USER MANUAL
IVR-1200MPPT/IVR-2400MPPT
Solar Inverter

Advertisement

loading
Need help?

Need help?

Do you have a question about the IVR-1200MPPT and is the answer not in the manual?

Questions and answers

Sharman O'CONNOR
January 23, 2025

Our new Mecer IVR-1200MPPT Inverter's **** is always running

1 comments:
Mr. Anderson
February 10, 2025

The Mecer IVR-1200MPPT inverter may always be running because it is designed to provide continuous power to connected equipment. It prioritizes solar energy for power supply and switches to battery energy when solar power is insufficient. If the battery voltage drops to a low level, the inverter may use utility power as a backup. Additionally, if the inverter is configured to certain power source priorities (such as SBU mode), it will continue operating based on the available energy sources.

This answer is automatically generated

Subscribe to Our Youtube Channel

Summary of Contents for Mecer IVR-1200MPPT

  • Page 1 USER MANUAL IVR-1200MPPT/IVR-2400MPPT Solar Inverter...
  • Page 2: Table Of Contents

    Table of Contents 1. Introduction ..............................1 2. Important Safety Warning (SAVE THESE INSTRUCTIONS) ..............1 3. Product Overview ............................2 4. Installation ..............................2 5. Operation ............................... 5 6. Trouble Shooting ............................14 7. Specifications ............................. 15...
  • Page 3: Introduction

    1. Introduction Thank you for purchasing this solar inverter. This simple solar inverter is designed to power your home appliances or precious 3C electronics. It also can handle motor-type loads with high surge power such as vacuums, small freezers, or drills. With built-in MPPT solar charger, it can convert solar power to battery power and provide continuous power to connected equipment during night time.
  • Page 4: Product Overview

    CAUTION! Have plenty of fresh water and soap nearby in case battery acid contacts skin, clothing, or eyes. CAUTION! NEVER smoke or allow a spark or flame in vicinity of a battery. CAUTION! If a remote or automatic generator start system is used, disable the automatic starting circuit or disconnect the generator to prevent accident during servicing.
  • Page 5 1) Single battery connection: When using a single battery, its voltage must be equal to the Nominal DC Voltage of the unit Breaker 2) Multiple batteries in series connection(Refer to Fig. 3): All batteries must be equal in voltage and amp hour capacity.
  • Page 6 When selecting proper PV modules, please be sure to consider below requirements first: 1. Open circuit Voltage (Voc) of PV modules not exceeds max. PV array open circuit voltage of inverter. INVERTER MODEL IVR-1200MPPT IVR-2400MPPT Charging Current (MPPT) 55 Amp...
  • Page 7: Operation

    CAUTION: Please strictly follow installation procedure when you want to connect PV or DC terminals. Don’t touch the DC terminals and the PV terminals by hand. Failure to follow these instructions can result in serious electrical shock. 5. Operation Power On/Off Once the inverter has been properly installed, press the power switch to turn on the unit.
  • Page 8 LCD Display Display Function Input source information Indicates the AC input Indicates the PV input Indicates input voltage, input frequency, PV voltage, charging current, battery voltage, Configuration Program and Fault Information Indicates the setting programs. Indicates the warning and fault codes. Warning: Flashing with warning code Fault:...
  • Page 9 13.0V to 14.6V for model and increment of each IVR-1200MPPT click is 0.1V. Setting range is from 26.0V to 29.2V for model IVR-2400MPPT and increment of each click is 0.2V. IVR-1200MPPT model default setting: 13.5V Floating charging voltage...
  • Page 10 If self-defined is selected in program 02, this program can be set up. Setting range is from 13.0V to 14.6V for model and increment of each IVR-1200MPPT click is 0.1V. Setting range is from 26.0V to 29.2V for model and IVR-2400MPPT increment of each click is 0.2V.
  • Page 11 Available options in model: IVR-1200MPPT 11.0V 11.3V 11.5V (default) 11.8V 12.0V 12.3V 12.5V 12.8V Setting voltage point back to utility source when selecting “SBU Available options in model: IVR-2400MPPT priority” or “Solar 22.0V 22.5V 23.0V (default) first” in program 07.
  • Page 12 Available options in model: IVR-2400MPPT Battery fully 24.5V charged Setting voltage 25.5V point back to battery mode when selecting “SBU 26.5V 27V (default) 27.5V priority” or “Solar first” in program 07 If this inverter/charger is working in Line, Standby or Fault mode, charger source can be programmed as below: Utility first Utility will charge battery as first priority.
  • Page 13 Display Setting The LCD display information will be switched in turns by pressing “SCROLL” key. The selectable information is switched as below order: input voltage, input frequency, PV voltage, charging current, battery voltage, output voltage, output frequency, load percentage, load in Watt, load in VA, load in Watt, DC discharging current, main CPU Version and second CPU Version.
  • Page 14 Battery voltage=25.5V Secondary CPU version 00003.03 Secondary CPU Battery voltage version checking Output frequency=50Hz Output frequency Operating Mode Description Operation mode Description LCD display Charging by utility and PV energy. Standby mode Charging by utility. Utility input bypass to Note: output, charger *Standby mode: The inverter is available, LCD backlight...
  • Page 15 Fault Reference Code Fault Code Fault Event Icon on Fault Code Fault Event Icon on Output short circuit Fan locked Over load time out Over temperature Output voltage too Over charge high Warning Indicator Warning Code Warning Event Icon flashing Over load Battery low...
  • Page 16: Trouble Shooting

    6. Trouble Shooting Use the table below to solve minor problems. Problem LCD/LED/Buzzer Explanation / Possible cause What to do Charge the unit at least 8 Battery voltage is too low. hours. When power fails, Battery low alarm the backup time is Battery capacity is not full even Check the date code of the issue quickly.
  • Page 17: Specifications

    7. Specifications MODEL IVR-1200MPPT IVR-2400MPPT CAPACITY 1200VA/1000W 2400VA/1800W POWER FACTOR 0.83 0.75 INPUT Voltage 220-240 VAC Voltage Range 90-280 VAC Nominal Operating Frequency 50/60Hz Maximum Input Current OUTPUT Nominal Output Voltage 220-240 VAC Voltage Regulation (Batt. Mode) +/-10% Output Frequency Range...
