaning windshield outside the vehicle Ensure that the window is clean to beneficial to reduce glare and improve Waxiness or other materials on the front Vehicle washing view. windshield and wiper blade may result in The best method for protecting the shake of blade during operation.

  • Page 184: Anticorrosion

    180 Vehicle maintenance Note Clean aluminum wheel and wheel Anticorrosion trim cover Forbid cleaning the vehicle The vehicles of SGMW are designed with household tableware In order to keep the original appearance to have anticorrosive capability. Most detergent. of wheel and wheel trim cover, you automobile parts are made of special Tableware detergent can wash should not make the dirt and brake dust...
  • Page 185 Vehicle maintenance 181  Sap. Maintenance at the body bottom  Bird droppings. Corrosive substances used for melting ice, snow and dust prevention will  Industrial dust. accumulate at the body bottom. The corrosion and rust will be accelerated if Clean the hazardous substances on these matters are not cleaned.

  • Page 186: Maintenance Procedure

    182 Maintenance procedure distributor of its pure accessories, nor General description Maintenance will be responsible for all the resulting procedure This chapter introduces consequences. In the meantime, any maintenance plan of the vehicle, which fault or damage caused directly or General description ....
  • Page 187 Maintenance procedure 183  Repeated short distance (less than Operating conditions 10km) driving. You should comply with the specified  Idle or low speed driving under the regular maintenance plan. See the stop-and-go traffic conditions. "Routine maintenance specification sheet" "Extraordinary ...

  • Page 188: Technical Data

    184 Technical data Vehicle identification Vehicle identification number Technical data inside the engine compartment Vehicle identification number Vehicle identification ..... 184 (VIN) Vehicle identification number Your vehicle has three common legal (VIN) ........184 vehicle identification marks. Vehicle identification number Identification number on the instrument inside the engine panel part compartment ......184...

  • Page 189: Technical Data 185

    Technical data 185 Vehicle identification number Engine number sign Engine serial number is near the flywheel close with the engine cylinder This plate is a paper plate and is body. located on the door frame at the front passenger side.

  • Page 190: Main Performance Parameters Of The Engine

    186 Technical data Technical Data Main performance parameters of the engine Engine model: N15T Item Unit Transmission Model: CTF 25 Four stroke, water-cooled, inline, 16 valve, double overhead camshaft, belt Engine type variable camshaft phase, timing chain, turbo, electronically controlled gasoline injection, electronic ignition Cylinder diameter X mm x mm...

  • Page 191: Main Quality Parameters Of Vehicle

    Technical data 187 Main quality parameters of vehicle Parameters Item Unit 1.5L Turbo - CVT Seating Capacity Person Curb weight 1580 Gross Vehicle Weight (GVW) 1950 Main liquid parameters Parameters Point Spesifikasi 1.5L Turbo - CVT Fuel Grade #92 or above 52 L Engine Oil SM/GF-4 5W-30...

  • Page 192: Main Dimensions Parameters Of Vehicle

    188 Technical data Main dimensions parameters of vehicle Item Unit Parameter value Total length 4655 Total width 1835 Total height (zero load) 1760 Wheel base 2750 Tire inflation pressure (cold condition) Tire inflation pressure (unit: kPa) Tire model Item Without loaded Fully loaded Front tire 220-240...
  • Page 193 Technical data 189...
  • Page 194 190 Technical data List of following parts The accessory part list ..191 Following tool ......192...

  • Page 195: List Of Following Parts 191

    List of following parts 191 The accessory part list Serial Name Quantity Remarks Vehicle audio system operating instructions Distributed as per the vehicle model. Following kits (including: “Owner manual”, “maintenance and warranty manual” and “Quick reference manual”) Following tool Located near spare tire Triangle warning sign First-aid packet...
  • Page 196 192 List of following parts Following tool Jack Jack rocker Screw driver Wheel nut wrench Towing hook...
  • Page 197 List of following parts 193 Note...

Table of Contents

Save PDF
