Summary of Contents for Liftket LSF 200/1-15
- Page 1 Operating Instructions Wire rope winch Type LSF 200/1-15 Please do not use the electric chain hoist before all operators have carefully read and understood this manual and signed the form on the rear cover.
- Page 2 LIFTKET Hoffmann GmbH Dresdener Straße 66-68 04808 Wurzen / Germany +49-3425-89 24-0 +49-3425-89 24-99 sales@liftket.de www.liftket.de Ho 08/2017 englisch Original operating instructions © 2017...
-
Page 3: Table Of Contents
Contents Safety advice ..............................5 Advice for the use of the wire rope winches ....................5 European regulations ............................. 5 Spare parts ..............................6 Technical overview ............................7 Explanation of type designation ........................7 Technical data of the wire rope winches ......................7 Assembly of the wire rope winch ........................ -
Page 5: Safety Advice
Safety advice Advice for the use of the wire rope winches The wire rope winches are designed to lift and to lower loads vertically in building and mounting trade and for different transportation tasks. Every other mode of use is prohibited and undertaken at the risk at of the operator. Refer to the manufacturer in advance for any special mode of use. -
Page 6: Spare Parts
Harmonized regulations EN ISO 12100:2010 Safety of machinery; Basic terminology, methodology EN 14492-2:2006+A1:2009 Cranes - Power driven winches and hoists EN ISO 13849-1:2008 Safety of machinery - Safety-related parts of control systems; General principles for design EN 60034-1:2004 Rotating electrical machines; Rating and performance EN 60034-5:2001 Rotating electrical machines;... -
Page 7: Technical Overview
Explanation of type designation Example: LSF 200 / 1 - 15 lifting speed [m/min] load capacity [kg] wire rope winch Technical data of the wire rope winches LSF 200/1-15 duty group FEM 9.511 V voltage 50 Hz, 3 phases kW motor power 0.55 kg... -
Page 8: Assembly Of The Wire Rope Winch
Assembly of the wire rope winch Wire rope winch with wall bracket dimension of the fastening points Figure 2: Assembly of the wire rope winch with wall bracket Prepare the assembly of the wire rope winch onto the wall according to the dimensions as shown in Figure 2. -
Page 9: Wire Rope Winch With Foot Support
Wire rope winch with foot support dimension of the fastening points Figure 3: Assembly of the wire rope winch with foot support Prepare the assembly of the wire rope winch on the wall according to the dimensions as shown in Figure 3. -
Page 10: Mains Connection
Mains connection Work on the electric installation may only be carried out by qualified electricians. The mains power supply (main incoming line conductor) must be disconnectable at all poles by means of a mains switch (in accordance with EN 60204-1 section 5.3). Check that the mains voltage agrees with that specified on the type plate. -
Page 11: Adjustment Of The Electric Limit Switch
4.3.2 Adjustment of the electric limit switch The load hook switches off the lifting motion by touching the actuator of the limit switch (see Figure 6). The switch point is pre-set at the factory. The limit switch should be activated immediately after the hook touches the actuator. The switch cam is adjustable and attached to the shaft by a small threaded pin. -
Page 12: Directions And Prohibitions For Use
Directions and prohibitions for use Directions for use Use the wire rope winch in accordance to the European regulations, harmonized regulations and local legislation and directives for different countries. Please pay particular attention to the rules for the prevention of accidents and the statutory regulations. -
Page 13: Maintenance
Maintenance All maintenance work must be carried out by trained specialists and may only be carried out if the wire rope winch is unloaded and the mains is switched off so that the power supply is disconnected. Test and maintenance works The operation of the wire rope winch is covered by the DGVU Vorschrift 54 §23 „Winches, lifts and pulleys“... -
Page 14: Replacement Of The Wire Rope
Replacement of the wire rope 6.2.1 Replacement of the wire rope at the hook tackle wire rope suspension plate wedge hook mounting Figure 8: View of the hook tackle (dismantled) Assembly instructions: • Screw off the suspension plate for wire rope. •... -
Page 15: Construction And Mode Of Operation Of The Dc Disk Brake
Construction and mode of operation of the DC disk brake Construction and mode of operation of the DC disk brake The DC disk brake consists of the magnetic body (1) concerning the magnetic coil and the mounting screws, the plate (2), the brake pressure springs, the brake disk with brake lining and the fan (3). -
Page 16: Check Of The Bfk 457-08
Check of the BFK 457-08 The air gap between the magnetic coil (1) and the anchor plate (2) should be checked once a year or if the brake distance is too long. If the air gap is too large, the brake has to be replaced. Assembly instructions: 1. -
Page 17: Lubrication
Lubrication Gear box: The gear box is already filled with oil by the manufacturer. The oil must be changed if the wire rope winch is going to be overhauled. The oil has to be disposed in accordance with the law of environmental protection. Use oil with a viscosity of 220 mm²/s at 40°C and an operating temperature of - 20°C to + 40°C. -
Page 18: Measures To Be Taken At The End Of The End Of The S.w.p
Measures to be taken at the end of the end of the S.W.P. After the wire rope winch or its components have reached the end of the S.W.P. the wire rope winch or its components have to be overhauled or to be taken finally out of operation. The parts have to be disposed in accordance to the law of environment protection. - Page 20 The operators who have been instructed to this wire rope winch and have read the manual and especially the safety advice. Name, Surname Date Signature The advice contained within this manual should be implemented by the appropriate skilled and qualified operators of wire rope winches.
