Summary of Contents for Atlas IED Atmosphere AZM4
- Page 1 Atmosphere ™ Next-Gen Expandable Zone DSP Controller User Manual 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM...
-
Page 2: Table Of Contents
Atmosphere User Manual Table of Contents Important Safety Instructions ..................................... 4 Introduction ..........................................5 Key Features and Applications ....................................5 Package Contents ......................................... 6 Rack Installation Guide ........................................ 7 Hardware Overview ........................................8 AZM4 & AZM8 Front Panel ....................................8 AZM8 Back Panel ........................................ - Page 3 Atmosphere User Manual GPIO Overview .......................................... 37 GPIO Inputs .......................................... 37 Setting Up a GPIO to Recall a Scene and/or Play a Message ........................37 GPIO Outputs (GPO’s) ......................................38 High Priority .......................................... 39 Setting Up a High Priority GPIO to Play an Alert Message .......................... 39 Scenes Overview ........................................
-
Page 4: Important Safety Instructions
Atmosphere User Manual Important Safety Instructions 13. Only use attachments / accessories specified by the manufacturer. 14. Use only with the cart, stand, tripod, bracket, or table CAUTION specified by the manufacturer, or sold with the device. When a cart is used, use caution when moving the RISK OF ELECTRIC SHOCK cart / device combination to avoid injury from tip-over. -
Page 5: Introduction
Atmosphere User Manual Introduction Thank you for choosing AtlasIED and the Atmosphere line of signal processors for your project. The Atmosphere family of products are designed to meet the highest standards for design, quality, and value that our customers have come to expect from AtlasIED. The flexibility and breadth of available accessories that the Atmosphere ecosystem offers is unmatched in the industry. -
Page 6: Package Contents
Atmosphere User Manual Package Contents AZM4 or AZM8 Quick Start Guide Hardware Box Input Connector Output Connector QTY: 1 QTY: 1 AZM4 = QTY: 4 AZM4 = QTY: 4 and Safety Sheet QTY: 1 AZM8 = QTY: 6 AZM8 = QTY: 6 GPIO Connector AZM4 - 1/2 Rack AZM8 - Rack Ears... -
Page 7: Rack Installation Guide
Atmosphere User Manual Rack Installation Guide To rack mount the AZM8, remove included rack ears and fasteners from hardware box and attach to each side. To rack mount the AZM4, remove included rack ear and ½ rack adapter and fasteners from hardware box and attach to each side. Note: The AZM4 is a ½-RU device and can be mounted in a side-by-side configuration using the AtlasIED part # PA702-RMK rack kit. -
Page 8: Hardware Overview
Atmosphere User Manual Hardware Overview AZM4 and AZM8 Front Panel WiFi Enable Out of the box, the AZM is configured to connect to an existing network via the back panel ethernet port. However, there are two additional methods for connecting to the AZM for configuration, WiFi or Access Point mode, enabled from the front panel menu. If no existing network is available, it is recommended that the onboard WiFi (Access Point mode) be used for initial configuration. -
Page 9: Azm8 Back Panel
Atmosphere User Manual Light Bar System “State” Indicator This indicator monitors the current state of the AZM. • Blue = Unit powered ON and operating properly • = Live Fault is detected Flash RED If a Fault is indicated, use the Menu Display to navigate to “Faults”, and evaluate the source of the problem, or go to the UI Dashboard and see Faults for specific cause. - Page 10 Atmosphere User Manual Balanced Line Outputs Zone outputs 1-4 (AZM4) or 1-8 (AZM8) are to connect to balanced line inputs, primarily for amplifiers, such as the Atmosphere AZA amplifiers, that power zone speakers. GPIO (General Purpose Input Output Ports) The 3.5mm 12-way GPIO Euro block contains: •...
-
Page 11: Connections
Atmosphere User Manual Connections Cabling Balanced Inputs & Outputs - Use of 2 conductor w/shield for low level signals of 20-22 gauge is best. Maintain the proper polarity, + to +, – to – and shield to ground. Note: When using an unbalanced source on the 3.5mm Euro Connector, connect the GND to – with a jumper wire. (see unbalanced image in connections guide). -
Page 12: Network Connection Overview
Atmosphere User Manual Network Connection Overview Connecting Devices to the AZM for Configuration Out of the box, the AZM is configured to connect to an existing network via the back panel ethernet port. However, there are two additional methods for connecting to the AZM for configuration. If no existing network is available, it is recommended that the onboard WiFi Access Point (Method -#3) be used for initial configuration. -
Page 13: Method 3 - Access Point Connection
Atmosphere User Manual Method-3 - Access Point Connection (Built-in WiFi creates a local wireless network for connection) • From the front panel menu enable Access Point Mode (Network>WiFi>Change Mode>Access Pt, then confirm change). • The unit will now broadcast an SSID (AtlasIED_AZM will be the default SSID) that can be found using WiFi enabled devices. •... -
Page 14: Inputs Page
Atmosphere User Manual 7. Zone Status - displays the activity of each zone output, what source feeds them, and LED type status indicators; Green = signal presence, Yellow = limiter active, Red = clip. A quick link to settings is in the upper right corner of this area. 8. -
Page 15: General Settings Page
Atmosphere User Manual General Settings Page Identifies selected input connector on back panel. 0dB to +60 dB of preamp gain available to fine tune input sensitivity for Mic or Line sources. Phantom Mic setup. Pre-set High Pass Filter Enable –a separate EQ filter placed before the Equalizer page allowing roll-off of low end before the Gate and Compressor, allowing all bands of the equalizer to be used for other requirements. -
Page 16: De-Esser
Atmosphere User Manual The dynamic settings can be adjusted with left or right arrows or by entering the desired number. The dynamic settings are defined as follows: • Threshold: the signal level required to engage the Gate. • Attack Time: amount of time to fully engage (Gate, De-Esser, Compressor, Limiter) after signal level increases beyond the threshold. -
Page 17: Compressor
Atmosphere User Manual Compressor A compressor is a dynamic setting that can automatically reduce peaks in volume and smooth out a radically changing signal. It is used differently depending on what instrument or signal is being tamed. Compressing reduces the peak levels by squashing the sound into more even levels, reducing channel clipping, while remaining loud. -
Page 18: Equalizer
Atmosphere User Manual Equalizer Equalizers allow raising or lowering the level of individual frequencies or ranges (bands) of frequencies to improve the overall sound of a source signal. Narrow bands can also be set to remove problems, like feedback or an acoustically induced low end. EQ Enable/Bypass in real-time;... -
Page 19: Auto-Gain Control
Atmosphere User Manual Preset Popup Window 4 spots, A, B, C, D to name and save settings for your Recall presets own Presets to this channel Auto-Gain Control When stepping to a microphone, everyone speaks with a different level of voice projection; some almost whisper and some sound like they are shouting. -
Page 20: Rca Inputs
Atmosphere User Manual • Target Window: When AGC output level is within the Target Window, AGC does not modify the gains. This is a sort of hysteresis control which helps AGC avoid being over-active once the general target gain has been reached. 15 dB is a good general setting for speech or music. -
Page 21: Audio Wall Plate Accessories
Atmosphere User Manual Audio Wall Plate Accessories A-XLR A-RCA A-BT Balanced Mic/ Stereo Summed Bluetooth Line Input dual RCA or Input 3.5mm TRS Input Audio Wall Plate Accessories that begin with an “A”, denoting that they are audio inputs, include: A-XLR, A-RCA, and A-BT. -
Page 22: General Settings For A-Xlr Page
Atmosphere User Manual General Settings for A-XLR Page The General Settings page shows the connected port, with links to pages for Gate, De-Esser, Compressor, Equalizer, and Auto-Gain Control. (Note: see UI pages for Mic/Line input General Settings definitions) Accessory Name – displays reference to Port ID (D2) and the editable name for this accessory. Connected Port ID, includes port (“D”) and location (“2”) of the accessory on the port wiring bus. -
Page 23: General Settings For A-Rca Page
Atmosphere User Manual General Settings for A-RCA Page The General Settings page shows the connected port, with links to settings pages for Equalizer and Auto-Gain Control. (Note: see UI pages for Mic/Line EQ and Auto-Gain definitions) Accessory Name – displays reference to Port ID (C3) and the editable name for this accessory. Connected Port ID (“C”) and location (“3”) of the accessory on the port wiring bus. -
Page 24: General Settings For A-Bt Page
Atmosphere User Manual General Settings for A-BT Page The General Settings page shows the connected port, with settings pages for Equalizer and Auto-Gain Control. (Note: see UI pages for Mic/Line EQ and Auto-Gain definitions) Accessory Name – displays reference to Port ID (A2) and the editable name for this accessory. Connected Port ID (“A”) and location (“2”) of the accessory on the port wiring bus. -
Page 25: Virtual Mix Inputs
Atmosphere User Manual Virtual Mix Inputs The four Virtual Mix inputs each allow a selection of any four inputs to be combined into a sub-mix to provide a single audio fader adjustment for the group. Each mix can be named here and will be available to select to any zone by selecting from the zone inputs source lists. Input Level adjust –... -
Page 26: Signal Generator Input
Atmosphere User Manual Signal Generator Input The Signal Generator Input provides a way to test, setup, and troubleshoot zones with a consistent audio source. A sine wave with frequency setting is a tone and useful in calibration throughout the system. White noise is a random signal containing equal energy per frequency, giving it a constant power spectral density. -
Page 27: General Settings Page
Atmosphere User Manual General Settings Page The General Settings page shows the connected port, with settings pages for Equalizer, Ambient Noise Compensation (ANC) Control and Limiter. Priority Ducker Settings and Priority Input and Limiter Status: • The High Priority GPI is permanently set to the highest priority. •... -
Page 28: Equalizer
Atmosphere User Manual Equalizer Equalizers allow raising or lowering the level of frequencies or ranges (bands) of frequencies to improve the overall sound of a source signal. Narrow bands can also be set to remove problems, like feedback or an acoustically induced low end. EQ enable/bypass in real-time;... -
Page 29: Ambient Noise Compensation - Anc
Atmosphere User Manual Ambient Noise Compensation - ANC Ambient Noise Compensation works in conjunction with the X-ANS (Ambient Noise Sensor Accessory; see X-ANS install placement rules). The X-ANS is installed in the zone where the noise levels vary depending on activity and where the audio level needs to be managed so it can always be heard. For example, this can be used for keeping an announcement clear and intelligible above the changing ambient noise in the zone. -
Page 30: Anc - Auto Mode
Atmosphere User Manual Enables Auto Mode. Like a smart thermostat, the system will learn the ideal noise-compensating gains to apply as the end-user adjusts zone gains while the ANS sensor is assigned to the zone. Because of this, Auto Mode should be used in a system where the end-user will have control over zone gains via Main UI, Virtual Wall Controller, or C-V / C-ZSV accessories. -
Page 31: Ambient Noise Sensor Placement
Atmosphere User Manual Ambient Noise Sensor Placement Correct placement of the X-ANS Ambient Noise Sensor is a critical, aspect of a good system installation. The X-ANS provides real-time noise level measurements to the Atmosphere’s system that, in turn, allows the system to continuously adjust the zone output level to maintain an intelligible announcement above the current noise level in the zone. -
Page 32: Rule-2
Atmosphere User Manual RULE 2: The sensor must be placed far enough away from the audience as not to pick up on individual conversations. Placing the sensor too close to the source of ambient noise will cause the system to adjust primarily based on noise in one small location. In most systems, the ambient noise that is being detected is due to crowds of people moving into and out of the zone. -
Page 33: Rule-4
Atmosphere User Manual RULE 4: The sensor should be placed towards the middle of the zone with nearly equal distance between the sensor and immediately adjacent loudspeakers. The reason behind this rule is to prevent similar issues encountered when considering Rule 1. If a sensor is located too close to any one speaker, the sound from that speaker could easily mask the ambient noise level from the sensor while an announcement is in progress. -
Page 34: Limiter
Atmosphere User Manual Limiter The Output Limiter is used primarily for taming transient peaks to keep the output signal strength below a specified level. This can help prevent damage to loudspeakers in the event of unintended loud signals like the drop of a microphone. Enable On/bypass and Active indicator. -
Page 35: Message Player Overview
Atmosphere User Manual Message Player Overview The message player feature allows uploading and configuring audio files to the AZM messages storage library where they can then be selected and used by the system to play a message, tone, bell, or chime, as a stand-alone function or as part of system events, schedules, or triggered third party device functions. -
Page 36: Audio Files
Atmosphere User Manual Audio Files Click on the Messages Toolbar to open the Messages page. Select Audio Files and Upload New File. Upload the .wav file from a computer. Audio Files must be: PCM-WAV (.wav - mono or stereo), 48kHz, any bit rate, 15 minutes maximum in length. The files can be sorted by Name, Size, Length, Date uploaded, or Deleted from the library. -
Page 37: Gpio Overview
Atmosphere User Manual GPIO Overview The GPIO interface allows external controllers to trigger pre setup activities or functions such as Scenes or Message Playbacks. There are six standard and one High-Priority input contact closure or voltage triggers. The High Priority input has additional settings specifically for Public Alert Messaging or where emergency systems need to be coordinated with the audio system. -
Page 38: Gpio Outputs (Gpo's)
Atmosphere User Manual GPIO – Outputs GPO 1 & 2 are either high or low voltage logic outputs only. Note: See Scenes GPO output settings: Set-High, Set-Low, Toggle, and Pulse adjustable in 50ms increments. Enter a name for the Function in one of 2 GPO ports. Select this to use system Faults to trigger the GPO for external devices. -
Page 39: High Priority
Atmosphere User Manual GPIO – High Priority Input Setting up a High Priority GPIO to Play an Alert Message In the UI, select the GPIO Toolbar then: Select High Priority Input. Enter a name for the function. Select the type of activation control. Select Wall Controllers to Lock &... -
Page 40: Scenes Overview
Atmosphere User Manual Scenes Overview The Scenes Toolbar lets you add a name and save a group of settings that can be recalled by name. Scenes can be recalled in the following ways: • By using the Scene UI to select it by name, then select Recall Scene. •... -
Page 41: Accessories Overview
Atmosphere User Manual Accessories Overview Six plug and play smart wall plate accessories can be populated on AZM accessory ports to add remote source inputs or provide zone control. Accessories include: • 3 x audio inputs- balanced mic/line XLR, dual RCA stereo summed with 3.5mm, and Bluetooth® audio wall plate inputs. •... - Page 42 Atmosphere User Manual Accessories Toolbar Device name will display or can be entered. The name will populate the UI wherever device is referred to. “+ADD NEW” allows up to 25 virtual controllers to be added and configured. Selecting QR Code icon will pop-up a QR code to scan, or, select Print and All QR codes to print all configured virtual controllers. Note: Mobile device must be connected to the same network as the AZM.
-
Page 43: Setting Up A Virtual Wall Controller
Atmosphere User Manual Setting up a virtual wall controller General Settings Page General settings: Select (#1) Accessories Toolbar – Virtual Controllers – (#6) for Settings. Import Settings – this allows a saved configuration file to be imported to duplicate an existing setup. Export Settings –... -
Page 44: Scenes
Atmosphere User Manual Scenes Page Open Scenes setup page Select from the list of pre-configured Scenes to be included to recall on mobile device. Set mute to allow it to be available on the mobile device to toggle. Messages Page Open Messages page Select from the list of pre-configured messages to be included on mobile device. -
Page 45: Print-Assemble-Place-Scan
Atmosphere User Manual Print, Assemble, Place, and Scan After creating virtual controllers, go back to the Accessories main page and select #4 “Print QR Codes.” This will bring up a print window with all QR codes that have been configured. Print and cutout the zone QR codes you would like to put in zones to be scanned. Mount in GEM holder and place on wall. -
Page 46: Setting Up Accessory Port Wall Controllers
Atmosphere User Manual Setting up Accessory Port wall controllers Note: see Inputs - Audio Wall Plates section for A-XLR, A-RCA, and A-BT settings UI pages General Settings Page for C-ZSV The General Settings page shows the connected port, with settings pages for Zones Source Volume, Scenes, Messages, Screen Settings, and Light Ring. -
Page 47: Zones, Source, And Volume Settings
Atmosphere User Manual Zones Source and Volume Page Select Zones Source Volume tab. Add zones you want to control on the mobile device. Select the zones to be displayed for control by the mobile device. Select input sources individually or ALL to enable all sources to be displayed as a selection list on mobile device. Set an acceptable range of volume to adjust. -
Page 48: Scenes
Atmosphere User Manual Scenes Page Select Scenes tab to open. Select the Scenes desired for recall on the mobile device controller. Select Mute control to be available on mobile device. This “Locate” click on, click off button will toggle the LED on the accessory to locate where it is installed. Flashing will automatically stop after 30 minutes. -
Page 49: Screen Settings
Atmosphere User Manual Screen Settings Page Select Screen Settings tab to open. Select the Theme for the C-ZSV display and time of day to change if desired. Set Screen Saver display and time to activate in X seconds. Set PIN Code to restrict access to this controller. This “Locate”... -
Page 50: C-V General Settings
Atmosphere User Manual General Settings Page for C-V The General Settings page shows the connected port, with settings pages for Zone Volume, and Light Ring. Accessory Name – displays the editable name for this accessory. Connected port ID, and location of the accessory on the port wiring bus. Import Settings –... -
Page 51: Zones Volume
Atmosphere User Manual Zones Volume Page The C-V acts like a traditional zone output volume controller. The Zone tab opens the list of zones available for control: AZM4=4 Zones, and the AZM8 = 8 Zones. Select the Zones to be displayed for control by the mobile device Set an acceptable range of volume to adjust. -
Page 52: X-Ans General Settings
Atmosphere User Manual General Settings Page for X-ANC The General Settings page shows the connected accessory port. Accessory Name – displays the editable name for this accessory. Connected Port ID, and location of the accessory on the port wiring bus. Import Settings –... - Page 53 Atmosphere User Manual Image 4 Image 5 Image 6 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 53 –...
-
Page 54: Scheduler
Atmosphere User Manual Scheduler The scheduler allows scheduling event actions just like scheduling a meeting on a calendar. Actions can be configured to take place in several ways when the Event Date/Time/Start-Stop takes place. Once scheduled, the event will show up on your dashboard as an upcoming event. The event log (Settings>Event Log) will show scheduled events that have taken place to confirm it is working. -
Page 55: Connection Diagram
Atmosphere User Manual Connection Diagram In the UI, select the Diagrams icon to open the diagram type selection page. Choose from Connection Diagram or Block Diagram. The Connection Diagram automatically populates all inputs and outputs as they are named. It also allows text fields for editing each one, including a notes window for network and GPIO settings. -
Page 56: Settings Page Overview
Atmosphere User Manual Settings Page Overview The Settings page is where all the device settings are located for configuration, updating, saving, and toubleshooting. Configurations This page provides utilities to back-up, move, and clone system configurations settings. • Import – click on import and find the saved system configuration file (.azm) on the pc where it was saved. Select file and it will upload to the AZM. -
Page 57: Network
Atmosphere User Manual Network The left panel is the wired connection and the right panel is the wireless connection. Both can be connected at the same time, with different IP addresses. In addition, the wireless can be configured as an access point to directly connect to the UI when a network isn’t available. This is useful when setting up the device prior to being on-site for install or if the site doesn’t yet have an active connection. -
Page 58: Device Settings
Atmosphere User Manual Device Settings This is where you can find global settings. • At the top is CPU usage meter and operational up timer. • Priority ducking dynamics setup – these settings adjust all ducking behavior system wide. • Factory Reset –... -
Page 59: Event Log
Atmosphere User Manual Event Log Event Log is where scheduled events and faults are logged, and time/date stamped. The tool bar allows you to sort by Time/Date, Type, and Detail, to assist searching for specific events. Licenses Software license agreements. User Account Manage registered user accounts. -
Page 60: Project Settings
Atmosphere User Manual Project Settings Name the project, and make any specific notes associated with the Project, Network, or GPIO settings. Note: These notes will also populate the printable connection diagram notes. 10. Theme Select Light/Dark background theme Note: This selection is also part of the initial log-in. 1601 JACK MCKAY BLVD. -
Page 61: Front Panel Display Menu Tree
Atmosphere User Manual Front Panel Display Menu Tree Select Source Zones List Change Volume Zones Mute Scenes List Start Scene Zone Control Scenes Messages List Play Message Messages IP Address Address Mode Ethernet Static IP Subnet Mask Gateway Mode Change Mode Wifi Network Access Point... -
Page 62: Specifications
Atmosphere User Manual Specifications System Type Signal Processor Output Power (Note 1) AZM4 AZM8 Mic / Line Inputs 4 (Euroblock) 6 (Euroblock) 2 (mono-summed) 4 (mono-summed) Line Outputs 4 (Euroblock) 8 (Euroblock) General Purpose Inputs 6 (Euroblock) 6 (Euroblock) High Priority Inputs 1 (Euroblock) 1 (Euroblock) General Purpose Outputs... - Page 63 Atmosphere User Manual Other Connections Contact Closure: Normally Open General Purpose Inputs Capable of Internal Pull-up to 5VDC via User Interface Voltage Input: 0 - 12VDC (1.3VDC Trigger Voltage) Contact Closure: Normally Open High Priority Input Capable of Internal Pull-up to 5VDC via User Interface Voltage Input: 0 - 12VDC (1.3VDC Trigger Voltage) Source Current: 10mA at 2VDC General Purpose Outputs...
- Page 64 Atmosphere User Manual Right Channel Color: Red Left Channel Color: White Sensitivity: -10dBV (Same as AZM) Maximum Input Voltage: +8dBu A-RCA Type: Mono-summed Pair Indicator: Green = Signal Presence, Red = Clip, Blue = Locate Dimensions: 1.78" x 4.2" x 1.5" Minimum Box Depth: 2.25"...
-
Page 65: Mechanical Line Drawings With Dimensions
Atmosphere User Manual Dimensional Drawings AZM4 8.5" (215.9mm) 1.7" (43.2mm) 11.78" (299.1mm) 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 65 –... - Page 66 Atmosphere User Manual Dimensional Drawings AZM8 17" (431.8mm) 1.7" (43.2mm) 11.78" (299.1mm) 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A. SUPPORT@ATLASIED.COM – 66 –...
- Page 67 Atmosphere User Manual Dimensional Drawings C-V, C-ZSV, A-RCA, A-BT, and X-ANS share the same dimensions 2.75" 1.86" (69.9mm) (47.2mm) 4.5" (114.3mm) 1.15" (29.1mm) A-XLR 2.75" 2.06" (69.9mm) (52.4mm) 4.5" (114.3mm) 1.71" (43.4mm) 1601 JACK MCKAY BLVD. TELEPHONE: (800) 876-3333 AtlasIED.com ENNIS, TEXAS 75119 U.S.A.
-
Page 68: Regulatory Information: Azm4 / Azm8 / A-Bt
Atmosphere User Manual Regulatory Information: Models: AZM4 / AZM8 / A-BT United States: (AZM4 / AZM8) Contains Transmitter Module FCC ID: 2ADHKATWILC1000U . (A-BT) Contains FCC ID: WAP3026 These devices comply with Part 15 of the FCC Rules, and the requirements for modular transmitter approval as detailed in FCC public Notice DA00-1407. -
Page 69: Compliance Certs/Fcc Statement
Atmosphere User Manual ISED RADIATION EXPOSURE STATEMENT FOR CANADA This equipment complies with ISED radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance between the radiator and your body. Cet équipement est conforme aux limites d’exposition aux radiations ISED prévues pour un environnement incontrôlé. -
Page 70: Limited Warranty
Atmosphere User Manual Limited Warranty All products manufactured by AtlasIED are warranted to the original dealer/installer, industrial or commercial purchaser to be free from defects in material and workmanship and to be in compliance with our published specifications, if any. This warranty shall extend from the date of purchase for a period of three years on all AtlasIED products, including SOUNDOLIER brand, and ATLAS SOUND brand products except as follows: one year on electronics and control systems;...
