Oway WB3100 User Manual

Oway Portable Interactive Whiteboard User Guide
Caution: Before Setting Your Portable Interactive Whiteboard, Please Check All the Parts and
Read The User Guide
Step1. Confirm each
component
of the Portable IWB is
present.
Step4. Calibrating:
Click the "Calibrate" on the notify menu of SmartIWB, make sure the red laser aim in the middle of the projection area.
Please see below picture.
Click the 15(or 4)points in order, don't move the e-pen until the point disappeared.
Check the calibration with the e-pen (Look the e-pen and the mouse pointer)
Step2. Install: The device is
connected the PC by USB cable;
The projector is connected the PC
by VGA Cable
For WB3100
Step3. Install Driver: Insert
the CD and Install the
driver, Click "SmartIWB"
icon in the desktop
