Adaptec APD-2940UW User Manual

Adaptec APD-2940UW User Manual

Fast and wide ultrascsi accelerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PowerDomain 2940UW/3940UW
Fast and Wide UltraSCSI Accelerator
A
AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA
A A
PowerDomain 2940UW/3940UW User's Guide
A A
A A
Stock Number: 510864-00, Rev. B
A
A A
Print Spec Number: 493742-00
A A
Current Date: 2/20/96
AAAA AAAA
A
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA
User's Guide
Page: Front Cover
ECN Date: 2/27/96
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
AAAA AAAA
A
A A
A A
A A
A
A A
A A
AAAA A A
A A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the APD-2940UW and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Adaptec APD-2940UW

Summary of Contents for Adaptec APD-2940UW

  • Page 1 PowerDomain 2940UW/3940UW Fast and Wide UltraSCSI Accelerator AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA User’s Guide Page: Front Cover...
  • Page 2 Adaptec, Inc. 691 South Milpitas Boulevard Milpitas, CA 95035 Copyright © 1996, Adaptec, Inc. All rights reserved. Adaptec and the Adaptec logo are trademarks of Adaptec, Inc. which may be registered in some jurisdictions. Printed in Singapore STOCK NO.: 510864-00, Rev. B CW 2/96 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide...

  • Page 3: Powerdomain 2940Uw

    PowerDomain 2940UW Fast and Wide UltraSCSI Accelerator AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
  • Page 4 Copyright Copyright © 1996 Adaptec, Inc. All rights reserved. No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, electronic, mechanical, photocopying, recording or otherwise, without the prior written consent of Adaptec, Inc., 691 South Milpitas Blvd., Milpitas, CA 95035.
  • Page 5 – The Adaptec Interactive Fax system provides product literature, answers to commonly asked questions, and current information about Adaptec products and services. The Adaptec Interactive Fax system is available 23 hours a day, 7 days a week. The Fax system is out of service 1 hour each day.
  • Page 6 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA Page: iv ECN Date: 2/27/96 AAAA AAAA AAAA AAAA...

  • Page 7: Table Of Contents

    Getting Started System Requirements 1-1 Hardware 1-1 Software 1-1 Tools and Equipment Required 1-2 Notes, Cautions, and Warnings 1-2 Installing the PowerDomain 2940UW/ 3940UW and Connecting SCSI Devices Installing the PowerDomain 2940UW/3940UW— Tower Models 2-2 Installing the PowerDomain 2940UW/3940UW— Desktop Models 2-11 Connecting SCSI Cables and Devices 2-19 Choosing SCSI Cables 2-21 Connecting Internal SCSI Devices 2-22...
  • Page 8 PowerDomain 2940UW/3940UW User’s Guide Opening and Using the PowerDomain Control Utility Opening the PowerDomain Control Utility 3-2 Using the PowerDomain Control Utility 3-3 Obtaining Additional SCSI Controller Information 3-4 Setting Termination 3-7 Updating Flash ROM 3-11 Setting Advanced Options 3-14 Setting Defaults 3-15 Target Options 3-16 Saving Settings 3-20...

  • Page 9: Getting Started

    Getting Started ® Welcome to Adaptec , and congratulations on your purchase of ™ the PowerDomain 2940UW/3940UW. Your new SCSI (Small Computer System Interface) accelerator card features Fast, reliable data transfer among the SCSI devices connected to it A configuration control utility that enables you to easily...

  • Page 10: Tools And Equipment Required

    PowerDomain 2940UW/3940UW User’s Guide Tools and Equipment Required To install the PowerDomain 2940UW/3940UW, you should have the following items on hand: At least one PowerDomain 2940UW/3940UW accelerator card The PowerDomain Control Utility diskette included with your accelerator card A medium-sized standard screwdriver A wrist grounding strap (optional) Notes, Cautions, and Warnings Always use care when handling any electrical equipment.
  • Page 11 Adaptec does not claim to have included in this document every condition or situation that might require a caution or warning notice. Be sure to consult the documentation for your computer and any connected equipment when you are installing the equipment or changing its configuration.
  • Page 12 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA Page: 1-4 ECN Date: 2/27/96 AAAA AAAA AAAA AAAA...

  • Page 13: Installing The Powerdomain 2940Uw/ 3940Uw And Connecting Scsi Devices

    Installing the PowerDomain 2940UW/ 3940UW and Connecting SCSI Devices This chapter tells you how to do the following: Install PowerDomain 2940UW/3940UW accelerator cards in your MacOS PCI-based system (both tower and desktop models) Connect internal and external SCSI devices to each PowerDomain 2940UW/3940UW installed Set SCSI chain termination Assign SCSI IDs...

  • Page 14: Installing The Powerdomain 2940Uw/3940Uw- Tower Models

    PowerDomain 2940UW/3940UW User’s Guide Installing the PowerDomain 2940UW/ 3940UW—Tower Models Note: If your tower model differs from the one illustrated in this manual, refer to your computer user documentation for instructions on installing an expansion card. (Instructions for desktop models begin on page 2-11.) To install the PowerDomain 2940UW/3940UW in your tower- model computer Turn...
  • Page 15 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Loosen the six large screws on the corners and sides of the computer ’s back panel. Do not completely remove the screws or the back panel. AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA...
  • Page 16 PowerDomain 2940UW/3940UW User’s Guide Remove the front cover. With the front of the computer facing you, place one hand on either side of the cover. Slide the cover toward you about 8 in. Lift the cover straight up and off the computer. Refer to your computer user documentation if you need more information about removing the cover.
  • Page 17 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Touch the metal part of the power supply to discharge any static electricity from your clothes and body. (Use a wrist grounding strap if you have one.) Caution: Be sure to do this step before you touch any parts inside the computer, install the PowerDomain 2940UW/3940UW, or install any internal devices.
  • Page 18 PowerDomain 2940UW/3940UW User’s Guide Lower the auxiliary fan. Release the auxiliary fan by squeezing the sides of the fan housing just below the power supply. Continue to squeeze while pulling down on the fan. Power Supply Squeeze here. AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev.
  • Page 19 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Choose an empty PCI expansion card slot, and remove its port access cover. To release the port access cover, spread the two tabs apart slightly that secure the cover to the computer case. WARNING: Be careful not to touch the sharp edges of the port access cover.
  • Page 20 PowerDomain 2940UW/3940UW User’s Guide Pull the front portion of the port access cover away from the computer case about 15 degrees. Pull the port access cover toward you to remove it from the computer. Store the port access cover in a safe place in case you need to use it again.
  • Page 21 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Position the PowerDomain 2940UW/3940UW accelerator card component-side down. Align the left side of the card with the port access opening, and align the connector with the expansion card slot. Expansion Card Slot Port Access Opening Insert the connector end of the PowerDomain 2940UW/...
  • Page 22 PowerDomain 2940UW/3940UW User’s Guide Position the card between the two tabs that secured the port access cover you removed in step 7. (You might need to pull the tabs apart slightly so the card fits between them.) At the same time, push the PowerDomain 2940UW/3940UW into the expansion card slot as far as it will go.

  • Page 23: Installing The Powerdomain 2940Uw/3940Uw- Desktop Models

    Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Installing the PowerDomain 2940UW/ 3940UW—Desktop Models Note: If your desktop model differs from the model illustrated in this manual, refer to your computer user documentation for instructions on installing an expansion card. (Instructions for tower models begin on page 2-2.) To install the PowerDomain 2940UW/3940UW in your desktop- model computer Turn...
  • Page 24 PowerDomain 2940UW/3940UW User’s Guide To release the cover from the computer chassis Position the computer so its front is facing you. Press and hold the release buttons. Pull the cover toward you approximately 2 in. 2-12 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev.
  • Page 25 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Lift the cover straight up and off the computer. Refer to your computer user documentation if you need more information about removing the cover. Touch the metal part of the power supply to discharge any static electricity from your clothes and body.
  • Page 26 PowerDomain 2940UW/3940UW User’s Guide Expansion Card Cover Open the expansion card cover. Expansion Card Cover Expansion Card Slot 2-14 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
  • Page 27 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Choose an empty PCI expansion card slot, and remove its port access cover. (The three port access covers are located at the back of the computer.) Grasp the port access cover with your right hand. WARNING: Be careful not to touch the sharp edges of the port access cover.
  • Page 28 PowerDomain 2940UW/3940UW User’s Guide Gently push the port access cover toward the inside of the computer with a finger of your left hand. At the same time, lift the port access cover straight up and out of the computer with your right hand. Store the port access cover in a safe place in case you need to use it again.
  • Page 29 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Position the PowerDomain 2940UW/3940UW accelerator card so its components face the expansion card cover. Align the left side of the card with the port access opening, and align the connector with the expansion card slot. Port Access Opening Expansion Card Slot Insert the connector end of the PowerDomain 2940UW/...
  • Page 30 PowerDomain 2940UW/3940UW User’s Guide Push the PowerDomain 2940UW/3940UW into the expansion card slot as far as it will go. Caution: Do not force the card. If you’re having trouble installing it, carefully remove the card and try installing it again. Pull on the accelerator card slightly.

  • Page 31: Connecting Scsi Cables And Devices

    Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Connecting SCSI Cables and Devices SCSI devices are connected by cables in one continuous line called the SCSI chain. A SCSI chain consists of an accelerator card and the SCSI cables and devices connected to it. The SCSI chain can include both internal and external devices.
  • Page 32 PowerDomain 2940UW/3940UW User’s Guide The PowerDomain 3940UW has one internal 16-bit (68-pin) and one external 16-bit (condensed 68-pin) Fast and Wide connector per channel (channels A and B). You can connect up to 15 SCSI devices (seven of which can be 8-bit Narrow devices) to each channel in any combination, for a maximum of 30 devices per card.

  • Page 33: Choosing Scsi Cables

    Note: Adaptec sells high-quality internal and external SCSI-2 cables, which you can purchase by calling Adaptec at the number listed on page iii. To assure reliable operation, the total length of the SCSI chain, including both internal and external cabling, should not exceed 6 m (19.5 ft).

  • Page 34: Connecting Internal Scsi Devices

    PowerDomain 2940UW/3940UW User’s Guide Any change in cable impedance, including the following – A change in wire gauge from one cable to the next – A change in the type of wire from one cable to the next – A change in the type of insulation from one cable to the next –...
  • Page 35 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices To attach devices to the 50-pin internal connector of the PowerDomain 2940UW, use a 50-pin Narrow ribbon cable. To attach devices to the 68-pin internal connectors of the PowerDomain 2940UW/3940UW, use 68-pin Wide ribbon cables. Make sure your SCSI ribbon cable(s) have enough connectors to accommodate all your internal SCSI devices.
  • Page 36 PowerDomain 2940UW/3940UW User’s Guide Caution: When arranging ribbon cables so they’ll fit in the computer, be careful not to crease them. 2-24 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
  • Page 37 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Routing the Cables—Tower Models Push one end of a 50- or 68-pin SCSI ribbon cable (as shown in the illustration on the right) through the opening between the upper and lower portions of the computer.
  • Page 38 PowerDomain 2940UW/3940UW User’s Guide Routing the Cables—Desktop Models If your computer has a processor card, grasp both ends of the processor card and pull it straight up and out of the computer. Processor Card Remove the access panel. To release the left side of the access panel, push it toward the expansion card cover.
  • Page 39 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Access Panel (Back of Computer) Expansion Card Cover AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA...
  • Page 40 PowerDomain 2940UW/3940UW User’s Guide Push one end of a 50- or 68-pin SCSI ribbon cable (as shown in the following illustration) through the opening created when you removed the access panel. Replace the processor card (if you have one). Continue with the next section, Connecting Internal Devices— Tower and Desktop Models.
  • Page 41 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Connecting Internal Devices— Tower and Desktop Models 50-pin Internal Connector (PowerDomain 2940UW only) To connect internal SCSI devices to the 50-pin internal connector of the PowerDomain 2940UW Connect the cable end referred to in step 1 on page 2-25 (for tower models) or in step 3 on page 2-28 (for desktop models) to the 50-pin internal accelerator card connector.
  • Page 42 PowerDomain 2940UW/3940UW User’s Guide Plug the last connector on the ribbon cable (opposite the end attached to the accelerator card) into the 50-pin SCSI connector on an internal SCSI device. SCSI Device To connect a second internal SCSI device, plug a free 50-pin SCSI ribbon cable connector into the SCSI connector on the second internal SCSI device.
  • Page 43 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices SCSI Device Note: Be sure to terminate the device at the end of the SCSI chain. (Termination is explained in Setting SCSI Chain Termination on page 2-48.) Be sure to check the documentation included with your SCSI device for any special installation instructions.
  • Page 44 PowerDomain 2940UW/3940UW User’s Guide 68-pin Internal SCSI Connector Plug the last connector on the ribbon cable (opposite the end attached to the accelerator card) into the 68-pin SCSI connector on an internal SCSI device. SCSI Device 2-32 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev.
  • Page 45 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices To connect a second internal SCSI device, plug a free 68-pin SCSI ribbon cable connector into the SCSI connector on the second internal SCSI device. Connect the second SCSI device here. Connected to the first SCSI device.

  • Page 46: Connecting External Scsi Devices-Tower Models

    PowerDomain 2940UW/3940UW User’s Guide Note: Be sure to terminate the device at the end of the SCSI chain. (Termination is explained in Setting SCSI Chain Termination on page 2-48.) Be sure to check the documentation included with your SCSI device for any special installation instructions. Connecting External SCSI Devices—Tower Models Note: Instructions for desktop models begin on...
  • Page 47 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices To reassemble the computer and restore power Lift the auxiliary fan back in place. Lift the auxiliary fan. The fan housing should touch all expansion cards installed in the computer. AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev.
  • Page 48 PowerDomain 2940UW/3940UW User’s Guide Replace the cover on the computer case. Align the cover with the case, and lower the cover onto the case. Push the cover back until it engages the back panel. 2-36 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev.
  • Page 49 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Tighten all six screws on the back panel. Reconnect the power cords to all external SCSI devices and to the computer. Turn the power to all external devices, and then turn the power to the computer. After the accelerator card is installed, you can change its configuration using the configuration control utility, which is explained in Chapter 3, Opening and Using the PowerDomain Control...
  • Page 50 Note: Mixing Wide (68-pin) and Narrow (50-pin) devices requires special work to ensure proper termination. Contact Adaptec Technical Support at the number shown on page ii for assistance. To connect external SCSI devices Attach one 68-pin SCSI cable connector to the...
  • Page 51 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Attach the connector at the other end of the external cable to either one of the SCSI connectors on the external SCSI device. SCSI Terminator To connect another external SCSI device Attach one end of a SCSI cable to the empty connector on the device you just connected to the computer.
  • Page 52 PowerDomain 2940UW/3940UW User’s Guide Repeat step 4 until you have connected all external SCSI devices. Note: Remember, you can connect up to 15 SCSI devices to the PowerDomain 2940UW (seven of which can be 8-bit Narrow devices) to a maximum of two connectors in various configurations.

  • Page 53: Connecting External Scsi Devices-Desktop Models

    Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Connecting External SCSI Devices—Desktop Models Before you connect external SCSI devices, you should reassemble your computer and restore power. Reassembling the Computer and Restoring Power Note: Instructions for tower models begin on page 2-34.
  • Page 54 PowerDomain 2940UW/3940UW User’s Guide To reassemble the computer and restore power Close the expansion card cover, and snap it into place. Expansion Card Cover 2-42 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA AAAA AAAA...
  • Page 55 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Replace the cover on the computer case. Align the cover with the case, and lower the cover onto the case so there is about a 2 in. gap between the back of the top cover and the back of the chassis.
  • Page 56 PowerDomain 2940UW/3940UW User’s Guide Slide the cover back until it snaps into place. Reconnect the power cords to all external SCSI devices and to the computer. Turn the power to all external devices, and then turn the power to the computer. After the accelerator card is installed, you can change its configuration using the configuration control utility, which is explained in Chapter 3, Opening and Using the PowerDomain...
  • Page 57 Note: Mixing Wide (68-pin) and Narrow (50-pin) devices requires special work to ensure proper termination. Contact Adaptec Technical Support at the number shown on page ii for assistance. To connect external SCSI devices Attach one 68-pin SCSI cable connector to the...
  • Page 58 PowerDomain 2940UW/3940UW User’s Guide Attach the connector at the other end of the external cable to either one of the SCSI connectors on the external SCSI device. To connect another external SCSI device Attach one end of a SCSI cable to the empty connector on the device you just connected to the computer.
  • Page 59 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Repeat step 4 until you have connected all external SCSI devices. Note: Remember, you can connect up to 15 SCSI devices to the PowerDomain 2940UW (seven of which can be 8-bit Narrow devices) to a maximum of two connectors in various configurations.

  • Page 60: Setting Scsi Chain Termination

    PowerDomain 2940UW/3940UW User’s Guide Setting SCSI Chain Termination Termination circuits must be either installed in or enabled on the first and last physical devices of the SCSI chain; otherwise, the chain will not operate properly. Incorrect termination can cause numerous problems such as missing drives, system error messages, applications reported as bad, failure to restart, or system hangs during restart.

  • Page 61: Setting Scsi Device Termination

    Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices Setting SCSI Device Termination Termination on some SCSI devices is controlled by a device (such as a switch) located close to the SCSI connector. On other SCSI devices, you must physically remove or install built-in terminators.
  • Page 62 PowerDomain 2940UW/3940UW User’s Guide Termination Enabled Termination Disabled Termination Disabled PowerDomain 2940UW with 50-pin Internal Devices If you attach internal SCSI devices to the PowerDomain 2940UW 50-pin internal SCSI connector and do not attach any external devices, you must enable termination on the last internal device in the chain and disable termination on the other devices.
  • Page 63 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices PowerDomain 2940UW with 50-pin and 68-pin Internal Devices When both the 50-pin and 68-pin internal connectors on the PowerDomain 2940UW have SCSI devices connected to them, you must enable termination on the last SCSI device connected to each connector, and you must set termination on the PowerDomain 2940UW to Automatic or Wide-to-narrow.
  • Page 64 PowerDomain 2940UW/3940UW User’s Guide PowerDomain 2940UW with 50-pin Internal and 68-pin External Devices When both the 50-pin (Narrow) internal and 68-pin (Wide) external connectors of the PowerDomain 2940UW have SCSI devices attached to them, you must enable termination on the last SCSI device attached to each connector, and you must set termination on the PowerDomain 2940UW to Automatic or Wide- to-narrow.
  • Page 65 Installing the PowerDomain 2940UW/3940UW and Connecting SCSI Devices PowerDomain 3940UW with 68-pin Internal and Condensed 68-pin External Devices When both the 68-pin internal and condensed 68-pin external connectors have SCSI devices attached to them, you must enable termination on the last SCSI device attached to each connector, and you must disable termination on the PowerDomain 3940UW.

  • Page 66: Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Aaaa Ecn Date:

    PowerDomain 2940UW/3940UW User’s Guide Setting SCSI IDs Each device on the SCSI chain, including the accelerator card, must have a unique SCSI ID. The computer uses the SCSI ID to identify the SCSI device on the SCSI chain. Setting SCSI IDs is a two-step process: Determine the SCSI ID of each device to be connected on the SCSI chain.

  • Page 67: Opening And Using The Powerdomain Control Utility

    Opening and Using the PowerDomain Control Utility The PowerDomain Control utility enables you to do the following for all installed PowerDomain 2940UW/3940UW accelerator cards—directly from your computer’s desktop: Obtain additional SCSI controller information Set termination Update a SCSI controller’s firmware by programming its flash ROM Set parity options Select an initiator SCSI ID...

  • Page 68: Opening The Powerdomain Control Utility

    PowerDomain 2940UW/3940UW User’s Guide Opening the PowerDomain Control Utility Before you begin this procedure, make a back-up copy of the PowerDomain Control Utility disk supplied with your PowerDomain 2940UW/3940UW accelerator card. Then store the original disk in a safe place. If you need information about making a back-up copy or about performing any other basic procedure, refer to your user documentation or request assistance from someone who knows...

  • Page 69: Using The Powerdomain Control Utility

    Opening and Using the PowerDomain Control Utility Drag the PowerDomain Control application icon onto your system hard disk drive, and place it in the folder of your choice. Eject the back-up disk, and put it away. Double-click the PowerDomain Control icon. The PowerDomain Control window appears.

  • Page 70: Obtaining Additional Scsi Controller Information

    PowerDomain 2940UW/3940UW User’s Guide Obtaining Additional SCSI Controller Information To obtain additional SCSI controller information From the Select a SCSI bus list, click the accelerator card for which you want additional SCSI controller information. The item becomes highlighted. The information in parentheses identifies the PCI slots on your motherboard in which PowerDomain 2940UW/3940UW accelerator cards are installed.
  • Page 71 Opening and Using the PowerDomain Control Utility While the PowerDomain Control window is active, choose Get Info from the Special menu or press Command–I. The Information dialog box appears. AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA...
  • Page 72 PowerDomain 2940UW/3940UW User’s Guide The table below defines each item in the Information dialog box. Information Item Definition vendor The name of the vendor of the selected SCSI bus HBA location The location of the selected SCSI bus HBA version The version number of the selected SCSI vendor The name of the vendor of the driver for...

  • Page 73: Setting Termination

    Opening and Using the PowerDomain Control Utility Setting Termination The PowerDomain Control utility provides the following termination options: Enable Click this button to enable termination on the SCSI chain highlighted in the Select a SCSI bus list. Disable Click this button to disable termination on the SCSI chain highlighted in the Select a SCSI bus list.
  • Page 74 PowerDomain 2940UW/3940UW User’s Guide PowerDomain 2940UW Termination Termination is initially set to Automatic on the PowerDomain 2940UW accelerator card. If you are using only one internal SCSI connector or only the external SCSI connector, you do not need to change this setting. In case your particular SCSI device does not respond appropriately to the Automatic setting, refer to the following table to determine which termination setting you should use:...
  • Page 75 Opening and Using the PowerDomain Control Utility PowerDomain 3940UW Termination Termination is initially set to Automatic on the PowerDomain 3940UW accelerator card. For each channel, if you are using only the internal SCSI connector or only the external SCSI connector, you do not need to change this setting.
  • Page 76 PowerDomain 2940UW/3940UW User’s Guide To set termination for a PowerDomain 2940UW/3940UW accelerator card From the Select a SCSI bus list, click the accelerator card (or channel) for which you want to set termination. The item becomes highlighted. Note: A check mark to the left of the selected SCSI bus indicates that any changes you made to that bus have not yet been saved.

  • Page 77: Updating Flash Rom

    PowerDomain Control utility to update flash ROM. You can recognize firmware files by their distinctive icon, such as the one shown below. Note: Adaptec will distribute new versions of the firmware files as they become available. AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev.
  • Page 78 PowerDomain 2940UW/3940UW User’s Guide To update the PowerDomain 2940UW/3940UW flash ROM Choose Update Flash ROM from the Special menu. The following dialog box appears: 3-12 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA AAAA AAAA...
  • Page 79 Opening and Using the PowerDomain Control Utility Click the file that contains the most recent version of the PowerDomain firmware, and click Open. A list of the PowerDomain 2940UW/3940UW accelerator cards installed in your system will appear in a dialog box similar to the following.

  • Page 80: Setting Advanced Options

    PowerDomain 2940UW/3940UW User’s Guide Setting Advanced Options Parity Options Click Parity on to enable parity checking. Click Parity off to disable parity checking. Parity Options are set to Parity on for most SCSI devices. (A check mark to the left of the selected SCSI bus indicates that any changes you made to that bus have not yet been saved.) Parity Options Select Initiator ID...

  • Page 81: Setting Defaults

    Opening and Using the PowerDomain Control Utility To change the Initiator ID, select an Initiator ID from the Select Initiator ID menu. The current Initiator ID is indicated by a filled circle on the left. (A check mark to the left of the selected SCSI bus indicates that any changes you made to that bus have not yet been saved.) Setting Defaults...

  • Page 82: Target Options

    PowerDomain 2940UW/3940UW User’s Guide Target Options A target is a device attached to a SCSI bus and identified by a target ID. Target ID numbers range from 0 to 7 for narrow devices and from 0 to 15 for wide devices. To access the target options Select the bus for which you want to set the target options.
  • Page 83 Opening and Using the PowerDomain Control Utility Select a SCSI ID List This list contains the following information for the selected target: SCSI ID Current Synchronous Transfer Rate. This setting is either async (asynchronous), indicating that synchronous negotiation is disabled, or nn MHz, where nn is the transfer rate (for example, 10 MHz).
  • Page 84 PowerDomain 2940UW/3940UW User’s Guide To specify the maximum synchronous transfer rate the SCSI accelerator card will accept from the selected device during negotiation, choose an item from the Synchronous Transfer Rate menu. Synchronous Transfer Rate Menu: UltraSCSI Not Selected The current synchronous transfer rate is indicated by a filled circle on the left.
  • Page 85 Opening and Using the PowerDomain Control Utility Click Enable to enable SCSI Disconnection; click Disable to disable SCSI Disconnection. (A check mark to the left of the selected target indicates that any changes you made to that target have not yet been saved.) Wide Negotiation Wide Negotiation is normally negotiated between the SCSI...

  • Page 86: Saving Settings

    PowerDomain 2940UW/3940UW User’s Guide UltraSCSI UltraSCSI provides faster bus transfer rates when used with UltraSCSI devices. To enable or disable UltraSCSI transfers for the selected bus (in the PowerDomain Control window), click the UltraSCSI checkbox. A checkmark indicates that UltraSCSI is enabled. When switching between UltraSCSI and Fast SCSI, all the target IDs’...

  • Page 87: Powerdomain Control Window

    Opening and Using the PowerDomain Control Utility PowerDomain Control Window When you have made all your changes in the PowerDomain Control window Click Revert to restore all PowerDomain Control window settings (not target options settings) as they were when you last opened the PowerDomain Control window or when you last clicked Set.

  • Page 88: Using Balloon Help

    PowerDomain 2940UW/3940UW User’s Guide Using Balloon Help The PowerDomain Control utility fully supports Balloon Help. Refer to your computer user documentation for instructions on using Balloon Help. Getting Information about the PowerDomain Control Utility The about box provides information about the PowerDomain Control utility, such as version number and copyright date.

  • Page 89: Quitting The Powerdomain Control Utility

    Opening and Using the PowerDomain Control Utility The following about box appears. To dismiss the about box, click in it. Quitting the PowerDomain Control Utility There are two ways to quit the PowerDomain Control utility: Choose Close from the File menu when the PowerDomain Control window is active.
  • Page 90 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA Page: 3-24 ECN Date: 2/27/96 AAAA AAAA AAAA AAAA...

  • Page 91: Troubleshooting

    SCSI chain. If you continue to have problems after trying the solutions listed in this section, call Adaptec Technical Support at the number listed on page ii. AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide...
  • Page 92 PowerDomain 2940UW/3940UW User’s Guide Answer the following questions first if a problem occurs during installation. Are the power cables and SCSI cables properly connected? (See Connecting SCSI Cables and Devices on page 2-19.) Follow the instructions in the computer and SCSI device documentation for installing SCSI devices.

  • Page 93: Error Messages

    Error Messages Most error messages tell you what problem has occurred. Whenever you see an error message, contact Adaptec Customer Support as directed on page ii. The following illustration shows an example of a PowerDomain Control error message. AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev.
  • Page 94 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA Page: 4-4 ECN Date: 2/27/96 AAAA AAAA AAAA AAAA...

  • Page 95: A Product Specifications

    Product Specifications System Interface Peripheral Component Interconnect (PCI) Host bus transfer up to 133 MB/sec burst rate Bus master DMA interface protocol Unit Connectivity (Single-ended) PowerDomain 2940UW One internal and one external 68-pin connector (Wide) One internal 50-pin connector (Fast) Up to 15 devices (Fast and/or Wide) can be connected PowerDomain 3940UW Two internal 68-pin connectors (Wide)

  • Page 96: Speed

    PowerDomain 2940UW/3940UW User’s Guide Speed Up to 6.0 MB/sec asynchronous burst rate Up to 10 MB/sec synchronous Fast 8-bit burst rate Up to 20 MB/sec synchronous Fast and Wide 16-bit burst rate Up to 20 MB/sec synchronous Ultra 8-bit burst rate Up to 40 MB/sec synchronous Ultra and Wide 16-bit burst rate Dimensions (Standard PCI Bus Form Factor)
  • Page 97 2-20 choosing characteristics 2-21 length restrictions 2-21, 2-22 connecting 2-19 ordering from Adaptec iii caution notice, explanation of 1-2 channel/slot identifier 3-4 check mark, meaning of in Select a SCSI bus list 3-10 in Select a SCSI ID (target)
  • Page 98 PowerDomain 2940UW/3940UW User’s Guide Disable Negotiation option 3-18 disassembling the computer desktop models 2-11 tower models 2-3 disconnection, SCSI, setting 3-18 Done button 3-20 Enable (termination) option 3-7 equipment required for installation 1-2 error messages 4-3 external SCSI devices, connecting 2-34, 2-38, 2-41, 2-45 firmware files icon 3-11 firmware, updating 3-11 flash ROM, updating 3-11...
  • Page 99 2-19 caution to install only single- ended devices 2-20 choosing characteristics 2-21 length restrictions 2-21, 2-22 connecting 2-19 ordering from Adaptec iii SCSI chain definition of 2-19 termination, setting 2-48 SCSI controller information, additional, obtaining 3-4 Index-3 Page: Index-3...
  • Page 100 PowerDomain 2940UW/3940UW User’s Guide SCSI devices connecting 2-19 external, connecting 2-34, 2-38, 2-41, 2-45 internal, connecting 2-22 termination, setting 2-49 SCSI Disconnection, setting 3-18 SCSI IDs definition of 2-54 setting 2-54 Select a SCSI bus list, contents of 3-4 Select a SCSI ID list, contents of 3-17 Select Initiator ID menu 3-14 Set button...
  • Page 101 UltraSCSI setting and synchronous transfer rate 3-18 UltraSCSI transfers, enabling 3-20 unit connectivity A-1 Update Flash ROM command 3-12 using the PowerDomain Control utility 3-3 warning notice, explanation of 1-2 Wide Negotiation, setting 3-19 Wide-to-narrow option 3-7 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev.
  • Page 102 AAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAAA PowerDomain 2940UW/3940UW User’s Guide Stock Number: 510864-00, Rev. B Print Spec Number: 493742-00 Current Date: 2/20/96 AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA AAAA Page: Index-6 ECN Date: 2/27/96 AAAA AAAA AAAA AAAA...
