Solo PRONTO POST 42" Instructions

INSTRUCTIONS SOLO PRONTO POST 42"
B
A
Top
Step 1
Place the base (D) at the site of display, unwind the
tensaflex (E) and stretch out. Place the tensaflex
along the reference dots, with arrows pointing up.
Step 2
Attach the base velcro (D) to the tensaflex velcro (E).
Leave one of the ends loose.
Step 3
Set shelf (C) in the corresponding place indicated
by the velcro (take reference points into account).
Step 4
Set shelf (B) in the corresponding place indicated
by the velcro while centering and adjusting the
tensaflex (E) simultaneously (take reference points
into account).
Step 5
Place top (A) and press the two velcro faces
together. Make sure that each of the elements is in
perfect position taking the reference dots into
account.
Step 6
Door Installation Detach the tensaflex , two inches
from each side of the tops and shelves as shown in
the figure. Place the door (F) in the corresponding
space, open it and press the door frame velcro
against the tensaflex velcro (E).
Note: To disassemble, reverse the steps.
US Patent: 10/518,476
Colombian Patent: 02-054.774
Australian Patent: 2003242928
C
Shelves
I N S T R U C T I O N S
P A R T S
D
Base
Tensaflex
D
Step 1
C C
D
Step 3
Step 3
B
C
D
Step 5
estore.tradeshow-stuff.com
European Community Patent: 03760840.3
Mexican Patent: Pa/a/2005/000032, No 254022
Door
Posts
E
Step 2
E
Step 4
B
E
E
C
D
Step 6
Brazilian Patent: PI03121968-4
Support
E
D
B
E
E
C
D
E
E
