- Page 1 RangePro ® Using the Ultimate Duo 400W Charger with a RangePro X8 RP6S24KHDA Battery Pack Toll Free: +1 (800) 628-3119 Phone: +1 (301) 263-7321 Support: https://terraview.com/contact/ Web: www.terraview.com Part Number: TSN0001, Rev. A Revised: January 17, 2020...
- Page 2 Using the D400 Charger with a RangePro X8 Battery Contents Introduction ............................3 Modify and Verify System Settings ....................... 4 Program Battery Memory Charge Settings ................... 5 Balance Charge the Battery using Battery Memory #1 ................ 6 Troubleshooting Common Charging Errors ..................7 ©...
- Page 3 Using the D400 Charger with a RangePro X8 Battery 1. Introduction The Range Pro X8 RP6S24KHDA is a dual 6S2P, 24,000 mAh, high density, battery pack consisting of two independent 6S2P Lithium Ion Polymer battery packs installed in a single battery cage. The battery packs are impedance matched at the factory, placed in a common cage, and wired independently to a single connector.
- Page 4 Using the D400 Charger with a RangePro X8 Battery 2. Modify and Verify System Settings Verify the correct system settings for BOTH charging channels using the following steps. a. Power on the Ultimate Duo 400W Charger (D400). b. Press the STATUS “+” or “–“ button for the channel until the display screen reads: BATT/PROGRAM SYSTEM SETTING->...
- Page 5 Using the D400 Charger with a RangePro X8 Battery 3. Program Battery Memory Charge Settings Verify the correct Battery Memory settings for BOTH charging channels using the following steps. a. Power on the Ultimate Duo 400W Charger (D400). b. Press the STATUS “+” or “–“ button for the channel until the screen reads:...
- Page 6 Using the D400 Charger with a RangePro X8 Battery 4. Balance Charge the Battery using Battery Memory #1 a. Start up the Ultimate Duo 400W Charger (D400) b. Press the STATUS “+” or “–“ button for the channel until the display screen reads:...
- Page 7 Using the D400 Charger with a RangePro X8 Battery 5. Troubleshooting Common Charging Errors a. The channel times out before charging is complete Error Message: OVER TIME LIMIT ii. In the system settings, (1) set the Safety Timer to OFF to prevent this from ever happening, OR...
- Page 8 Using the D400 Charger with a RangePro X8 Battery ii. When using the LiHV model as a basis for a customized program, if the total battery voltage is below 20.4 volts (3.4 volts per cell), the charger will only trickle charge at 0.1A until the battery reaches the minimum voltage threshold.
