EN AQUA LUNG SEAFLARE SERIES DIVING LIGHTS
PRODUCT FEATURES
Type Ⅲ military hard-anodized finishing for abrasion and corrosion resistance.
The impact protected body is made of high-end AL-6061 T6 Aircraft-grade aluminum.
4mm hardened glass lens provides optimal pressure- and scratch resistance.
Regulated power supply maintains constant current output for a steady and constant light source.
Reverse polarity protection: Torch electronics prevent damage when accidentally installing the battery
wrong.
Over-heat protection prevents high temperature influencing the electronic components.
Titanium button switch for easy on/off operation and quick mode changing.
Double O-ring sealed to ensure waterproof function down to 150 meters (490 foot).
Standard accessories: Spare O-rings, strap with springless cord lock, PCB protected Lithium battery,
LCD intelligent charger, user manual and kraft packaging.
Special accessories: Colored deflector (patent pending) for diver identification at night and glow-in-
the-dark recovery option.
OPERATION
Push the button switch and circulate between a different brightness according to your current use and
need
1) Brightness:
With the light turned off, press the button once to turn the light on.
With the light on, press the button down repeatedly to cycle through the following output: High-Middle-Low
SEAFLARE PRO special feature: When not in use for more than 3 minutes, the SEAFLARE PRO will enter a
protection mode and can only be activated by pressing the button for more than 3 seconds.
2) Self-check:
When installing the battery, the light turns on at low mode in order to confirm that the light and its
electronics are working correctly.
SEAFLARE MINI: PRODUCT SPECIFICATION
11 degree narrow beam LED diving light, suitable for both recreational scuba diving and surface use.
Light source 1 x Cree XM-L2(U4) led, max 900 lumens output
Powered by 1 x 18650 rechargeable lithium battery, the maximum runtime reaches up to 10h
TECHNICAL PARAMETERS SEAFLARE MINI:
Notice: This data may vary slightly during different condition use due to battery temperature, individual
usage habits and other environmental factors.
ANSI
Lumen Output
Runtime(1 x 18650)
Luminous Intensity
Beam Angle
Drop Resistance
Waterproof Grade
Dimension
Net Weight
High
900 lumens
3 hours
IPX-8,underwater 150 meters
30 mm(Head Dia) X 30 mm(Body dia) X 140 mm(Length)
144 g (Excluding battery)
Medium
200 lumens
4 hours
5000 cd
11°
1.5 meters
Low
100 lumens
10 hours
