*** Read All Instructions ***
Instructions for Models DS 140 and DSX 140
High Performance Fence Energizer with 4 internal
D-cell batteries or external 6-12V.
Powers up to 35 acres or 15 miles of multi-wire
overgrown fence.
Ground Terminal &
Post Clamp
Model #:
Name:
Address:
Phone:
Fence Wire / Tape
Connector. Live
Mounting Post
Recess (backside)
External Battery
Connection
Control Switch
Return Authorization Form
Description of Problem
Live Terminal
Live
Area
On / Off /
LCD display (DSX140)
LED indicator
Return Authorization #____________________
WARNING
Risk of Electric Shock
Top Cover
Catch
Call 1-800-922-3273
for this number.
Advertisement
Table of Contents
Summary of Contents for Dare DS 140
- Page 1 *** Read All Instructions *** Instructions for Models DS 140 and DSX 140 High Performance Fence Energizer with 4 internal WARNING D-cell batteries or external 6-12V. Powers up to 35 acres or 15 miles of multi-wire Risk of Electric Shock overgrown fence.
- Page 2 Safety Considerations IMPORTANT - READ THE FOLLOWING SAFETY CONSIDERATIONS CAREFULLY: 1. WARNING: DO NOT CONNECT ENERGIZER SIMULTANEOUSLY TO A FENCE AND TO ANY OTHER DEVICE SUCH AS A CATTLE TRAINER OR A POULTRY TRAINER. OTHERWISE, LIGHTNING STRIKING YOUR FENCE WILL BE CONDUCTED TO ALL OTHER DEVICES. 2.
- Page 3 Keys to Successful Energizer Installation Take care of the following details and you will save many hours of labor time. 1. Use the correct size energizer. If your energizer is underpowered for the fence condition and application you want to energize, your electric fence will not work to expectations. 2.
- Page 4 External Battery Connection ***WARNING*** The DS140 Series are also able to operate with an external 6 or 12V battery. INTERNAL BATTERIES MUST BE REMOVED BEFORE EXTERNAL BATTERY IS To connect the External Battery, first remove the internal D-cells. Connect the CONNECTED wires provided to the underside of the unit using flat female connectors.
- Page 5 Steel T-Post Ground Connection Methods **Important: The DS 140 Series must have a ground connection to operate correctly** It is possible to ground the DS140 either through: • The rod or fence post it's hung from, if it is metal.
- Page 6 Specification & Function Model DSX 140 • Adjustable Pulse Rate from 20 - 60 pulses per minute. • Increased energy output when operated from supply above 7V.* • Operates from 4 internal D-cell batteries or external 6-12V battery. • Protection against reversed battery. •...
- Page 7 (Continued) Specification & Function Example of display During operation, the information on the display is changed for every pulse in a round robin fashion as follows: 1st. & supply voltage in volts. (Above 9.9V no decimal will be shown). 2nd. &...
- Page 8 The sole obligation of Dare Products, Inc. shall be limited to repair or replacement, at its option, of the defective fence energizer or part and prepaid return to the owner.
