SFX -GS Operation Manual

Split fiber laser engraver

Hide thumbs

Table Of Contents

K0904C

SPLIT FIBER LASER ENGRAVER

Operation Manual

SFX-GS

HONESTY DESERVES SINCERE

BEHAVIOR BEFORE WORK

Luoyang Xincheng Precision Machinery Co., Ltd

ADD : NO.256 Tanggong Road , Luoyang , HenanChina 471002

TEL : +86-0379-63512276

FAX: +86-0379-69960770

E-MAIL: tapremover@lyxc.com

Luoyang Xincheng Precision Machinery Co.,Ltd

Web: www.sfxlaser.com

www.sfxlaser.com

Table of Contents

Need help?

Do you have a question about the SFX-GS and is the answer not in the manual?

Questions and answers

Summary of Contents for SFX SFX-GS

Page 1 K0904C SPLIT FIBER LASER ENGRAVER Operation Manual SFX-GS HONESTY DESERVES SINCERE BEHAVIOR BEFORE WORK Luoyang Xincheng Precision Machinery Co., Ltd ADD : NO.256 Tanggong Road , Luoyang , HenanChina 471002 TEL : +86-0379-63512276 FAX: +86-0379-69960770 E-MAIL: tapremover@lyxc.com Luoyang Xincheng Precision Machinery Co.,Ltd Web: www.sfxlaser.com...
Page 3 Contents It is important that you read this guide PRIOR to uncrating and setting up the machine. There may be slight differences in the appearance or features of your machine depending on the model that you purchased. Safety / Warning Safety / Warning ..........2 Component Identification........3 Uncrating / Unpacking..........4...
Page 4 Once the laser source/controller and emitter/working platform are moved to their permanent location proceed to the next steps for preparing the machine for use. SFX model SFX-50GS...
Page 5 provided by the power outlet that you have available via the third pin [ground / earth] (Figure 1). Initial Setup Requirements NOTE: The fiber laser marking machine is shipped with the emitter assembly moved forward so the lens is not centered on the working space, this is done to save space for shipping and protect it from damage.
Page 6 Driver Installation Once connected to the machine, connect the USB cable to the PC, then plug the machine into the AC power outlet and perform the following steps: -Plug the USB Thumb Drive into the PC (it contains the driver software for the laser controller) -Twist the Emergency Stop button clockwise, it will pop outwards and the “Indicator Lamp”...
Page 7 Once the driver is installed the Device Manager view will be updated emitter over the working platform. The following steps will help you to show the Laser Control Board recognized by the system (Figure 5). accomplish this. 1.Locate the center threaded hole in the working platform and insert one of the M6 Allen head screws into it finger tight, this serves as an easy reference to center of the working platform.
