  • Page 1 Copyright Notice All title, copyright and other intellectual property rights in and to the Software Product(Including but not limited to any relevant media, images, photographs, animations, video, audio, text, and applets incorporated into the Software Product),the accompanying manuals and other documents, and on-line or electronic documents, if any,(collectively “Software Product”) are owned by the Manufacturer unless otherwise expressly licensed by The Manufacturer in writing, any provision of the Software Product does not represent any license of any of the above rights.

  • Page 2: Table Of Contents

    Table of Contents Installing I/O shield... 3 Installing Motherboard... 4 III. Installing riser card ... 5 How to use clamp bar ... 6 Installing 2.5” HDD ... 7 VI. Installing 3.5”OS HDD... 8 VII. Installing 3.5” Hot-Swap HDD Tray ... 9 VIII.

  • Page 3: Installing I/O Shield

    Installing I/O shield Type A_ I/O shield is provided with Motherboard 1. I/O shield snaps in from inside of chassis into the cutout Type B 1. I/O shield snaps in from inside of chassis into the cutout 2. Lock it by 2 x M3 screws...

  • Page 4: Ii. Installing Motherboard

    1. Install the provided brass standoffs on chassis (1) at appropriate positions 2. Place motherboard into the chassis, and make sure that the back panel I/O shield cutout and chassis mounting standoffs align correctly. Install the M/B by M3 screws.

  • Page 5: Installing Riser Card

    III. Installing riser card (Base on socket’s type, chassis’ height and PCI card’s type to select the riser card) Type A：1U solution 1. Insert the PCI card to riser card and then install the riser card at appropriate PCI slot.

  • Page 6: How To Use Clamp Bar

    IV. How to use clamp bar 1. Extract the thumb screw and swing backward the clamp 2. Fit the clamp bar over the add-on card and tighten the thumb screw to bring the clamp forward thus pushing down on the card. 3.

  • Page 7: Installing 2.5" Hdd

    V. Installing 2.5” HDD Type A 1. Install the 2 brackets on both sides of 2.5” HDD with 4 x M3 screws 2. Install the provided 2.5” HDD adaptor Type B _For install PSU-P2G only Put the 2.5”HDD under the top side of the cage (1) and fix it to the cage with 4 screws as shown in (2) Type C Put the 2.5”HDD into the pilot pins on the right side of the cage and fix it to the cage with 2 screws...

  • Page 8: Installing 3.5"Os Hdd

    Lock the HDD with the right and left bracket by 4 x 6# screws and then lock it in the bottom of chassis. Type D Type D does not use any bracket but just screws HDD into the bottom of chassis by 4 screws. (6# type) Type E Install each HDD into the bracket with 4 screws (6#type) in the bottom.

  • Page 9: Installing 3.5" Hot-Swap Hdd Tray

    3. Put the HDD onto the tray and install 4 x 6# mounting screws from underside. 4. Insert the tray back into the chassis by pushing on the HDD tray panel all the way until tray handle starts to swing shut 5.

  • Page 10: How To Use The Slim Cd-Rom & Floppy Direct Device Cage

    VIII. How to use the Slim CD-Rom & Floppy Direct Device cage ** Installing 3.5” FDD or 3.5” HDD 1. Remove the knock-out shield from 3.5” device bay 2. Remove the USB port PC board 3. Install 3.5” FDD from both sides with 4 x M3 screws 4.

  • Page 11: I X I S C D R Om

    Remove the blanking shield from bracket and then put the slim CD-ROM drive onto the tray. Fix the slim CD- ROM device from both sides by 4 x M2 screws. Insert the tray back into chassis and tighten the thumb screws. - Page 11 of 17 -...
  • Page 12 Type B 1. Remove slim CD-ROM bezel by loosening the 2 screws on the sides. 2. Attach the two brackets on two sides of slim CD-ROM and install the mounting 4 x M2 screws. Type C 1. Release 1 screw to remove S-CD cover. 2.

  • Page 13: I N S T A L I N G S L I M F Dd

    1. Mount slim FDD onto bracket by installing and tightening 4 x M2.5 screws. 2. Mount slim FDD adaptor by securing it with 2 x M3 screws. 3. Insert the slim FDD bracket module back into the chassis and fixed it by 2 screws. 4. Connect flat cable between slim FDD and adaptor.
  • Page 14 2. Remove the knock-out shield. Install the slim FDD by fix 4 x M2.5 and adaptor by 2 x M3 screws as (2). 3. Connecting both data and power cables before install the slim FDD back into the chassis. Fix it by tightening the two thumb screws.

  • Page 15: Installing 5.25" Bay Device

    3. Connecting both data and power cables 4. Insert the Device back into the chassis and secure it by tightening the two thumb screws. Type B 1. Insert the CD-Rom into the chassis and align the right side bracket pins with the mounting holes on the right side of CD-ROM.

  • Page 16: Installing 3.5" Bay Device

    XII. Installing 3.5” Bay Device Remove front shield by releasing the 2 screws. Install the each 3.5 device bay with 4 x M3 screws at appropriate location - Page 16 of 17 -...

  • Page 17: Glossary

    XIII. Glossary Ricer Card A card that plugs into the motherboard to provide a perpendicular extension of the bus. Adapter cards are then plugged into the riser instead of the motherboard, allowing a lower profile to the case. Most often used for desktop systems that sit under the monitor. 1U/2U A “U”, Rack Unit, is equal to 1.75"...
