Summary of Contents for Kirstein SHOWLITE BL-8 USB Burst Partylight
- Page 1 BL-8 USB Burst Partylight User-Manual Item number: 00069700 Version: 08/2020...
- Page 2 Thank you for choosing this product. To ensure that you are completely satisfied with this product, please read and understand this manual carefully. PLEASE READ CAREFULLY Please keep this manual in a safe place for future reference. Hand over all documents when passing on the product to third parties.
- Page 3 Caution Please observe the following basic instructions in order not to endanger yourself or others and to avoid damage to external devices. Warnings Do not disassemble or modify the product. This could result in injury from electric shock. If you notice that the power cord shows obvious signs of wear, the appliance is malfunctioning, smells burnt or smokes, immediately unplug the appliance from the wall outlet and refer servicing, maintenance or repair to an authorised service centre or your dealer.
- Page 4 Installation / Hanging mounting The installation may only be carried out by authorised specialist personnel! In case of overhead rigging, please observe the applicable standards and regulations in your country. In any case, a second independent suspension must be used to secure the unit. This can be ensured by a safety net or a suitable safety rope/chain or similar.
-
Page 5: Table Of Contents
© 2020 This manual is protected by copyright. Copying or reprinting, even in extracts, is only permitted with the consent of Musikhaus Kirstein GmbH. The same applies to the reproduction or copying of pictures, also in modified form. Content 1. General overview ....................5 2. -
Page 6: Product Overview And Operating Elements
3. Product overview and operating elements Name Function IR receiver Receives the signal from the remote control Bracket For mounting the fixture. Loosen the plastic screws on the sides to change the angle and then tighten them again sufficiently. Lens Light emission... - Page 7 Name Function Microphone The input signal via the microphone influences the music control. USB port for power Connect this connector to the supplied power supply 5V 2A supply. Selector switch Mode selection: Close, Auto, Sound Position Close: Blackout Position Auto: Auto program Position Sound: Music control...
-
Page 8: Ir Remote Control
4. IR remote control Auto program green Music control green+blue Blackout red+green Reduce speed blue Increase speed red, green+blue Not assigned red+green green+blue red+white red+green Not assigned Not assigned Not assigned... -
Page 9: Technical Data
5. Technical data Article description BL-8 USB Burst Partylight LED Power 2W red, 2W green, 2W blue, 2W white Operating Modes Auto/Sound Size in mm 135x135x158 Weight in kg Power supply 5V/2A via USB-C Power consumption Operating temperature max. 40°C Protection class IP20... - Page 10 Musikhaus Kirstein GmbH - Products are only available through authorized dealers. Distributors and dealers are not authorized representatives of Musikhaus Kirstein GmbH and have no authorization to bind Musikhaus Kirstein GmbH legally in any way, be it expressly or through coherent action.
