Summary of Contents for WHOOP WHT-25LT
- Page 1 Quick Start Guide LTE USB DONGLE WHT-25LT Whoop...
- Page 2 • For details about how to set the device and management parameters, see help information at www.whoopmobility.com • WHOOP reserves the right to modify or enhance all products described in this document, and to revise this documentation without prior notice.
- Page 3 Getting to Know Your device The following figure shows the device sketch. The actual product may look different. Whoop...
- Page 4 1. USB connector Connect the device to a computer or other data ready device. Note: Please consult your supplier for the appropriate model. Whoop...
- Page 5 The IMEI and Serial number are printed on the device as shown in the following figure. xxxx xxxx Whoop...
- Page 6 Steady cyan.Blue flashes once every 1800ms : Data transfer is ongoing Light off: device is off. 3. Reboot Use a small pin to push the reset button. 4. SIM card slot Subscriber Identity Module (SIM) card holder for the device. Whoop...
- Page 7 Install SIM card 1. Remove the front cover as shown in the figure below. Whoop...
- Page 8 2. Insert SIM card as shown in the following figure. Ensure that the SIM is place in the right direction and fully embedded. NANO SIM Whoop...
- Page 9 3. Replace the front cover on the device properly as shown in the figure below. Whoop...
- Page 10 SIM may get corrupt. • Use compatible SIM cards to avoid damage to your device and SIM card. • Make sure the SIM card is Unlocked. • Make sure the SIM is Activated and has a DATA plan. Whoop...
- Page 11 Left ⬅ ：�� MOBILE NETWORK MODE ：(first install the driver in LAN network mode). In this mode the device will show up as a MOBILE connection. REMARK: Carefully move the switch in the other position with a small pin! Whoop...
- Page 12 Plug the device into a free USB port at your computer. Whoop...
- Page 13 4. The drivers will be installed automatically. 5. When the installation is completed, a new LAN connection will show up. 6. The device connects to the mobile network automatically. 7. You can enter the device management web page at http://192.168.100.1 Whoop...
- Page 14 NOTE: Make sure you have installed the Driver first in LAN network mode. Connecting to a Network 1. Connect the device to one of your computer's USB ports. 2. When the installation is completed, a new MOBILE connection will show up. 3. The device connects to the mobile network automatically. Whoop...
- Page 15 1. Take the 2pcs CRC9 antenna from packaged and take off the cover of the connectors. 2. Open the 2 connectors on the LTE USB Dongle. 3. Carefully plug in the 2pcs antennas. The 2 antennas are exactly the same and can be used on both connectors. 4. Connect the Dongle. Whoop...
- Page 16 Windows drivers. The device will show up as a LAN connection. 3. Left ⬅ ：�� MOBILE NETWORK MODE ：(first install the driver in LAN network mode). In this mode the device will show up as a MOBILE Connection. 1.RESET 2.Dip switch Whoop...
- Page 17 Factory settings Model: WHT-25LT Web: http://192.168.100.1 Password: admin Restoring Factory Settings If you wish to restore factory settings on your device, you can connect the device to a computer or a power outlet, then press and hold the RESET button for 5 seconds.
- Page 18 Dimensions 95 x 36 x 13（mm） Processor Qualcomm Power Consumption 2W (Max) Antenna 1×4G Main antenna,1×4G Auxiliary antenna Sim card slot NANO SIM card slot Operating Voltage 5V USB Whoop...
- Page 19 Temperature Range Operating: -20°C to 60°C Storage: -40°C to 85°C Humidity Operating: 5％ to 95％(non-condensing) Storage: Max. 90％ (non-condensing) Host Interface USB 2.0 LTE FDD B2 / B4 / B12 / B66 / B71 Drivers Windows / Linux Whoop...
- Page 20 Limited Warranty WHOOP provides a one year warranty service after purchase of this product. Within this year when the product stops working because of design defects, the product will be repaired or replaced. (replacement of the product is sole to the decision of Whoop and only when the product is not physically damaged).
- Page 21 Notice of content and ownership Copyright © 2020 WHOOP. All rights reserved. The full and total contents of this documentation is protected by copyright laws. Any form of reproduction, transference, distribution or saving of the contents of this document, be it partly or wholly, without prior consent in writing from WHOOP, is prohibited.
- Page 22 This documentation was supplied to serve as a user guide exclusively for WHOOP devices and contains no clarification with regard to hardware- or software configurations of the products described within this document. The availability of specific products or expansions may vary depending on your location.
- Page 23 However, there is no guarantee that interference will not occur in a particular installation If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is Whoop...
- Page 24 Caution: Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. ●The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Whoop...
- Page 25 USB slot configurations including Horizontal-UP, Horizontal-Down, Vertical- Front, Vertical-Back. This device can be used in host product(s) with substantially similar physical dimensions, construction, and electrical and RF characteristics. The highest SAR value, tested per FCC RF exposure guidelines Whoop...
- Page 26 Equipment Authorization for this device with all reported SAR levels evaluated as in compliance with the FCC RF exposure guidelines. SAR information on this device is on file with the FCC and can be found under the Display Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID: 2AP7L-WHT25LT. Whoop...
