MK-50 / 100 / 150 RGBW-T DMX
User manual
MK-50 / 100 / 150 RGBW-T DMX
Model
Programs
DMX modes
Remote controller
Light source type
IP rating
Light colour mode
Working voltage
Power
Material of housing
Light engine dimensions
Net weight
Fibre optic port diameter
Maximum number of fibre
optic bundles at 0.75 mm
diameter
Lifetime
Warranty
Package dimensions
(excluding fibre optic bundle)
Weight with packaging
www.stellarlighting.co.uk
email: info@stellarlighting.co.uk
MK-50 RGBW-T DMX
Speed and brightness control, 14 programs, music sync function
(1) DMX 512 Signal mode (2) Master and slave mode (3) Music sync mode
(DMX socket standard:
Yes, RF
LED
IP20
RGBW
110 / 230V
50W
Aluminium
270 mm (L) x 264 mm (W) x 135 mm (H)
8 kg
30 mm
1,250
50,000 hours
1 year
360 mm (L) x 330 mm (W) x 200 mm (H)
8.5 kg
MK-100 RGBW-T DMX MK-150 RGBW-T DMX
XLR)
100W
150W
1
Advertisement
Summary of Contents for Stellar Lighting MK-50 RGBW-T DMX
- Page 1 MK-50 / 100 / 150 RGBW-T DMX User manual MK-50 / 100 / 150 RGBW-T DMX Model MK-50 RGBW-T DMX MK-100 RGBW-T DMX MK-150 RGBW-T DMX Programs Speed and brightness control, 14 programs, music sync function (1) DMX 512 Signal mode (2) Master and slave mode (3) Music sync mode...
-
Page 2: Safety Notices
MK-50 / 100 / 150 RGBW-T DMX User manual Safety notices Electrical work safety advice and tips ● Make sure the input voltage is correct. ● Avoid placing the light engine in the rain or in moist areas. Please ensure that the light engine has sufficient ventilation and is not placed in a completely sealed area. - Page 3 MK-50 / 100 / 150 RGBW-T DMX User manual Light engine information and dimensions Connection method between optical fibres and the light engine Your fibre optic bundle will come with the connector fittings ready to connect to the light engine. 1.
- Page 4 MK-50 / 100 / 150 RGBW-T DMX User manual 4. Make sure that the optical fibre bundle head is smooth and clean to ensure even light distribution. . Fasten the bundle with the screw on the top of the Light engine control modes •...
- Page 5 MK-50 / 100 / 150 RGBW-T DMX User manual Notes o If you need Master/Slaves to change colour ontrol needs to be switched on. • Light engine connection diagram in Master/slave mode DMX signal cable and connector: 2 x 0.5 mm audio cable Wireless remote controller display shows...
- Page 6 MK-50 / 100 / 150 RGBW-T DMX User manual Note: • The address codes of the slave machines are not adjustable when the remote-control mode is switched • While selecting the programme on the remote, two digits need to be entered even for single digit 14 program codes: Troubleshooting for remote controller connection issues: •...
