Aethra ShDSL71 Technical Specifications

ShDSL71
ShDSL CARD FOR MULTI INTERFACE TESTER D2071
OVERVIEW
The ShDSL71 module represents the ideal solution for the management of
ShDSL lines, a task achieved quickly and in depth at the same time.
This module works in combination with the Aethra multi-interface xDSL
tester D2071.
The key aspect is based on having the complete technology inside a single
module in order to permit a relevant save of money and time; in fact only
the tests you need are hosted in the card and the troubles can be faced in
a fast and direct way.
Through the connection test, it's possible to characterize the ShDSL link
completely, showing the anomalies, the defects and the discrepancies with
the chosen configuration. Data related to CRC errors, LOSW, loop
attenuation and SNR are excellent indicators of the connection status.
Through the IP2071 software option to be set in the main unit, the IP and
ATM stacks are available, in order to investigate the problems with the
upper layers.
Now, by making the "IP Generate Traffic" test work, the user can consult
the statistics pages dealing with the most widespread protocols of the
Internet world like HTTP, FTP and TFTP.
The three main operating modes (STU-R, STU-C and BRIDGE mode) cover
every possible test scenario to check the correctness of an installation or
to detect troubles on any device, both user's side and CO side; the Graphic
User Interface shows a page (that is preliminary to the test) for every
operating mode to avoid wiring mistakes and then the user can get into
focus immediately, with a remarkable save of time.
MODULE
Modular philosophy
All you need for measurements dealing with
ShDSL
Definite target
Immediate location of the suitable tests
Different operating modes
Act as user's side, CO side and transparent
mode
FEATURES AT A GLANCE
,
ShDSL connection "demystified"
2 or 4 wires ShDSL connections
Full statistics for HTTP , FTP , TFTP protocols
Small size and easy portability
Full set of Data Encapsulation Methods
