- Page 1 Air Filtration Unit PuraShield Smart 500 & PuraShield Smart 1000 User Manual The company reserves the right of final interpretation of the user manual Purafil, Inc 2654 Weaver Way Doraville, GA 30340 U.S.A. Phone: +1 770 662 8545 website: www.purafil.com...
- Page 2 Safety precautions for products Dear users of Purafil products, Thank you for choosing a Purafil product. In order to use the product better, please read this manual carefully before use. Even though we have done long-term safety tests on our products, please install and use the product in strict accordance with the requirements of this manual for your health and safety! ...
- Page 3 Introduction to quick start operations How to turn on the machine Press the “OFF/ON” button to turn on/off the machine. Insert the power plug of the machine into the power socket correctly, and the red “OFF/ON” indicator light on the machine's operation screen will light up, indicating that power is connected correctly.
-
Page 4: Brief Description Of The Product
Brief Description of the Product PuraShield Smart 500 & PuraShield Smart 1000 Purafil air purifiers are widely used in schools, medical institutions, nursing homes, care centers, offices, laboratories, museums, hotels and other public business places. They can be used to Quickly and effectively removes many aerosols carrying harmful viruses, bacteria, mold, and smoke from the Purafil air purifiers are equipped with a filter layer protected by PuraWard®... -
Page 5: Product Features
Display and controller Safety limit switch A filter material hatch Main maintenance hatch Side air inlet Main maintenance hatch Moving caster Moving caster B filter material module Preliminary filter B filter material hatch Front air inlet PuraShield Smart 1000 PuraShield Smart 500... -
Page 6: Description Of Functions
Description of the operation screen and functions Current ambient temperature (Fahrenheit) on/off button Current ambient particulate concentration Service life of high High efficiency filter efficiency filter expiring in normal condition The service life of the filter material module is expiring Filter does not yet need Reset the replacement reminder to be replaced... -
Page 7: Maintenance Instructions
Maintenance instructions ① Do not place any thin or hard objects in the machine to avoid damage to the machine. ② The machine should not be placed on soft or uneven ground, so as to avoid the risk of electric leakage or machine damage caused by vibration or noise generated during the operation of the machine. - Page 8 PuraShield Smart 1000 Maintenance Any of the following maintenance procedures should be performed with the power supply disconnected. Service and maintain the air purifier regularly to improve the service life. Before servicing and maintenance, make sure to shut down the air purifier and unplug the power cord.
- Page 9 PuraShield Smart 1000 Maintenance B. Clean or replace the high efficiency filter and the preliminary filter 1. As shown in the figure: with both hands on the left side of the machine, pull out the upper hatch plate and lower hatch plate in the indicated direction. Next, turn the compartment cover downward in the indicated direction to open the filter screen compartment hatch, and, following the direction indicated by the arrow, grab the filter handle to pull out the high efficiency filter ②...
- Page 10 PuraShield Smart 1000 Maintenance C. Replace filter material 1. As shown in the figure: turn the hatch cover downwards in the direction of ① to open the filter material hatch, and pull out the filter module following the arrow's direction in ②. Note: ②...
- Page 11 PuraShield Smart 500 Maintenance Any of the following maintenance procedures should be performed with the power supply disconnected. Service and maintain the air purifier regularly to improve the service life. Before servicing and maintenance, make sure to shut down the air purifier and unplug the power cord.
- Page 12 PuraShield Smart 500 Maintenance B. Clean or replace the high efficiency filter and the preliminary filter 1. As shown in the figure: with both hands on the left side of the machine, pull out the upper hatch plate and lower hatch plate. Next, turn down the hatch cover to open the ① filter compartment, and, following the direction indicated by the arrow, grab the filter handle to pull out the high efficiency...
- Page 13 PuraShield Smart 500 Maintenance C. Replace filter material 1. As shown in the figure: turn the hatch cover downwards in the direction of ① to open the filter material hatch, and pull out the filter module following the arrow's direction in ②. Put the new filter module into the machine following the instructions in the figure.
- Page 14 Removal of stains may further damage clothing, items or tools used in an attempt to remove the stains. If the dust in the PURAFIL filter material comes into contact with organic material, two dyeing problems may occur: 1.
- Page 15 Common troubleshooting Problem Check list Troubleshooting Is the power on? Turn on the power The air purifier cannot be Is the power plug loose? Plug in properly turned on Is the hatch plate closed tightly? Close the hatch tightly Are the filters and filter material Check the installation of modules installed correctly? the filters and filter material...
-
Page 16: Product Warranty
Product warranty Purafil warrants that the equipment hardware manufactured by Purafil is free from material and process defects. Under normal use and service, warranty is provided for twenty four (24) months from the date of its first use or from the date of shipment of the machine. In accordance with this warranty, Purafil's obligation is limited to replacing only those parts that are proven to be defective. - Page 17 Purafil, Inc 2654 Weaver Way Doraville, GA 30340 U.S.A. Phone: +1 770 662 8545...
