Backyard Discovery GABLE Assembly Manual
  1. Manuals
  2. Brands
  3. Backyard Discovery Manuals
  4. Outdoor Storage
  5. GABLE
  6. Assembly manual
Backyard Discovery GABLE Assembly Manual

Backyard Discovery GABLE Assembly Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
16770-
CB
STOP!
STOP!
Call Us First!
DO NOT RETURN TO STORE.
For immediate help with assembly or product information
call our toll free number:
1-888-827-9056
or email:
customerservice@backyardproductsllc.com
Our staff is ready to provide assistance
April through October M-F 8:00 AM to 4:30 PM EST
Saturday 8:30 AM to 4:30 PM EST
November through March M - F 8:00 AM to 5:00 PM EST

Advertisement

loading

Related Manuals for Backyard Discovery GABLE

Summary of Contents for Backyard Discovery GABLE

  • Page 1 16770- STOP! STOP! Call Us First! DO NOT RETURN TO STORE. For immediate help with assembly or product information call our toll free number: 1-888-827-9056 or email: customerservice@backyardproductsllc.com Our staff is ready to provide assistance April through October M-F 8:00 AM to 4:30 PM EST Saturday 8:30 AM to 4:30 PM EST November through March M - F 8:00 AM to 5:00 PM EST...
  • Page 2 (This page intentionally left blank.)

  • Page 3: Assembly Manual

    16770-CB 07/01/2020 ASSEMBLY MANUAL GABLE 10' x 8' (305 x 244) BUILDING SIZE ACTUAL FLOOR SIZE 10' x 8' (305 x 244 cm) BASE MODEL 10' x 7' 8-5/8" (305 x 235,3 cm) ADD ONE 10' x 4' 10' x 12' (305 x 365,8 cm) 10' x 11' 8-5/8"...
  • Page 4 TOOLS Required Optional K Phillips K Tool Belt/ K Utility Knife Screwdriver Nail Pouch K Shingle Blades K Drill / Driver K Tin Snips K 3/8" Drill Bit K Caulk Gun (for drip edge) K #2 Philips Drive Bit K Chalk Line K Hammer K Paint Tools K Level...

  • Page 5: Parts List

    PARTS IDENTIFICATION AND SIZES WOOD SIZE CONVERSION CHART Part identification is Treated lumber is stamped: Nominal Board Size Actual Size stamped on some parts. 2 x 4 ....1-1/2" x 3-1/2" (3,8 x 8,9 cm) 1 x 4 ....3/4" x 3-1/2" (1,9 x 8,9 cm) 2 x 3 ....1-1/2"...
  • Page 6 WALL PANEL & DOORS PARTS LIST LEFT RIGHT 3/8 x 48 x 72" (1 x 122 x 183 cm) LEFT DOOR RIGHT DOOR ROOF PANELS 48" x 96" 19" x 96" (122 x 244 cm) (48 x 244 cm) Roof panels are 7/16"...
  • Page 7 ROOF PANELS 48" x 96" 19" x 96" (122 x 244 cm) (48 x 244 cm) Roof panels are 7/16" (11 mm) thick. 2" (5,0 cm) 1 lb. of 2" (5,0 cm) 48" x 96" 19" x 48" (122 x 244 cm) (48 x 122 cm) Roof panels are 7/16"...

  • Page 8: Additional Materials

    ADDITIONAL MATERIALS FOUNDATION OR FLOOR MATERIALS • Your shed kit does not include a wood oor frame or oor panel materials. • See page 8 for the additional oor panel sizes and quantities required. • This shed does not include any leveling materials. •...
  • Page 9 CONCRETE FOUNDATION If you choose to install your kit on a concrete slab refer to the diagram below. Attach the sill plates on the foundaton as shown, and continue on to page 21. Treated Sill Plate Caulk between sill plate and concrete.
  • Page 10 FLOOR FRAME (Not Included) You may need treated 2 x 4" boards cut to size and nails to complete your floor. Floor panel sizes and quantities are shown below. MUST be treated lumber. 2 x 4 x 48" (5 x 10 x 122 cm) 2 x 4 x 72"...
  • Page 11 OPTIONAL WOOD FRAME FLOOR LEVELING OPTIONS There are multiple ways to level your floor frame. Our recommended leveling method is shown below. Leveling materials are not included in this kit. PREFERRED METHOD - 4x4 TREATED RUNNERS (Typical for 10' x 12' Kit) Seam Runners are generally 4x4 Runners...
  • Page 12 10' x 8' FLOOR FRAME (Not Included) PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 72" (5 x 10 x 183 cm) Treated Wood 2 x 4 x 89-1/2" (5 x 10 x 227 cm) Treated Wood 2 x 4 x 48" (5 x 10 x 122 cm) Treated Wood BEGIN Orient parts as shown on flat surface.
  • Page 13 10 x 12' FLOOR FRAME (Not Included) PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 72" (5 x 10 x 183 cm) 2 x 4 x 48" (5 x 10 x 122 cm) 2 x 4 x 45" (5 x 10 x 114,3 cm) You will build two floor sections.
  • Page 14 10 x 16' FLOOR FRAME (Not Included) PARTS REQUIRED: 3" (7,6 cm) 2 x 4 x 72" (5 x 10 x 183 cm) 2 x 4 x 48" (5 x 10 x 122 cm) 2 x 4 x 93 " (5 x 10 x 236,2 cm) You will build two floor sections.
  • Page 15 LEVEL AND SQUARE FLOOR FRAME Before attaching fl oor decking, it is important to level and square the fl oor frame. A level and square fl oor frame is required to correctly construct your shed. BEGIN See page 9 for the preferred fl oor leveling method. Use level and check the frame is level before applying fl oor panels.
  • Page 16 10 x 12' FLOOR FRAME (Not Included) 3" (7,6 cm) Put both fl oor sections together and attach as shown using 3" nails. FINISH You have fi nished your fl oor frame. Proceed to level and square frame. (4) Nails per side, stagger pattern.
  • Page 17 10 x 16' FLOOR FRAME (Not Included) 3" (7,6 cm) Put both fl oor sections together and attach as shown using 3" nails. FINISH You have fi nished your fl oor frame. Proceed to level and square frame. (4) Nails per side, stagger pattern.
  • Page 18 10' x 8' FLOOR PANELS (Not Included) PARTS REQUIRED: 2" (5 cm) FLOOR PANELS NOT INCLUDED. SEE PAGE 8 FOR PANEL SIZES 48" x 92-5/8" AND QUANTITIES. (122 x 235,3 cm) Ensure your floor frame is square by installing one panel and squaring frame. BEGIN Attach the 48 x 92-5/8"...
  • Page 19 10' x 8' FLOOR PANELS (Not Included) PARTS REQUIRED: 2" (5 cm) FLOOR PANELS NOT INCLUDED. SEE PAGE 8 FOR PANEL SIZES 48" x 92-5/8" 5/8 x 23-7/8 x 92-5/8" AND QUANTITIES. (122 x 235,3 cm) (1,6 x 61 x 235 cm) Continue installing panels with rough side up (painted grid lines).
  • Page 20 10' x 12' FLOOR PANELS (Not Included) PARTS REQUIRED: 2" (5 cm) FLOOR PANELS NOT INCLUDED. SEE PAGE 8 48" x 48" (122 x 122 cm) FOR PANEL SIZES AND QUANTITIES. BEGIN Attach the 48 x 48" panel with the rough side up (painted-grid lines side) on Section 2 with the 48"...
  • Page 21 10' x 12' FLOOR PANELS (Not Included) PARTS REQUIRED: 2" (5 cm) FLOOR PANELS NOT INCLUDED. SEE PAGE 8 FOR PANEL SIZES 48" x 48" 5/8 x 23-7/8 x 48" AND QUANTITIES. (122 x 122 cm) (1,6 x 61 x 122 cm) Continue installing panels with rough side up (painted grid lines) as shown.
  • Page 22 10' x 16' FLOOR PANELS (Not Included) PARTS REQUIRED: 2" (5 cm) FLOOR PANELS NOT INCLUDED. SEE PAGE 8 FOR PANEL SIZES 48" x 96" (122 x 244 cm) AND QUANTITIES. BEGIN Position the 48 x 96" panel with the rough side up (painted-grid lines side) with the 96"...
  • Page 23 10' x 16' FLOOR PANELS (Not Included) PARTS REQUIRED: 2" (5 cm) FLOOR PANELS NOT INCLUDED. SEE PAGE 8 FOR PANEL SIZES 5/8 x 48 x 96" 5/8 x 23-7/8 x 96" AND QUANTITIES. (1,6 x 122 x 244 cm) (1,6 x 61 x 244 cm) Continue installing panels with rough side up (painted grid lines).
  • Page 24 IMPORTANT! I M P O R T A N T ! Check the floor frame is level after installing floor panels. Re-level if needed. • The floor should used as a stable work surface for wall construction. HINT: • Organize your assembly procedure during the build process to avoid over-handling of the walls.
  • Page 25 RAFTER ASSEMBLY JIG PARTS REQUIRED: 1-1/4" (3,2 cm) 1 x 3 x 7-1/2" (2,5 x 7,6 x 19 cm) ¸ BEGIN Build a Jig to ensure all Rafters are assembled the same. Mark a straight line on the Floor from corner to corner (Fig. A) or on sill plates to fi t measurements (Fig.
  • Page 26 RAFTERS PARTS REQUIRED: 2" (5 cm) x6/x10/x14 6 x 24" (15 x 61 cm) x6/x10/x14 2 x 4 x 65-7/8" (5 x 10 x 167 cm) ¸ BEGIN Place two rafter halves CV on fl oor jig. You will assemble (4) rafters. Nail gusset onto rafter using 2"...
  • Page 27 BACK WALL FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 46-1/4" (5 x 7,6 x 117,5 cm) 2 x 3 x 77" (5 x 7,6 x 196 cm) 2 x 3 x 94-1/2" (5 x 7,6 x 240 cm) BEGIN Orient parts on edge on floor as shown.
  • Page 28 BACK WALL FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 46-1/4" (5 x 7,6 x 117,5 cm) Orient parts on edge on fl oor as shown. Use two 3" screws at middle connection. FINISH You have fi nished building your back wall frame. 48-3/4"...
  • Page 29 BACK WALL PANELS PARTS REQUIRED: 2" (5 cm) 3/8 x 48 x 84" (1 x 122 x 213,4 cm) 3/4" GAUGE BLOCK BEGIN Place LEFT panel on back frame as shown with primed side facing up. Use a 3/4" gauge block at edges of panel. Nail using 2"...
  • Page 30 BACK WALL PANELS PARTS REQUIRED: 2" (5 cm) 3/8 x 48 x 84" 3/4" GAUGE (1 x 122 x 213,4 cm) BLOCK Place RIGHT panel on back frame as shown with primed side facing up. Use a 3/4" gauge block at edges of panel. Nail using 2"...
  • Page 31 WING WALL PANELS PARTS REQUIRED: 1-1/4" (3 cm) RIGHT LEFT 2 x 3 x 72" (5 x 7,6 x 183 cm) BEGIN You will assemble TWO RIGHT and TWO LEFT wing walls. Place OY on floor. Place a wing wall panel primed side down onto OY (Fig.
  • Page 32 BACK WALL PANELS PARTS REQUIRED: 2" (5 cm) Pre-assembled LEFT Pre-assembled RIGHT Place wing wall assemblies onto frame with bottom of panels fl ush. Nail left and right wing wall assemblies onto back wall frame Do not nail using 2" nails 6" apart. in groove.
  • Page 33 LEFT BEGIN Place left gable panel onto frame primed side up and fl ush to left panel. NOTE: Panel grooves will not align. Use a 3/4" gauge block at edge of panel. Nail using 2" nails along edge as shown.
  • Page 34 FRONT WALL FRAME PARTS REQUIRED: 3" (7,6 cm) 2 x 3 x 22-1/8" (5 x 7,6 x 56 cm) 2 x 3 x 77" (5 x 7,6 x 196 cm) 2 x 3 x 94-1/2" (5 x 7,6 x 240 cm) BEGIN Lay out two PB, one PR and one LT on edge on fl oor.
  • Page 35 FRONT WALL PANELS PARTS REQUIRED: 2" (5 cm) 3/4" GAUGE BLOCK BEGIN Place LEFT panel on front frame as shown with primed side up. Use a 3/4" gauge block on edges of panel. Nail panel to frame with 2" nails 6" apart. Do not nail in groove.
  • Page 36 FRONT WALL PANELS PARTS REQUIRED: 2" (5 cm) 3/4" GAUGE BLOCK Place RIGHT panel on front frame primed side up. Use a 3/4" gauge block on edges of panel. Nail panel to frame with 2" nails 6" apart. Do not nail in groove.
  • Page 37 FRONT WALL PANELS PARTS REQUIRED: 2" (5 cm) Pre-assembled LEFT Pre-assembled RIGHT Place wing wall panels onto frame with bottom of panels fl ush. Nail left and right wing wall assemblies using 2" nails 6" apart. Do not nail in groove. FINISH You have fi nished attaching your wing walls.
  • Page 38 SIDE WALL FRAMES PARTS REQUIRED: 3" (7,6 cm) 7/16 x 2-1/2 x 24-3/4" (1,1 x 6,4 x 62,9 cm) 2 x 3 x 69" (5 x 7,6 x 175 cm) 2 x 3 x 92-5/8" (5 x 7,6 x 235,3 cm) BEGIN If building 10' x 12' kit goto page 40.
  • Page 39 10' x 8' SIDE WALL FRAME- SOFFIT PARTS REQUIRED: 1-1/4" (3,2 cm) 3/8 x 5 x 93-1/4" (0,9 x 12,7 x 236,9 cm) Place panel onto 2 x 3 with primed side against 2 x 3 (Fig A) Keep panel flush along entire edge of 2 x 3 top plate (Fig A). Attach soffit panel flush to 2 x 3 (Fig A) and with 3/8"...
  • Page 40 10' x 8' SIDE WALL PANELS PARTS REQUIRED: 2" (5 cm) 3/4" GAUGE BLOCK 3/8 x 48 x 72" (1 x 122 x 183 cm) Ensure your wall frame is square by installing one panel and squaring frame. Place the 48 x 72" panel onto wall frame with primed side up as shown. Note the lip and square edges.
  • Page 41 10' x 8' SIDE WALL PANELS PARTS REQUIRED: 2" (5 cm) 3/8" x 48" x 72" (1 x 122 x 183 cm) Place 48" panel on frame as shown with primed side facing up. NOTE THE SQUARE AND LIP EDGES. Do not nail in groove.
  • Page 42 10' x 12' SIDE WALL FRAMES PARTS REQUIRED: 3" (7,6 cm) 7/16 x 2-1/2 x 24-3/4" (1,1 x 6,4 x 62,9 cm) 7/16 x 2-1/2 x 48 (1,1 x 6,4 x 122 cm) 2 x 3 x 69" (5 x 7,6 x 175 cm) 2 x 3 x 48"...
  • Page 43 10' x 12' SIDE WALL FRAME- SOFFIT PARTS REQUIRED: 1-1/4" (3,2 cm) 3/8 x 5 x 48" (0,9 x 12,7 x 122 cm) 3/8 x 5 x 93-1/4" (0,9 x 12,7 x 236,9 cm) Place panels onto 2 x 3 with primed side against 2 x 3 as shown (Fig A) Keep panel flush along entire edge of 2 x 3 top plate (Fig A).
  • Page 44 10' x 12' SIDE WALL PANELS PARTS REQUIRED: 2" (5 cm) 3/4" GAUGE BLOCK 3/8 x 48 x 72" (1 x 122 x 183 cm) Ensure your wall frame is square by installing one panel and squaring frame. Place the 48 x 72" panel onto wall frame with primed side up as shown. Note the lip and square edges.
  • Page 45 10' x 12' SIDE WALL PANELS PARTS REQUIRED: x148 2" (5 cm) 3/8" x 48" x 72" (1 x 122 x 183 cm) Place 48" panels on frame as shown with primed side facing up. NOTE THE SQUARE AND LIP EDGES. Do not nail in groove.
  • Page 46 10' x 16' SIDE WALL FRAMES PARTS REQUIRED: 3" (7,6 cm) 7/16 x 2-1/2 x 24-3/4" (1,1 x 6,4 x 62,9 cm) 7/16 x 2-1/2 x 48" (1,1 x 6,4 x 122 cm) 2 x 3 x 69" (5 x 7,6 x 175 cm) 2 x 3 x 48"...
  • Page 47 10' x 16' SIDE WALL FRAME- SOFFIT PARTS REQUIRED: 1-1/4" (3,2 cm) 3/8 x 5 x 48" (0,9 x 12,7 x 122 cm) 3/8 x 5 x 93-1/4" (0,9 x 12,7 x 236,9 cm) Place panels onto 2 x 3 with primed side against 2 x 3 as shown (Fig A) Keep panel flush along entire edge of 2 x 3 top plate (Fig A).
  • Page 48 10' x 16' SIDE WALL PANELS PARTS REQUIRED: 2" (5 cm) 3/4" GAUGE BLOCK 3/8 x 48 x 72" (1 x 122 x 183 cm) Ensure your wall frame is square by installing one panel and squaring frame. Place the 48 x 72" panel onto wall frame with primed side up as shown. Note the lip and square edges.
  • Page 49 10' x 16 ' SIDE WALL PANELS PARTS REQUIRED: x238 2" (5 cm) 3/8" x 48" x 72" (1 x 122 x 183 cm) Place 48" panels on frame as shown with primed side facing up. NOTE THE SQUARE AND LIP EDGES. Do not nail in groove.

  • Page 50: Back Wall Installation

    BACK WALL INSTALLATION PARTS REQUIRED (TEMPORARY): 3" (7,6 cm) 69" Door Stiffener (175,3 cm) 2" (5 cm) BEGIN Center back wall assembly on the 120" (305 cm) fl oor dimension. Use OO as a temporary brace. Secure with two 3" screws. 3"...
  • Page 51 SIDE WALLS INSTALLATION x4/8/12 3" (7,6 cm) 3" (7,6 cm) x30/39/48 2" (5 cm) Additional fasteners needed for 10' x 12' kit or 10' x 16' kit. Same instructions apply. BEGIN Stand right sidewall on floor. It is important to secure the sidewall in the following order: Soffit Center sidewall on floor front to Panel...
  • Page 52 FRONT WALL INSTALLATION 3" (7,6 cm) 2" (5 cm) BEGIN Stand frontwall on floor. It is important to secure the frontwall in the following order. Soffit 3/8" (0,9 cm) OVERLAP Panel Center frontwall on floor side-to-side. Trim Panel The sidewall soffit will overlap the Fig.
  • Page 53 GABLE TRIM PARTS REQUIRED: 1-1/4" (3 cm) 2 x 3 x 58" (5 x 7,6 x 147,3 cm) ¸ BEGIN Position one CDD fl ush to front panel edge and center on right edge of groove (Fig. A). Attach trim with eight 1-1/4" screws from inside. Install two screws at seam (Fig.
  • Page 54 PARTS REQUIRED: 3/4" (1,9 cm) x11 11/16 x 2-1/2 x 60-5/8" (1,7 x 6,3 x 154 cm) ¸ BEGIN Clamp or hold trim XMA onto gable panel seam and up against gable trim. Ensure XMA is level. GABLE TRIM SEAM Flush...
  • Page 55 TRIM / ENDCAPS PARTS REQUIRED: 1-1/4" (3,2 cm) 1 x 3 x 7-1/2" (2,5 x 7,6 x 19 cm) RIGHT PAINTED RED 3/4 x 5-1/8 x 8-3/8" (1,9 x 13 x 21,3 cm) LEFT PAINTED GREEN ¸ BEGIN Glue 7-1/2" boards onto endcaps, and fasten with 1-1/4" screws, as shown. Repeat steps to build two more endcaps.
  • Page 56 RAFTERS PARTS REQUIRED: 3" (7,6 cm) pre-assembled 2" (5 cm) ¸ BEGIN Locate rafters directly over studs and fl ush to overhang in wall frame (Fig. A). Check that you have the measurements shown. Screw through soffi t panel into rafters using one 2"...
  • Page 57 Fig. C panel side-to-side until the top corner is flush to the peak (Fig. C) and there is 1/8" measurement to the gable trim (Fig. D). You may need to move your backwall to get the 1/8" measurement. Secure panel with two 2"...
  • Page 58 6" (15 cm) Attach the lower roof panels flush to the upper panels and with a 1/8" Fig. F measurement at the gable trim (Fig.G). Nail the roof panel using 2" nails 6" apart on edges and 12" apart inside panel. 19"...
  • Page 59 TRIM PARTS REQUIRED: 2" (5 cm) 1 x 3 x 94-3/4" (2,5 x 7,6 x 240,6 cm) ¸ BEGIN Attach fascia trim fl ush under roof panel (Fig. A) and endcaps at ends of rafters (Fig. B) using 2" (5 cm) nails as shown. Repeat steps to attach fascia trim on both sides.
  • Page 60 DOORS PARTS REQUIRED: 1-1/4" (3 cm) 69" Door Stiffener (175,3 cm) 2" (5 cm) HINT: Look for 3/8" SPACER 3" (7,6 cm) attached to doors. 5/8 x 3 x 72" (1,6 x 7,6 x 183 cm) Left Door Right Door BEGIN 3/8"...
  • Page 61 DOORS PARTS REQUIRED: 3" (7,6 cm) 69" Door Stiffener (175,3 cm) Attach temporary support OO as a ledger board fl ush under wall panels for doors to rest on, using three 3" screws (Fig. A). Flush against wall panels. Fig. A Center doors on right edge of groove as shown (Fig.
  • Page 62 DOOR PARTS REQUIRED: 2" (5 cm) x8 3/4" (1,9 cm) x52 5/8 x 3 x 72" (1,6 x 7,6 x 183 cm) 64" Metal Threshold BEGIN Secure hinge boards from inside using 3/4" screws as shown (Fig. A). Reinforce the door trim using 3/4" screws through door panel into trim (Fig. A). Locate screws as shown in Fig.
  • Page 63 DOOR WEATHERSTRIP PARTS REQUIRED: 2" (5 cm) 69" Door Stiffener (175,3 cm) BEGIN With left door closed, center a weatherstrip OO vertically on the left door in the door opening (Fig. A). OO will offset the left door 1" OUT past the door trim 1"...

  • Page 64: Door Hardware

    DOOR HARDWARE PARTS REQUIRED: 3/8" (9 mm) Drill Bit 3/4" (1,9 cm) 3/4" (1,9 cm) BEGIN Mount barrel bolt fl ush at top of OO on left door using 3/4" screws as shown (Fig A). With door closed mark hole location for bolt to extend into. HINT: Extend bolt to leave a mark in wood.
  • Page 65 DOOR TRIM DOOR TRIM PARTS REQUIRED: PARTS REQUIRED: 3/4" (19 mm) 3/4" (1,9 cm) 5/8 x 4 x 14" (1,6 x 10 x 35,6 cm) 5/8 x 3 x 14" (1,6 x 7,6 x 35,5 cm) BEGIN Position parts on lower pane of Door Panel, as shown. Attach each using two 3/4"...
  • Page 66 - NOT INCLUDED - • Install over roof felt or over roof felt on gable side and under roof felt on eave side (Fig. A). • Do not use nails on side of drip edge that hangs over side of building.
  • Page 67 SHINGLES - NOT INCLUDED - • Follow directions provided by manufacturer and these instructions. Familiarize yourself with a 3-Tab Shingle. Notch Notch SHINGLE NAIL PATTERN 1/2 " 1" Sealing Str 1" (1,3 cm) (2,5 cm) (2,5 cm) Half A Rain Slot Full Rain Slot NAILS NEVER DRIVE FASTENERS INTO OR ABOVE SEALING STRIPS.
  • Page 68 SHINGLES continued... Beginning at front of shed, install first row of shingles with notch at 1" past roof edge or flush with drip edge. Roof Deck FRONT OF BACK OF SHED SHED 1" (2,5 cm) Flush with starter row. Notch - or - Drip Edge Flush with starter row.
  • Page 69 SHINGLES continued... Continue installing rows of shingles to the peak. At the peak make sure there is a maximum of 5" or less to the rain slot, as shown below. If shingles overlap at ridge cut to peak with a utility knife. 5"...
  • Page 70 SHINGLES - RIDGE CAP • You will finish off the top of the roof with a ridge cap made from shingles. BEGIN Cut shingles into THREE pieces. Hint: Use cut-off pieces first. 2" 2" (5 cm) (5 cm 2" 2" 2"...
  • Page 71 SHINGLES - RIDGE CAP continued... Continue installing ridge cap to back of roof. Make sure there is 4" between the shingle-color and edge of shingles. Trim cap off fl ush to shingles When you have 4" minimum of shingle color cut one piece to cap your roof. Install fl ush to shingles.
  • Page 72 LIMITED CONDITIONAL WARRANTY* Backyard Storage Solutions, LLC warrants the following: Every product is warranted from defects in workmanship and manufacturing for 1 year. All accessories, hardware and metal components are warranted for 2 years. All Oriented Strand Board (OSB) is warranted for 2 years Siding and Trim is warranted for 10 years.
