User Manual V 1.0 EN | April 2021 Pipe Adapter Kit for Magnetic Drilling Machines PAK.250 Serial number: Date of purchase:... - Page 2 Congratulations on purchasing this premium pipe adapter kit for magnetic drilling machines. At EUROBOOR we strive to exceed our customers’ expectations by developing and providing premium and innovative portable drilling and cutting solutions. We believe that a professional like you must be able to rely on a professional supplier.
-
Page 3: Table Of Contents
Table of Contents PAK.250 ............................1 Table of Contents ......................... 3 1. Safety Instructions ........................4 2.Description ..........................5 2.1 Intended use ..........................5 2.2 Description and features ....................... 5 2.3 Serial number ..........................5 2.4 Technical data ..........................6 2.5 Case content .......................... -
Page 4: Safety Instructions
1. Safety Instructions Do not use this pipe adapter kit before you have thoroughly read and completely understood this manual, specifically the “General safety instructions” including the figures, specifications, safety regulations and the signs indicating DANGER, WARNING and CAUTION. This manual should be kept for later use, should it be passed on or sold. WORK AREA 1. -
Page 5: Description
2.Description 2.1 Intended use Drilling on tubes and pipes is always hard work, but now with the EUROBOOR pipe adapter kit for magnetic drilling machines, it’s easy and efficient. 2.2 Description and features 01. Stop screw 10. Sprocket chain 11. Chain tightening bolt 12. -
Page 6: Technical Data
Weight Suitable for tube diameter from ø 50 up to 500 mm • Suitable for all EUROBOOR magnetic drilling machines (except ECO.200 and TUBE series) • Suitable for almost all magnetic drilling machines in the market (for universal application) •... -
Page 7: Preparation And Installation
3. Preparation and Installation 3.1 Prior to use Before using it, you must check the adapter kit for possible damage, especially for sprocket chains. DO NOT let children come into contact with the adapter kit. Supervision is required when inexperienced operators use this adapter kit. Before installation always make sure the junction plate on which you are going to attach the magnet base is clear of any rust, burr and debris. - Page 8 Step 2. Hook up the chains (10) into the lock groove, then turn the chain tightening bolt (11) counterclockwise. Lock groove Step 3. Place the magnetic drilling machine on the junction plate (12) of the adapter kit, by rotating the stop screw handle (01), you can move the machine into the appropriate position.
- Page 9 Step 4 Turn on the magnet switch and start the motor for drilling work. WARNING: Make sure the adapter kit is securely fixed to the pipe before start the motor.
-
Page 10: Maintenance
4. Maintenance Your EUROBOOR pipe adapter kit has been designed to use over a long period of time. Continuous satisfactory use depends upon proper tool care and regular cleaning. CAUTION: To reduce the risk of injury, remove the drilling machine from the pipe adapter kit before adjusting or while making repairs. -
Page 11: Exploded View & Spare Parts List
6. Exploded View & Spare Parts List 6.1 Exploded view... -
Page 12: Spare Parts List
Junction Plate 6.3 Warranty Euroboor B.V. warrants this pipe adapter kit to be free of material defects and workmanship errors under normal use for a period of 12 months after date of purchase. This 12 month period can be extended to 24 months in total by registering the product on our website: https://euroboor.com/support/register/...
