Summary of Contents for Blizzard BRRCG1A
- Page 1 Contact Grill User’s manual BRRCG1A BRSCG1A BRRCG2A BRSCG2A...
- Page 2 Thanks for your purchasing and using BR Series Contact Grill. For making full use of function of this product and reducing unnecessary damage and injure. Please read this manual carefully before using this machine and keep it well for future reference. Warning! Any refitting and wrong installation, adjustment and maintenance can lead to property loss and causality.
-
Page 3: Exterior Structure
BR Series Contact Grill is designed and developed by the company with combination of the advantage of both foreign and domestic similar products and achieves advantages such as fashionable design, reasonable structure and convenient operation and maintenance and durability. The temperature of the griddle pan can be regulated in a certain scale according to different cooking requirements. -
Page 4: Basic Parameter
Grill Contact Grill single single single single single Upper/lower ribbed Upper/lower Upper/lower Upper Upper ribbed smooth smooth/lower ribbed/lower ribbed smooth Model BRRCG1A BRSCG1A Voltage 220~240V 220~240V 220~240V 220~240V 220~240V 50/60Hz 50/60Hz 50/60Hz 50/60Hz 50/60Hz Power 1.8KW 1.8KW 1.8KW 1.8KW 2.2KW... -
Page 5: Transportation And Storage
Transportation and Storage Please handle the griller carefully and cautiously in transportation and do not turn it upside down to prevent any damage to the shell and interior. The packed griller should be stored in the storehouse ventilation and non-corrosive gas. Any weatherproof measures should be applied when temporary storage. - Page 6 NOTICE! ● When the thunderstorm is coming, the electricity supply must be cut off soon. It will avoid the equipment being damaged in cause of lightning stroke. ● Do not destroy the control panel and the surface of the machine with hard or sharp things.
-
Page 7: Cleaning And Maintenance
Cleaning and Maintenance During normal use the surface should be well oiled, burnt deposits should be scraped off immediately. DO NOT ALLOW carbon deposits to build up on the cooking surface. CLEAN DAILY. Disconnect the unit from the power supply and allow time to cool before cleaning. wipe clean all surfaces after use, use wire brush to remove stubborn carbon deposits from the cooking surfaces and protect with a thin coating of vegetable oil. -
Page 8: Circuit Diagram
Circuit Diagram 220V~240V,50HZ BRRCG1A BRSCG1A 220V~240V ,50HZ BRRCG2A BRSCG2A HL1, HL3----POWER INDICATOR HL2, HL4 --- HEATING INDICATOR SA, SA1, SA2----TEMPERAUTRE CONTROLLER E --- GROUND CONNECTION SB, SB1, SB2----TEMPERAUTRE CONTROLLER EH1, EH2, EH3, EH4 --- HEATING WIRE THE SHELL OF THIS MACHINE MUST BE EARTH GROUNDED FOR SAFETY SAKE. -
Page 9: Daily Check
Daily Check Everyday notice the situation of the machine before or after using. Whether the machine is tilted? Whether the power cord is old, broken or Before using damaged? Whether the control panel is damaged? Whether there is strange smell? Whether the upper and lower module After using plate cannot be heated at the same time?
