  • Page 1 USER-MANUAL Tamson Cool Cube Bath (TCC-B) Tamson Instruments bv ISO 9001 : 2015 NL/PRO 238239125 VAT: NL 80 66 34 984 B01 Bank account no.: NL28 INGB 0007 350 370 van 't Hoffstraat 12 NL95 RABO 0160100046 2665 JL Bleiswijk, The Netherlands Chamber of commerce 27 16 95 41 www.tamson.com T.

  • Page 2: Table Of Contents

    SAFETY AND WARNINGS ..........................3 WARRANTY ..............................3 DISCLAIMER ..............................3 PRECAUTIONS AND HAZARDS ........................4 INSTALLATION ..............................4 ..............................4 MPORTANT ..............................4 NPACKING ............................4 OUNT SPACERS AIR CIRCULATION ............................5 ..........................5 EGULAR MAINTENANCE OPERATION ..............................6 ............................

  • Page 3: Safety And Warnings

    SAFETY AND WARNINGS Make sure before installing or operating the equipment to read and understand all instructions and safety precautions listed in this manual. If there are any questions concerning the operation of the equipment or about the information given in this manual, please contact your local dealer or our sales department first. Performance of installation, operation, or maintenance other than those described in this manual may result in a hazardous situation and may void the manufacturer's warranty.

  • Page 4: Precautions And Hazards

    PRECAUTIONS AND HAZARDS Before attempting to operate the TCC – B, read all parts of this manual carefully to insure smooth operation and avoid damage to the equipment or its accessories. If a malfunction occurs, consult section "Trouble shooting”, READ page 17.

  • Page 5: Air Circulation

    KEEP AIR FLOW FREE Air circulation Put the unit in its proper place. Leave enough room around the cryostat for sufficient air circulation. Place the unit in a clean working environment and keep away from dust. When air can not circulate well, the cryostat will overheat itself resulting in irreversible and severe mechanical damage.

  • Page 6: Operation

    WAIT 10 MIN OPERATION BEFORE TURNING ON 7.1 Switching on If the bath has been properly filled with fluid, it can be switched with the mains switch located on the front panel. Choose a working temperature (set point) with keys. For an optimal performance the bath is best tuned at the set point temperature.

  • Page 7: Start

    7.4 Start The bath must be filled with a liquid suitable for the minimum operating temperature. VISCOSITY < 20 cSt It is very important to select a liquid with a viscosity of FLASHPOINT less than 20 cSt at the operating temperature and a flash >...

  • Page 8: Selecting Parameters

    7.5 Selecting parameters The front panel layout shows the following 4 operating keys: PAGE LIST DOWN Press shortly and following is displayed - Temperature set point in C, SP.1 - Tuning the bath (“Atune”), tU.n - Changing the tuning (PID) parameters "P"value - Changing the tuning (PID) parameters "I"value - Changing the tuning (PID) parameters "D"value Sequence...

  • Page 9: Quick Start

    displayed bath temperature is 20.0°C, an offset of 0.2 displays a value of 20.2°C. An offset of -0.2°C will display 19.8°C. Range is -5°C .. +5°C. Press page key to confirm setting when altered.  When tune is set to on, PID values can not note: be set.

  • Page 10: Fluid Level

    7.1 Fluid level Do not operate the bath with low fluid level. When the fluid level is too low, bath fluid will vaporize leading to toxic and flamable fumes. Flamable fumes can lead to fire Flammable fumes can be ignited by the not submersed part of the heating element.

  • Page 11: Maximum Fluid Level

    7.1 Maximum fluid level If the fluid level is too high, it will leave the bath via the overflow outlet (10 mm outside diameter pipe). Prevent fluid from the overflow outlet entering the backside of the apparatus. For this reason the overflow outlet must be connected to a waste container.

  • Page 12: Connecting

    Check mains CONNECTING voltage and frequency Before plugging TCC-B bath into mains socket, make sure the voltage of the bath corresponds to the local voltage and frequency. Use a mains supply that is well earthed, clean of interference and suitable for the acquired electrical load of the bath. 8.1 Cleaning Use a properly grounded mains...

  • Page 13: Introduction To The Tcc-B Series

    INTRODUCTION TO THE TCC-B SERIES PUMP MOTOR HOUSING CIRCULATION BATH INLET AND The TAMSON model TCC-B circulators are designed to OUTLET perform accurate temperature control required for general laboratory. Tamson circulator optimized temperature control of applications requiring a high degree of stability over a broad temperature range.
  • Page 14 The standard pump offers a motor protection (small thermal fuse) which is placed on the back panel of the motor REMOVE DISK compartment. This protects the motor from excessive loads. WHEN CIRCULATING When pumping viscous liquids the thermal fuse can be activated.

  • Page 15: Spare Parts List And Product Code

    10 Spare parts list and product code Product code Ordering code Description Tamson Cool Cube – Bath 230V / 50Hz 00T0310 Tamson Cool Cube – Bath 230V / 60Hz 00T0311 Tamson Cool Cube – Bath 115V / 60Hz 00T0302 Sparepart - list Ordering code Image Description...

  • Page 16: Ditechnical Details

    12 DiTechnical details Dimensions Casing Height + display [mm] Width [mm] Depth (casing) [mm] Do not operate backside directly to the wall Weight [kg] Power consumption Initial start (first 15 min. max) 2600W During first starting minutes Cooling down Working load 1500W max During normal operation and no heating...

  • Page 17: Trouble Shooting

    13 Trouble shooting : Electronics seem to be "dead" : Check fuse ☺: Replace fuse. Fuse can be accessed by removing right side panel. FUSE : Compressor (C1 or C2) do not run : Check apparatus for dust. ☺: Remove all dust using a vacuum cleaner.

  • Page 18: Ce Declaration Of Conformity

    14 CE DECLARATION OF CONFORMITY Following equipment is in compliance with EMC Directive 2014/30/EU: Product: Thermostatic bath and circulator Model: TCC - IC TCC - B Serial code: Effective from serial number 19Txxx Manufacturer: Tamson Instruments bv van 't Hoffstraat 12 2665 JL Bleiswijk The Netherlands The products are in conformity with the following specifications:...
  • Page 19 not applicable were: Conducted discontinuous emissions (Clicks) Radiated emission (OATS) Magnetic field immunity The equipment conforms with all the specifications and norms in this regard. The equipment conforms without any further notice. Entity responsible for marking this declaration : Manufacturer, Tamson Instruments bv, van 't Hoffstraat 12, Bleiswijk The Netherlands, Name R.C.
