User Manual
Unit overview
1
2
3
5
13
8
7
4
10
9
11
6
12
1.Power on-off
2.Earphone jack
3.Hold/Unlock
4.Micro SD card slot
5.Vol+/Scroll up
6.Vol-/Scroll down
7. Main Menu
8.Back/Exit to superior menu
9.Previous and fast forward playing
10.Next and fast backward playing
11.Play/Pause/On-off/Enter
12.USB Port
13.Clip
Advertisement
Table of Contents
Summary of Contents for Istar F3BT
- Page 1 User Manual Unit overview 1.Power on-off 2.Earphone jack 3.Hold/Unlock 4.Micro SD card slot 5.Vol+/Scroll up 6.Vol-/Scroll down 7. Main Menu 8.Back/Exit to superior menu 9.Previous and fast forward playing 10.Next and fast backward playing 11.Play/Pause/On-off/Enter 12.USB Port 13.Clip...
- Page 2 Technical Specification Screen 1.5 inch 128*128 TFT display Flash memory Bluetooth version Bluetooth 4.0 Audio format MP3/WMA/OGG/APE/FLAC/WAV/AAC-LC/ACELP Recording format FM/MIC record and WAV Battery Li-polymer rechargeable 300mAh FM frequency 87.5-108MHZ Micro-SD card Extend to 128GB Photo format JPG,BMP and GIF Charging time 3 hours Basic Operation...
- Page 3 At radio playing interface, press M and will show a related lists including “Auto tune”, “FM Record” ,“Save to preset ”, “Clear preset”, “FM bands” . Save to preset The frequency points of radio station are displayed with 30 frequency points reserved at most. Clear preset ...
- Page 4 Remove from playlist You can remove the song which is playing to any one of these three Playlist as you like. Delete It will show” ...(song name)” delete? Press to choose yes to delete this song. Bookmarks It is marked by the stopping time as “hh:mm:ss”.So you can set the stopping time before you add it for continues playing next time conveniently.
- Page 5 Use the button to scroll through your picture and select a photo you would like to view, and press the button. VIDEO To watch movies, select VIDEO from the main menu and press the button to confirm. The video playback screen will be displayed Movie playback controls 1.
- Page 6 Choose the language according to your need Set brightness or Back light timer under “ display setting “ See information about your player under “Information” Set the backlight time of your player Format the device or restore to factory setting ...
