JTS MA-XU Quick Manual

Speci cations
Input : XLR
Input Impedance : 10K
Input Gain Range : 35dB
Headphone Jack : 3.5mm stereo
Output：50mW (16 )
Indicator : USB.................Blue
Phantom.......RED
Peak Level.....Green : Signal
Red : Peak
USB Connector : B type , Digital audio interface
warrants that this product will be free from defects in materials and workmanship for one
year. Please contact your local dealer if the product encounters any problem. Make sure to return
the proof of purchase date with any warranty claim.
59010-096-03
Sampling Rate :
DAC: 32,44.1 , 48KHz
ADC: 8 , 11.025 , 16 , 22.05 , 32 , 44.1 , 48KHz
Bit Depth : 16-Bit
USB Type : USB 1.1 / USB 2.0
Phantom Power : 48V±2V,15mA
Frequency Response : 25~20KHz±3dB
Power consumption : 2.2W
Dimension (mm) : 117*31*28
Weight : 95g
PROFESSIONAL CO., LTD
No.148, Industry 9th Rd., Dali Dist., Taichung City
41280, Taiwan (R.O.C.)
TEL:886-4-24938803 FAX:886-4-24914890
E-mail:jts@jts.com.tw
www.jts.com.tw
MA-XU
XLR to USB Adapter
T
his XLR-to-USB adapter can use all your dynamic or condenser microphones
to digital record. Switchable phantom power is provided. The MA-XU features
built in headphone monitoring with easy control of the balance between
microphone and playback audio. The advanced technology renders the
product latency free.
