OPERATION&SERVICE MANUAL
MODEL:H10J
MANUAL STACKER
Eoslift Automation Technology Corp.
No.99, Yanjia Road, Yuantong Town, Haiyan, Zhejiang

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the H10J and is the answer not in the manual?

Questions and answers

Summary of Contents for Eoslift H10J

  • Page 1 OPERATION&SERVICE MANUAL MODEL:H10J MANUAL STACKER Eoslift Automation Technology Corp. No.99, Yanjia Road, Yuantong Town, Haiyan, Zhejiang...
  • Page 2 CONTENTS 1.Structural Data Form EJ(Single frame) 1 Structural Data Form Page 1 Model H10J 2 Safety Guidance Page 2 Manufacturer EOSLIFT 3 Maintenance Page 3 Load Capacity 2200 Inner Width of Legs 33-49 4 To Adjust Release Device Page 3 B1(in.)

  • Page 3: Safety Guidance

    2.Safety Guidance 3. Maintenance 3.1 Hydraulic oil - Check the oil level every six months. The oil must be hydraulic oil: ISO VG32, its viscosity 2.1 Operator should read all warning signs and instructions here and on the stacker before using it. °...

  • Page 4: Parts List

    6.Parts List Front wheel assembly -The piston rod or pump is Replace piston rod and/or pump deformed resulting from partial loading, cargo slanting to one side or over-loading The forks cannot Keep the forks at the lowest be descended -The truck was stored with setting while Not in use, and the forks raised for extended keep parts lubricated.
  • Page 5 Guide wheel with brake pedal plate,galvanized WC02000345 pinch roller,galvanized WC02000346 axle,galvanized WC02000347 GB70.1 Hex socket screw M6×20, WE03000021 galvanized Gb117 Pin 6×42,galvanized WE06000012 steering wheel frame with brake,black WC02000350 GB297,circular cone running pulley WC02000225 bearing 30205 wheel axle sleeve WC02000348 brake rod,black WC02000351 cover...

  • Page 6: Guide Wheel

    Guide wheel Guide wheel Part Number Description Qty. GB276,deep groove ball bearing6205， WC 02000224 two-side dusty cover axle cover,galvanized WC02000352 GB93 Spring washer 10,galvanized WE05000002 GB70.1 Hex socket screw M10×25,galvanized WE03000004 JB7940.4,Pressure distribution type forced WC02000019 filling oil cup 6 trailing wheel,black WC02000353 wheel axle sleeve...

  • Page 7: Cylinder Assembly

    Part Number Description Qty. Cylinder assembly 1 WE 07000004 GB894.1 Circlip for Shaft 20,black WC02000365 pressure spring WC02000108 spring cover,galvanized WC02000387 seal ringUHS14 WC02000363 pump core WC02000390 trundle,galvanized WC02000391 roller shaft,galvanized WC02000069 GB308,steel ball S7 WC02000393 spring seat WC02000375 bolt WC02000401 reverssliding bearing30/23×20×8 WE03000003...
  • Page 8 Cylinder assembly2 WE 03000016 GB70.1 Hex socket screw M5×16,galvanized WC 02000394 rubber sleeve WC02000396 pedal,black WC02000392 spring WC02000398 pin roll,galvanized WE 06000016 GB117 Pin 4×18,black...
  • Page 9 Part Number Description Qty. WC 02000132 GB3452.1,O-ringφ9.0×1.8 WC 02000358 cylinders(1.6),black WC02000373 sealing washer WC02000382 GB3452.1,O-ringφ15×2.65 WC02000069 GB308,steel ball S7 WE07000004 GB894.1 Circlip for Shaft 20,black WC02000366 dirt-proof boot GB818 Screw M6×10,galvanized WE03000023 WC02000368 unloading spring WC02000383 GB982,sseal washer 6 WC02000367 unloading rod WC02000364 guide sleeve...
  • Page 10 Forks carriage Part Number Description Qty. WC 02000721 outer mast,5012 WC02000355 locking ring,galvanized WE04000009 GB6170 Hex nut M10,galvanized WE01000002 GB5781 Hex bolt M10×50,galvanized WC02000357 gauze,black WE05000004 GB95 Plain washer 5,galvanized WE03000016 GB70.1 Hex socket screw M5×16,galvanized WC02000330 gauze pad,black WE03000014 GB70.1 Hex socket screw M8×20,galvanized WE04000015 GB889.1 Hex lock nut M8,galvanized...

  • Page 11: Roller Chain

    Roller chain Handle assembly Part Number Description Qty. WC 02000722 fork guide plate,black WE07000010 GB894.1 Circlip for Shaft 25,black WE03000019 GB77 Hexagon flat set screw M12×20,galvanized WC02000231 steel wheel GB276,deep groove ball bearing6205， WC02000224 two-side dusty cover WE07000007 GB893.1 Cieclip for hole 52,black Description Qty.
  • Page 12 Handle assembly Handle assembly Part Number Description Qty. WJ 10800036 EOS-HS handle-finger handle WJ10800037 EOS-HS handle-position sheet WJ10800038 EOS-HS handle-torsion spring WJ10800039 EOS-HS handle-cooper roller WJ10800040 EOS-HS handle-handle weldment WJ10800041 EOS-HS handle-connecting sheet of pull pole WJ10800042 EOS-HS handle-pull pole WJ10800043 EOS-HS handle-chain WJ10800044...
