Skywatch SKY899 Installation Manual

Traffic alert/advisory system
Hide thumbs

Advertisement

Quick Links

Download this manual
3.1
INTRODUCTION
This section contains checkout procedures that will validate the installation and return to service of the
SKY899 installed with a WX-1000/SKY497 display using TT391 Flightline Tester. Detailed setup,
operation and maintenance information for the TT391 Flightline Tester is provided in the TT391
Instruction Manual.
Each time the TRC, directional antenna, or directional antenna cables
(including connectors) are installed, removed or replaced, the TRC must be
calibrated to the directional antenna (refer to paragraphs 3.3.2 & 4.4.3).
1. This procedure assumes familiarity with the set up and operation of the
TT391 Flightline Tester.
2. All test equipment used in completing these tests shall be calibrated in
accordance with the manufacturer's recommendations.
3. This section provides checkout information for the SKY899 using the
WX-1000 Display. If using an alternate display use Appendix F for
installation checkout.
4. Checkout of the WX-1000 processor should be done in accordance
with the procedures detailed in the WX-1000 Installation Manual.
Table 3-1 lists the installation checkout procedures that should be used depending upon which display is
installed and which tester is being used.
Display
WX-1000 Display
Alternate Display
009-11900-001
Revision F
The document reference is online, please check the correspondence between the online documentation and the printed version.
SKY899
Installation Manual
Section 3
Installation Checkout
CAUTION
NOTES
Table 3-1: List of Installation Checkout Procedures
Flightline Tester
TCAS-201
TIC T-49C
IFR-6000
TCAS-201
TIC T-49C
IFR-6000
Installation Checkout
Procedure
TT-391
Section 3
Appendix C
Appendix D
Appendix G
TT-391
Appendix F
Appendix C
Appendix D
Appendix G
Installation Checkout - Page 3-1
July 18, 2013
