(55 Inch) User Manual
Product Model：JJ-F67-T
Copyright ©2020 PQ Labs.Inc
1
Packing List
Main Components
Accessories
HDMI Cable ×1
Optional (For Intel NUC Package only)
NUC Computer Bracket ×1
Ver. 1.0.3
Touch Display ×1
HUB ×1
M6 Bolt ×4
Remote Control ×1
Stylus Pen ×2
Power Cable ×1
(Remote Control)
M6*15 Screws ×4
NUC PC × 1
Advertisement
Table of Contents
Related Manuals for PQ Labs JJ-F67-T
Summary of Contents for PQ Labs JJ-F67-T
- Page 1 Stylus Pen ×2 Product Model：JJ-F67-T Accessories HUB ×1 Power Cable ×1 (Remote Control) HDMI Cable ×1 M6 Bolt ×4 M6*15 Screws ×4 Optional (For Intel NUC Package only) NUC Computer Bracket ×1 NUC PC × 1 Ver. 1.0.3 Copyright ©2020 PQ Labs.Inc...
- Page 2 Environment For the best user experience, please place the Holo Board with approx. 2.3 feet/ 0.7m from your conference table, also keep the middle of the Holo Board aligned to the middle of the conference table. b. Please install the screws to the NUC and mount the NUC to the bracket. ≈0.7m c.
- Page 3 b. Floor stand: sold separately, please refer to the installation guide of the floor stand. b. Please connect the touch sensor USB cable to the USB HUB below, and connect the USB HUB to your computer, you can also connect your keyboard/mouse/usb storage device to the HUB.
