Restoring Firmware Process - Neocom TRBOnet Swift A200 How To Reset

Once the device is detected by the PC as "STM32 Bootloader" or "STM
Device in DFU Mode", the short-wire jumper may be removed
(disconnected).
o Restore the firmware using Swift CPS,
"Device > Upgrade Firmware".
Once the process is completed the device will restart and
display the correct service information.
Note: Do not disconnect the CPU board from the USB cable
during the process of restoring the firmware.
Once the process of restoring the device firmware is completed:
Disconnect the CPU board from the USB cable.
•
Remove the short-wire jumper (if not done earlier).
•
Insert the SD card into the card slot.
•
Connect the CPU board to a USB port of the PC, and wait until
•
the SD card is initialized (the initialization is considered complete
when the device starts and displays service information on the
OLED display).
Note: Do not disconnect the CPU board from the USB cable
until the full start of the device.
