Industrial Electronic Devices
User Manual
Revision 1.000
English
IEC 61850 Server / Modbus TCP Slave -
Converter
(Order Code: HD67736-A1 )
For Website information:
www.adfweb.com?Product=HD67736
For Price information:
www.adfweb.com?Price=HD67736-A1
Benefits and Main Features:
Very easy to configure
Triple Electrical isolation
Temperature range: -40°C/+85°C (-40°F/+185°F)
User Manual
ADFweb.com S.r.l.
User Manual IEC 61850 Server / Modbus TCP Slave
Document code: MN67736_ENG
For other IEC 61850 server products see also the following link:
Converter IEC 61850 Server to
www.adfweb.com?Product=HD67733
www.adfweb.com?Product=HD67734
www.adfweb.com?Product=HD67735
www.adfweb.com?Product=HD67737
www.adfweb.com?Product=HD67738
www.adfweb.com?Product=HD67739
www.adfweb.com?Product=HD67740
www.adfweb.com?Product=HD67741
www.adfweb.com?Product=HD67742
www.adfweb.com?Product=HD67743
www.adfweb.com?Product=HD67744
www.adfweb.com?Product=HD67745
www.adfweb.com?Product=HD67746
www.adfweb.com?Product=HD67747
www.adfweb.com?Product=HD67748
www.adfweb.com?Product=HD67749
www.adfweb.com?Product=HD67750
www.adfweb.com?Product=HD67751
www.adfweb.com?Product=HD67B82
www.adfweb.com?Product=HD67752
www.adfweb.com?Product=HD67753
www.adfweb.com?Product=HD67754
www.adfweb.com?Product=HD67755
www.adfweb.com?Product=HD67756
Do you have your customer protocol? Then go to:
www.adfweb.com?Product=HD67003
Do you need to choose a device? Do you want help?
www.adfweb.com?Cmd=helpme
Revision 1.000
Page 1 of 25
(Modbus Master)
(Modbus Slave)
(Modbus TCP Master)
(BACnet Master)
(BACnet Slave)
(CAN)
(CANopen)
(DeviceNet Master)
(DeviceNet Slave)
(EtherNet/IP Master)
(EtherNet/IP Slave)
(J1939)
(KNX)
(MQTT)
(NMEA 0183)
(NMEA 2000)
(PROFIBUS Master)
(PROFIBUS Slave)
(PROFINET Master)
(PROFINET Slave)
(SNMP Manager)
(SNMP Agent)
(Serial)
(Ethernet)
Advertisement
Table of Contents
Related Manuals for Modbus HD67736-A1
Summary of Contents for Modbus HD67736-A1
- Page 1 User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 1 of 25 Industrial Electronic Devices User Manual Revision 1.000 English IEC 61850 Server / Modbus TCP Slave - Converter (Order Code: HD67736-A1 ) For other IEC 61850 server products see also the following link:...
-
Page 2: Table Of Contents
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 2 of 25 Industrial Electronic Devices INDEX: UPDATED DOCUMENTATION: Page Dear customer, we thank you for your attention and we remind you that INDEX you need to check that the following document is:... -
Page 3: Security Alert
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 3 of 25 Industrial Electronic Devices SECURITY ALERT: ENERAL NFORMATION To ensure safe operation, the device must be operated according to the instructions in the manual. When using the device, legal and safety regulation are required for each individual application. -
Page 4: Example Of Connection
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 4 of 25 Industrial Electronic Devices EXAMPLE OF CONNECTION: ADFweb.com S.r.l. -
Page 5: Connection Scheme
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 5 of 25 Industrial Electronic Devices CONNECTION SCHEME: Figure 1: Connection scheme for HD67736-A1 ADFweb.com S.r.l. -
Page 6: Characteristics
Page 6 of 25 Industrial Electronic Devices CHARACTERISTICS: The HD67736-A1 are IEC 61850 / Modbus TCP Slave - Converters. It allows for the following characteristics: Isolation between Ethernet - Power Supply; Two-directional information between IEC 61850 bus and Modbus TCP bus;... -
Page 7: Power Supply
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 7 of 25 Industrial Electronic Devices POWER SUPPLY: The devices can be powered at 8…24V AC and 12…35V DC. For more details see the two tables below. -
Page 8: Function Modes
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 8 of 25 Industrial Electronic Devices FUNCTION MODES: The device has got two function modes depending on the position of the ‘Dip1 of Dip-Switch A’: The first, with ‘Dip1 of Dip-Switch A’... -
Page 9: Leds
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 9 of 25 Industrial Electronic Devices LEDS: The device has got six LEDs that are used to give information about the functioning status. The various meanings of the LEDs are described in the table below. -
Page 10: Ethernet
IEC 61850 and Modbus TCP connection and the updating of the converter must be made using Connector3 and/or Connector4 of the HD67736-A1 with at least a Category 5E cable. The maximum length of the cable should not exceed 100m. The cable has to conform to the T568 norms relative to connections in cat.5 up to 100 Mbps. -
Page 11: Use Of Compositor Sw67736
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 11 of 25 Industrial Electronic Devices USE OF COMPOSITOR SW67736: To configure the Converter, use the available software that runs with Windows called SW67736. It is downloadable on the site www.adfweb.com and its operation is described in this document. -
Page 12: New Configuration / Open Configuration
Configuration” button creates the folder which contains the entire device’s configuration. A device’s configuration can also be imported or exported: To clone the configurations of a programmable “IEC 61850 Server / Modbus TCP Slave - Converter” in order to configure another device in the same manner, it is necessary to maintain the folder and all its contents;... -
Page 13: Software Options
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 13 of 25 Industrial Electronic Devices SOFTWARE OPTIONS: By pressing the “Settings” ( ) button there is the possibility to change the language of the software and check the updatings for the compositor. - Page 14 User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 14 of 25 Industrial Electronic Devices In the section “Software Settings”, it is possible to enable/disable some keyboard’s commands for an easier navigation inside the tables contained in the different sections of the software.
-
Page 15: Set Communication
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 15 of 25 Industrial Electronic Devices SET COMMUNICATION: This section define the fundamental communication parameters of two buses, IEC 61850 and Modbus TCP. By Pressing the “Set... - Page 16 The means of the fields for “Modbus TCP Slave” are: In the fields “IP Address” the IP address for Modbus TCP side of the converter is defined; In the fields “SubNet Mask” the SubNet Mask for Modbus TCP side of the converter is defined;...
-
Page 17: Iec 61850 Access
“Start Bit” the starting bit of the byte of the field “Position” is defined; In the field “Conversion” the conversion of the data is defined. This option is used to convert the data format between Modbus and IEC 61850; In the field “Molt. -
Page 18: Tls Known Certificate
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 18 of 25 Industrial Electronic Devices TLS KNOWN CERTIFICATE: Figure 5: “TLS Known Certificate” window By pressing the “TLS Known Certificate” button from the Main Window of SW67736 (Fig. 2) the “Definition the list of Known Certificates”... -
Page 19: Update Device
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 19 of 25 Industrial Electronic Devices UPDATE DEVICE: By pressing the “Update Device” button, it is possible to load the created Configuration into the device; and also the Firmware, if necessary. This by using the Ethernet port. - Page 20 User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 20 of 25 Industrial Electronic Devices Note: When you receive the device, for the first time, you also have to update the Firmware in the HD67736 device.
-
Page 21: Modbus Map
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 21 of 25 Industrial Electronic Devices MODBUS MAP: Data in reading: Type Address Function Description Input Bytes 0-1 of internal array (Position) Input Register Input Bytes 2-3 of internal array (Position) -
Page 22: Mechanical Dimensions
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 22 of 25 Industrial Electronic Devices MECHANICAL DIMENSIONS: Figure 8: Mechanical dimensions scheme for HD67736-A1 ADFweb.com S.r.l. -
Page 23: Ordering Informations
1: Removable 5mm Screw Terminal Enclosure Type A: 1M, 35mm DIN Rail mounting Device Family HD67736: IEC 61850 Server / Modbus TCP Slave - Converter Order Code: HD67736-A1 IEC 61850 Server / Modbus TCP Slave - Converter ACCESSORIES: Order Code: AC34011 35mm Rail DIN - Power Supply 220/240V AC 50/60Hz –... -
Page 24: Disclaimer
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 24 of 25 Industrial Electronic Devices DISCLAIMER: All technical content within this document can be modified without notice. The content of the document is a under continual renewal. -
Page 25: Warranties And Technical Support
User Manual IEC 61850 Server / Modbus TCP Slave Document code: MN67736_ENG Revision 1.000 Page 25 of 25 Industrial Electronic Devices WARRANTIES AND TECHNICAL SUPPORT: For fast and easy technical support for your ADFweb.com SRL products, consult our internet support at www.adfweb.com.
