- Page 1 PUR-Gas™ Purifier System Instructions READ AND COMPLY WITH THESE INSTRUCTIONS BEFORE INSTALLING, OPERATING, OR SERVICING MINT-0248 rev B...
-
Page 3: Table Of Contents
Table of Contents I. SERVICE ......................1 II. LIMITED WARRANTY ................... 2 III. USER RESPONSIBILITY ................. 3 IV. SAFETY PRECAUTIONS ................4 V. GENERAL DESCRIPTION ................4 VI. INSTALLATION OF A BASEPLATE ..............5 VII. STANDARD PURIFIER CARTRIDGE/BASEPLATE COMBINATION ....7 VIII. -
Page 5: Service
(All repairs must be made by MATHESON or an assigned and approved facility to maintain any warranties or guarantees). If the unit is under an applicable warranty, return the unit to MATHESON for repair or replacement. To arrange for warranty service, call 1-800-828-4313 and ask for the Warranty Administrator. -
Page 6: Limited Warranty
MATHESON's sole discretion, the equipment or part which is telephonically reported to be a problem to the local MATHESON Branch Location, and which if so advised, is returned with a written statement of the observed deficiency, not later than seven days... -
Page 7: User Responsibility
Should such repair or replacement become necessary, MATHESON recommends that a telephonic or written request for service advice be made to the MATHESON Equipment Engineering Group in Montgomeryville, Pennsylvania or to the nearest MATHESON branch location. -
Page 8: Safety Precautions
Use only original MATHESON baseplates; all warranties are voided with the use of a different model baseplate or other device. V. GENERAL DESCRIPTION MATHESON PUR-Gas purifier cartridges are designed for the purification of non- corrosive gases with low concentrations of contaminants to better than 6.0 grade (99.99990 %) purity. -
Page 9: Installation Of A Baseplate
VI. INSTALLATION OF A BASEPLATE NEVER INSTALL AN OXYGEN PURIFIER IN A BASEPLATE POSITION SUITED FOR AIR. It will result in instant saturation! A baseplate assembly can have either 1, 2, or 3 positions, depending on the number of gas purification applications. The following instructions are valid for each individual position on the baseplate. - Page 10 Remove the flushcap (4) by turning the knurled ring (5) counter-clockwise until the flushcap can be removed. Note: As long as a purifier cartridge is not installed, no gas will pass through the baseplate. 10. Install a new purifier cartridge on the baseplate. See SECTION VIII, Installing a Purifier Cartridge, for more detail.
-
Page 11: Standard Purifier Cartridge/Baseplate Combination
VII. STANDARD PURIFIER CARTRIDGE/BASEPLATE COMBINATION Purification System for GC/FID High Capacity: Triple + 2x Combi purifier on 3-position baseplate Purification System for Fuel Gas/FID 2x Combi purifier on 2-position baseplate Purification System for Carrier Gas with MS-ECD-NPD Triple purifier on 1-position baseplate... -
Page 12: Installing A Purifier Cartridge
The slightest leak allows moisture, oxygen and hydrocarbons to enter the system and contaminate the gas. All MATHESON PUR-Gas purifier cartridges are packed under Argon, except for the special Helium-specific GC/MS purifier cartridges. IX. REPLACEMENT OF A PURIFIER CARTRIDGE A purifier cartridge needs to be exchanged when the visual indicators start changing color. - Page 13 Explanation of Specifications on Purifier Cartridge Label Type of purifier cartridge MATHESON part number for purifier cartridge Indicator color before saturation Indicator color after saturation Installation date (to be filled in by user) Month/Year of production...
- Page 14 Specific Capacities of Purifier Types Capacity Type of Filter Hydro- (grams) (mL) carbons Moisture Oxygen 1000 Hydrocarbon specified Combi specified Triple specified Note: The data given in the table strongly depends on the level of gas purity prior to entering the purifier. Note: Replacement of the purifier cartridge is recommended at least every six months, regardless of the saturation level.
-
Page 15: Ordering Information
X. ORDERING INFORMATION MBAS-0014 1-Position Standard Baseplate (1/8” Brass Fittings) MBAS-0015 2-Position Standard Baseplate (1/8” Brass Fittings) MBAS-0016 3-Position Standard Baseplate (1/8” Brass Fittings) MBAS-0017 2-Position LC/MS Baseplate (1/4” Brass Fittings) MBAS-0018 1-Position Baseplate with 1/4” Brass Fittings MBAS-0019 2-Position Baseplate with 1/4” Brass Fittings MBAS-0020 3-Position Baseplate with 1/4”... - Page 16 Copyright 2019 Matheson Tri-Gas, Inc. All Rights Reserved. All contents of this document are subject to change without notice and do not represent a commitment on the part of Matheson Tri- Gas, Inc. Every effort is made to ensure the accuracy of this information. However, due to differences in actual and ongoing operational processes and product improvements and revisions, Matheson Tri-Gas, Inc.
