LOOM COT
Instruction Manual
Congratulations!
You are now the owner of a Nurseryworks
product...a line of modern baby furniture that
redefines the nursery. Nurseryworks' products
are designed with both style and functionality
in mind, and we hope it becomes a source of
pleasure for you and your family. Quality material,
workmanship and pride have gone into these
products. Proper assembly is important to
ensure a safe and comfortable end result for
your baby. Please read all instructions before
assembly, and keep instructions for future use.
revised 26JAN2011
Advertisement
Related Manuals for Nurseryworks Loom Cot
Summary of Contents for Nurseryworks Loom Cot
- Page 1 LOOM COT Instruction Manual Congratulations! You are now the owner of a Nurseryworks product...a line of modern baby furniture that redefines the nursery. Nurseryworks’ products are designed with both style and functionality in mind, and we hope it becomes a source of pleasure for you and your family.
- Page 2 finish. With proper care and assembly, your Nurseryworks products will be a part of your family for years to come. Please note that due to the handcrafted nature of our products...
- Page 3 Periodic polishing or oiling on furniture pieces that have a stain finish will help to maintain the rich wood tones. Each Nurseryworks item is a unique piece, made of White Pine, Paulownia Wood and with rich and high quality wood veneers.
- Page 4 WARNING Please read the Caution and Warning Statements insert before using your cot. CAUTION: ANY MATTRESS USED IN THIS COT MUST BE AT LEAST 690 MM BY 1310 MM WITH A THICKNESS NOT EXCEEDING 150 MM. WARNING: Failure to follow these warnings and the assembly instructions could result in serious injury or death.
- Page 5 WARNING: Do not use this cot if the enclosed or attached instructions cannot be strictly adhered to. Do not use this cot if the child is able to climb out unaided or is taller than 90 cm. Do not place cords, straps, or similar items that could become wound around the child’s neck in or near this cot.
- Page 6 the child should be placed in a youth or regular bed, and the cot shall no longer be used. • Check this product for damaged hardware, loose joints, missing parts or sharp edges before and after assembly and frequently during use. DO NOT use cot if any parts are missing, damaged or broken.
- Page 7 RECOMMENDED MATTRESS SIZE: This cot has been manufactured for use with a mattress which measures 690 mm wide by 1310 mm long and 150 mm(or less) in thickness. The width and length are specified because it is important that the gaps between the mattress and the sides and ends of the cot will not exceed 40 mm.
-
Page 8: One-Year Limited Warranty
Some States do not allow limitation on how long an implied warranty lasts. Registering your product is even easier than before. You can register your product on our website at : www.nurseryworks.net IF YOU WOULD LIKE TO ORDER REPLACEMENT OR MISSING PARTS. PLEASE VISIT US AT: WWW.NURSERYWORKS.NET... - Page 9 Loom Cot (50mm/2”) (15mm/0.6”) (15mm/0.6”)
- Page 10 Loom Cot End Panel Slat Panel Mattress Board Be sure you follow the instructions in the order that they appear. To avoid possible scratching, assemble furniture on a soft surface. For instance on a carpet or blanket. Be aware that you can use both ends of the Allen wrench.
- Page 11 Loom Cot Assembly Instructions Step 1 Use Screw C to Fasten Male Rail Clip F to the top hole in End Panel with a phillips head screwdriver (not included). You will install 4 clips total, 2 on each End Panel...
- Page 12 Step 2 Determine if you want the Mattress Board at the High . Then use 2 Screws B to Position or the Low Position attach Bracket D through the corresponding holes. Tighten each screw with Allen Wrench H. You will install 4 brackets total, 2 on each End Panel...
- Page 13 Step 3 Attach one Slat Panel to one End Panel by aligning the Female Rail Clip G(pre-installed in the top rail of ) above the Male Rail Clip F. Push down Slat Panel firmly to set in place. Then screew one Plate E into the holes along the with three Screw B and tighten bottom of Slat Panel with Allen Wrench H.
- Page 14 Step 4 Fasten the other end of Slat Panel to the second End Panel by aligning the clips and installing the plate as you did in Step 3.
- Page 15 Step 5 Install the Mattress Board by matching up the four corner holes in the board with the four Brackets D. DO NOT screw down yet.
- Page 16 Step 6 Attach the second Slat Panel by aligning both the Female Rail Clips G with the Male Rail Clips F (similar to what you did in Step 3). Attach the remaining Plates E (also similar to Step 3).
- Page 17 Step 7 by inserting Screw A Firmly attach the Mattress Board at each of the four corner holes and tightening with Allen Wrench H.
