OPERATING INSTRUCTION
WSGB04/10
Progressive Type Safety Gear
Product manufacturer reference can be found on
the product type label. For any support or further
questions please contact your trading office.
No part of this publication may be reproduced or translated, even in part, without prior written permission from
WITTUR. Subject to change without notice!
www.wittur.com
Code
PM.7.000170.EN
Version
Date
07.08.2020
© Copyright WITTUR 2016
H
Advertisement
Table of Contents
Related Manuals for WITTUR WSGB04
Summary of Contents for WITTUR WSGB04
- Page 1 For any support or further questions please contact your trading office. No part of this publication may be reproduced or translated, even in part, without prior written permission from © Copyright WITTUR 2016 WITTUR. Subject to change without notice! www.wittur.com...
-
Page 2: Table Of Contents
Progressive Type Safety Gear Blatt/ sheet D7AMMGB.2 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/KKR Operating instructions Contents Page 1 General information prior to installation Description and functions ........... . .4 Liability and guarantee . - Page 3 Blatt/ sheet Progressive Type Safety Gear D7AMMGB.3 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/KKR Operating instructions Contents Page Spare parts list .............35 5.6.1...
-
Page 4: General Information Prior To Installation
The operating range is defined as follows: • Elevator speed 1. Gripping wedge - WSGB04 2,0 - 6,0 m/s 2. Counter wedge - WSGB10 2,0 - 8,0 m/s 3. Set screw (alignment of safety gear housing) •... - Page 5 Blatt/ sheet Progressive Type Safety Gear D7AMMGB.5 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions Gripping wedge Counter wedge Set screw (alignment of safety gear housing) Adjustment screw (gripping distance) Fixing for lifting lever Safety gear spring...
-
Page 6: Liability And Guarantee
This refers especially to the corresponding accident ed in these operating instructions. prevention rules. The WITTUR guarantee may be voided if parts Important safety advice and danger warnings are other than those described in these instructions emphasized with the following symbols: are installed. -
Page 7: Preparation
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.7 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions Advice for when working on Before starting installation work: safety components Only properly trained personnel may carry Safety gears are classified as safety components. It... -
Page 8: Content Of Supply
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.8 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/MZE Operating instructions Content of supply 1.6.1 Simplex safety gear After delivery, check the safety gear for damage and for full delivery of parts. The content of sup-... -
Page 9: Simplex Safety Gear With Housing And Integrated Synchronization
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.9 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/KKR Operating instructions 1.6.3 Simplex safety gear with housing and integrated synchronization After delivery, check the safety gear for damage and for full delivery of parts. The content of sup-... -
Page 10: Duplex Safety Gear With Housing
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.10 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/MZE Operating instructions 1.6.4 Duplex safety gear with housing After delivery, check the safety gear for damage and for full delivery of parts. The content of sup-... -
Page 11: Duplex Safety Gear With Housing And Integrated Synchronization
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.11 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/KKR Operating instructions 1.6.6 Duplex safety gear with housing and integrated synchronization After delivery, check the safety gear for damage and for full delivery of parts. The content of sup-... -
Page 12: Name Plate, Designation, Identification
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.12 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version F-06.04.2016 Geprüft/ approved WAT/MZE Operating instructions Name plate, designation, identification The safety gear identification indicators are locat- ed on the side of the safety gear housing. -
Page 13: Duplex
Blatt/ sheet D7AMMGB.13 Datum/ date 11.04.2003 Stand/ version F-06.04.2016 Geprüft/ approved WAT/MZE Duplex Type label acc. to EN81, GB7588, GOST R 53780 with type test designation CTP label for GOST R and CE-label 53780 Date of manufacture Type term Typenschild accor- ding to ASME Serial number Order number... -
Page 14: Installation And Adjustment
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.14 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions Installation and adjustment Important Note Check the distance between guide rails. Lift the synchronization-lever horizontal (recommentation: DBG +0/-2mm) and measure the distance between safety... -
Page 15: Alignment Of Safety Gear Block
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.15 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions Alignment of safety gear block After installation of the car frame and the guides, the correct centering and adjustment of the safe- ty gear with regard to the rails have to be done. -
Page 16: Alignment Of The Safety Gear
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.16 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions Alignment of the safety gear Check of the distance between safety gear and guide rail: DBG ... Distance between guides Änderungen vorbehalten! -
Page 17: Gripping Wedge Synchronization And Adjustment
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.17 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/KKR Operating instructions Gripping wedge synchronization and adjustment 3.4.1 Simplex (1-3) (1) Check that the fixing links (5) of the gripping wedges (1) do not rest against the safety gear block (8). -
Page 18: 3.4.2 Duplex
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.18 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions 3.4.2 Duplex (1-6) (1) Adjust the upper pair of safety gears accord- ing 3.4.1! The distance between the adjusting screws and the safety gear block should be accord- ing 3.4.1 while the gripping wedges are lift-... - Page 19 Blatt/ sheet Progressive Type Safety Gear D7AMMGB.19 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions (7) Check the horizontal movement of the safety gear to be sure that the counter wedge is able to access the guide rail when the safety gear is activated.
-
Page 20: Adjustment Of Running Clearance Between Guide Rails And Brake Linings
Adjustment of running clearance between guide rails and brake linings If there is safety gear delivered with safety gear This kind of instruction is valid for WITTUR housing adjust the correct running clearance car frames: according to below instructions (this is also valid WCF series (WCF10, WCF16, WCF25,WCF35) for adequate housing types). -
Page 21: Assembling And Adjustment Of Housing And Synchronization
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.21 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/MZE Operating instructions Assembling and adjustment of housing and synchronization 3.6.1 Safety gear with housing and separate synchronization Do the assembling and adjustment as follows:... - Page 22 Blatt/ sheet Progressive Type Safety Gear D7AMMGB.22 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions (4) Install the synchronization rod (G) to the axles (A) - secure with pin (H). Adjust the length by means of the adjustment nuts and lock with lock nuts (I).
-
Page 23: Safety Gear With Housing And Integrated Synchronization
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.23 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/KKR Operating instructions 3.6.2 Safety gear with housing and integrat- ed synchronization If there is safety gear delivered with safety gear housing and integrated synchronization do the... - Page 24 Blatt/ sheet Progressive Type Safety Gear D7AMMGB.24 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/KKR Operating instructions (6) Connect the left threaded bar with the left threaded fork joint and the right threaded bar with the right threaded fork joint and count- er both sides with a nut.
-
Page 25: Electrical Installation Of The Safety Gear Contact
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.25 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions Electrical installation of the safe- ty gear contact Work involving electrical equipment Take note of the following when laying the... -
Page 26: Function Testing
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.26 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions Function testing Operational reliability of the installation is assured. Preparations before tests: The quality and function of individual components are subject to thorough inspection and is checked The guide rail may NOT be lubricated at before dispatch from our works. -
Page 27: Static Functions Test
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.27 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions Static functions test The function of the safety gear is to be checked Before starting the dynamic function test, with empty car and at service speed before the real you have to test with nominal weigth and safety gear test is performed. -
Page 28: Dynamic Functions Test
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.28 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version E-24.08.2011 Geprüft/ approved WAT/MZE Operating instructions Dynamic functions test Each gripping test has to be documented and a Nobody should be in the lift car or on the... -
Page 29: Gripping Distance
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.29 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions Gripping distance • Shut down the power supply; keep the brake manually open. The elevator should accelerate to the tripping 4.3.1... -
Page 30: Check Of Gripping Distance "S
If the failure could get solved, you have to repeat the test after the correction work. • If the braking distance “s“ is out of the tolerat ed values again, the safety gear must be replaced (please contact WITTUR) Änderungen vorbehalten! Subject to change without notice! -
Page 31: Visual Checks After Each Safety Gear Tripping
- defects on the safety gear housing Maintenance, inspection and repair Maintenance and inspection The progressive type safety gear WSGB04, Please contact us at WITTUR if you have WSGB10 are basically maintenance free. The any problems or queries. whole installation is designed so that no large... -
Page 32: General
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.32 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions 5.1.1 General 5.1.3 Cleaning of guide rails The guide rail may not be lubricated at Any dust or dirt on the guide rails can have influ- all. -
Page 33: Operational Life Time Of The Safety Gears
The reasons are: Please contact WITTUR if for any reason • conditions of liability and technical safety something is unclear, or you encounter •... -
Page 34: Disposal Of Material
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.34 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/KKR Operating instructions Disposal of Material Lubricants, oils and other dangerous substances or materials which pollute the environment must be disposed of in conformity with the regulations. -
Page 35: Spare Parts List
Spare part ... used Number... Art. No. Safety gear contact Bernstein I88-U1Z Riwk 258453 Safety gear housing WSGB04, WSGB10 (LB0) 900961G01 always order G01 and G02 900961G02 WSGB04, WSGB10 (LB1) 900966G01 always order G01 and G02 900966G02 rope diam. 6-7 mm... -
Page 36: Duplex With Separate Synchronization
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.36 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/MZE Operating instructions 5.6.2 Duplex with separate synchronization Pos. Component Spare part ... used Number... Art. No. Safety gear contact Bernstein I88-U1Z Riwk... -
Page 37: Simplex With Integrated Synchronization
... used Number... Art. No. Safety gear switch Bernstein I88-U1Z Riwk 258453 Safety gear WSGB04* (a pair of) guide rail size: 16mm 900950A16 WSGB04* (a pair of) guide rail size: 19mm 900950A19 WSGB10* (a pair of) guide rail size: 16mm... -
Page 38: Duplex With Integrated Synchronization
Number... Art. No. Safety gear switch Bernstein I88-U1Z Riwk 258453 Safety gear WSGB04* up (a pair of) guide rail size: 16mm 900950A16D WSGB04* up (a pair of) guide rail size: 19mm 900950A19D WSGB04* down (a pair of) guide rail size: 16mm... -
Page 39: Revision Table
Blatt/ sheet Progressive Type Safety Gear D7AMMGB.39 Datum/ date 21.03.2002 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/MZE Operating instructions Revision Table Issue date description of change CRW-3391 15.10.2012 GB 7588 and reviewtable added CRW-4136 21.11.2012 GOST R 53780 added, spelling corrected WCR-3077 21.11.2012... - Page 40 Blatt/ sheet Progressive Type Safety Gear D7AMMGB.40 Datum/ date 21.03.2002 WSGB04, WSGB10 Stand/ version H-07.08.2020 Geprüft/ approved WAT/KKR Operating instructions ANNEX A The following brake length diagrams can be used as a reference in case no tolerated brake length is defined by the system distributor.
- Page 41 Blatt/ sheet Progressive Type Safety Gear D7AMMGB.41 Datum/ date 11.04.2003 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions Diagram 1: Test method A Änderungen vorbehalten! Subject to change without notice!
- Page 42 Blatt/ sheet Progressive Type Safety Gear D7AMMGB.42 Datum/ date 21.03.2002 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions Diagram 2: Test method B Änderungen vorbehalten! Subject to change without notice!
- Page 43 Blatt/ sheet Progressive Type Safety Gear D7AMMGB.43 Datum/ date 21.03.2002 WSGB04, WSGB10 Stand/ version D-16.02.2010 Geprüft/ approved WAT/MZE Operating instructions Diagram 3: Test method C1 and C2 Änderungen vorbehalten! Subject to change without notice!
- Page 44 Sarandi - Pcia. de Buenos Aires, Argentinia 43052 Colorno, Italy AUSTRIA INDIA WITTUR Austria GmbH WITTUR Elevator Components India Pvt. Ltd. Sowitschstrasse 1 Survey nos 45/1B , 3 & 4 , Pondur Village 3270 Scheibbs, Austria Sriperumbudur – 602 105...
