  • Page 1 OWNER’S MANUAL PROTIG -P SERIES WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. www.hugong.com11111...
  • Page 2 CATALOGUE GENERAL SAFETY RULES WELDING MACHINE INTRODUCTION TECHMICAL SPECIFICATION FUNCTION DESCRIPTION CURRENT ADJUST DESCRIPTION OPERATION METHOD TROUBLE SHOOTING SPARE PARTS LIST CIRCUIT CHART COMPLETE SET SPECIFICATION TRANSPORT & STORAGE...

  • Page 3: General Safety Rules

    GENERAL SAFETY RULES WARNING: Read and understand all instructions. Failure to follow all instructions listed below may result in serious injury. CAUTION: Do not allow persons to operate or assemble this PROTIG PIII SERIES until they have read this manual and have developed a thorough understanding of how the PROTIG PIII SERIES works.
  • Page 4 1.3 Use of Your Welder Do not operate the welder if the output cable, electrode, torch, wire or wire feed system is wet. Do not immerse them in water. These components and the welder must be completely dry before attempting to use them.
  • Page 5 -The fumes emitted from some metals when heated are extremely toxic. Refer to the material safety data sheet for the manufacturer’s instructions. -Do not weld near materials that will emit toxic fumes when heated. Vapors from cleaners, sprays and degreasers can be highly toxic when heated. UV and IR Arc Rays The welding arc produces ultraviolet (UV) and infrared (IR) rays that can cause injury to your eyes and skin.
  • Page 6 Electromagnetic Field -Electromagnetic fields can interfere with various electrical and electronic devices such as pacemakers. -Consult your doctor before using any electric arc welder or cutting device -Keep people with pacemakers away from your welding area when welding. -Do not wrap cable around your body while welding. -Wrap MIG gun and ground cable together whenever possible.
  • Page 7 WELDING MACHINE INTRODUCTION PROTIG-PIII SERIES Digital Inverter DC welding machine is the use of an inert gas (argon) as a protective medium arc, the use of a high melting point of the metal tungsten or tungsten oxide as an electrode, the workpiece as the other electrode, using high pressure high frequency or high-voltage pulse to advance into the inert gas ionization weld region, and between the tungsten electrode and the workpiece to ignite arc welding molten metal so as to achieve an effect of welding equipment.
  • Page 8 TECHMICAL SPECIFICATION Environmental condition * The surrounding temperature range * when working：-10~+40℃；During transport or in storage:-20~+55℃ * Relative humidity：when at 40℃：≤50%；when at 20℃：≤90%。 * Dust, acid , corrosive gas or matter in the air less than normal content Besides matter is produced in welding process. Place is not drastic motion. * Altitude less than 1000m * Keep from raining when it is used outdoor.
  • Page 9 The main tec hnical data welder 380V PROTIG PROTIG PROTIG Item unit 315P 400P 500P II I II I Input power 3～ 380 frequency 50/60 12.5 17.2 Rated input capacity Rated input current 22.6 Rated welding voltage 20～315 20～400 20～500 Welding current 20～315 20～400...
  • Page 10 20～315 20～400 20～500 Base current 20～315 20～400 20～500 Tig welding current 25～350 25～315 25～400 MMA welding current 0～10 Current up, down time 0.5～250 Pulse frequency 0～100 duty ratio Gas pre-flow 0.3～10 Gas post-flow 0.5～25 Rated output Cool type Fan cooled TIG arc Efficiency η...
  • Page 11 Efficiency η ≥ 85% Power factor Cosφ 0.93 Insulation grade level IP21S oversize L×W×H 71 9*308 *633 weight 440V PROTIG PROTIG PROTIG Item unit 315P 400P 500P II I II I Input power 3～ 440 frequency 50/60 12.5 17.2 Rated input capacity Rated input current 22.6 Rated welding voltage...

  • Page 12: Function Description

    Remark & Sign of Illustration ground connection 3ph static frequency changer—transformer—rectifier MIG/MAG。 MMA。 3ph, rated frequency 50Hz，operating frequency 60Hz。 X：duty cycle. I1max.A：rated max input current. I1eff...A：max effective input current. I2：rated welding current. U0：rated no loading voltage U1：rated input voltage. U2：loading voltage ...V：unit of voltage ...A：unit of current ...%：unit of duty cycle...
  • Page 13 selection of proper duty ratio will be able to well meet the needs of the concrete.Pulse welding current is to strengthen the mixing of molten pool, to minimize the pores.Under the same line energy, dc pulse arc than dc constant current arc penetration is big, pulse current of coagulation, form and normal form is different, it can improve the mechanical properties of a particular joint.Properly adjusting the parameters of the pulse and the welding speed, smooth dc pulse argon arc welding can form uniform and controllable fusion zone (scales).

  • Page 14: Operation Method

    and continue to transport the time of the gas.Welding is under the high temperature, high temperature hot will be oxide parts quickly.And although, at the end of the welding arc extinguishing no longer heated the artifacts, but molten pool need to place a time, in the break time continue to transport is necessary to protect gas pool, the time is 0.5 ~ 25 s.
  • Page 15 29 Water input interface 30 input power supply terminal 3 ~ 380 Manual welding use "hand contact arc/argon arc/high frequency argon arc" function on hand position, located in the "hand arc welding", namely into manual electric arc welding mode.The adjustment knob is to adjust the welding current, welding current 25A to 400 A.
  • Page 16 Adjust the pulse frequency adjustment knob to adjust pulse frequency, 0.5 ~ 25.0 Hz; Adjustment arc starting current adjustment knob to adjust the arc current, 20 ~ 500 a. Adjustment rise time adjustment knob to adjust welding current rise time, 0 ~ 10 s. Adjustment fall time adjustment knob to adjust welding current fall time, 0 ~ 10 s.
  • Page 17 time.Generally in dust without serious dust once a year, in the case of dust serious, once or twice every quarter.。 * Keep the welding cable plug contact is good When you use should check the contact of the welding cable plug in.Fixed used by the operator to check at least once a month once, in the mobile when using the inspection should be done before use。...

  • Page 18: Troubleshooting

    TROUBLE SHOOTING Breakdown Analysis Solutions Replace or repair Cooling fan not Fan is broken Find the disconnection and connect it reliably working Wire is broken /falling off Torch switch is broken Replace NO HF arc-pilot Main PCB is broken Replace Wire is broken /falling off Find the disconnection and connect it reliably Check the regulator &...

  • Page 19: Spare Parts List

    SPARE PARTS LIST...

  • Page 20: Specifications

    code （ EBS ） English name specifications 11010011795 cover PROTIG 500W PULSEii PTP500.10.24D33.3.1 20070250092 control transformer 380V/19/19/24V/73W/0.5KVA 11050110283 PWM PCB board NB-350E capacitor 20070120123 DMJ-MT 40uF±5%/800V DC filter capacitor 20030302216 common mode inductance NB500E/PM500.10.24D33.3.2 20040300009 cable fixed head EG-21 11110150117 power input cable PROTIG 400W PULSE 20070520004...
  • Page 21 11110270047 hall PM500.10.24D33.7 20050050654 plastic panel 572*308V1.0/PANTONG130C 20050050651 fan window INVERMIG 500E/232*205.5*55 11020015867 output fixed plate PRPTIG 400W PULSE 20070570206 quick socket DKJ50-70 20030300632 torch switch WSM-500E/PTP500.10.24D33.2.3 20030300482 aviation socket WSM-500E/PTP500.10.24D33.2.2 11020015866 switch support plate PROTIG 500W PULSE KN-21B-6/ 黑色 20070110068 potentiometer knob 11020015868...
  • Page 22 CIRCUIT CHART The circuit chart of PROTIG-PIII Series Inverter DC Pulse TIG Welder. (Only for reference, no notification will be given if there are any changes.)

  • Page 23: Complete Set Specification

    COMPLETE SET SPECIFICATION PROTIG-XXXPIII Inverter DC Pulse TIG Welder Product Certificate Warranty Card Operator’s Manual Torch Pottery nozzle (with one on the torch) Tungsten electrode holder (with one on the torch) Electrode Cup (with one on the torch) Long and short each TIPS Gas hoop Gas hose...
