Speedway 7253 Manual

3,000 lb 12 volt winch with roller fairlead
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
3,000 LB 12 VOLT WINCH
WITH ROLLER FAIRLEAD
This product contains or, when used, produces a chemical
known to the State of California to cause cancer and birth
defects or other reproductive harm.
(California Health & Safety Code § 25249.5, et seq.)
Please carefully read and save these instructions before attempting to assemble, maintain, install, or operate this product.
Observe all safety information to protect yourself and others. Failure to observe the instructions may result in property
damage and/or personal injury. Please keep instructions for future reference.
For warranty purchases, please keep your dated proof of purchase. File or attach to the manual for safe keeping.
For Customer Service, Call 1-800-348-5004
or e-mail feedback@natitools.com
WARNING
*Actual product may vary slightly
07253
08/2016

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 7253 and is the answer not in the manual?

Questions and answers

Summary of Contents for Speedway 7253

  • Page 1 3,000 LB 12 VOLT WINCH WITH ROLLER FAIRLEAD WARNING This product contains or, when used, produces a chemical known to the State of California to cause cancer and birth defects or other reproductive harm. (California Health & Safety Code § 25249.5, et seq.) *Actual product may vary slightly Please carefully read and save these instructions before attempting to assemble, maintain, install, or operate this product.

  • Page 2: General Safety Precautions

    GENERAL SAFETY PRECAUTIONS WARNING: FAILURE TO READ AND FOLLOW THE SAFETY INSTRUCTIONS IN THIS OWNER’S MANUAL BEFORE INSTALLING OR USING YOUR ELECTRIC WINCH COULD RESULT IN DAMAGE TO YOUR WINCH AND SERIOUS OR FATAL INJURY!! Check all safety and environmental conditions prior and during use. Before use, ensure that you are familiar with all winching performance and operation such as speed &...

  • Page 3: Moving Parts Entanglement Hazard

    GENERAL SAFETY PRECAUTIONS CAUTION CUT AND BURN HAZARD To avoid injury to hands and fingers: • Always wear heavy leather gloves when handling a wire rope. • Never let wire rope slip through your hands. • Always be aware of possible hot surface at winch motor, drum or wire rope during or after winch use.

  • Page 4: Wire Connection

    WINCH & ROLLER FAIRLEAD MOUNTING 1. It is very important that the winch shall be mounted on a flat hard surface in order to make sure the motor, drum and gearbox housing are aligned correctly. 2. If a different mounting plate is used, the thickness shall be 5 mm (3/16”). If different hardware is used, it must be grade 8 minimum.
  • Page 5 HANDLEBAR REMOTE CONTROL MOUNTING Handlebar mounted trigger switch can be operated without removing your hand from the grip. • It is recommended that the switch be installed on the left handlebar. A piece of electrical tape around the handlebar will help prevent rotation of mount on the handle bar. •...
  • Page 6 FREESPOOL FUNTION The freespool allows rapid pay-out of the wire rope for hooking onto a load or anchor points and is operated by a freespool shifter located on the end of the winch. 1). To engage the freespool, turn the freespool shifter counter-clockwise to the “Engaged” position.

  • Page 7: Check The System

    7). It is very important that the winch shall be mounted on a flat surface, with the wire rope feeding form the bottom of the drum. 8). To rewind wire rope on the drum correctly , it is necessary to keep a slight load on the wire rope while cable in.

  • Page 8: Troubleshooting

    TROUBLE SHOOTING When the winch fails to operate after several attempts, or if there is any fault operation while winching, check followings. Symptom Possible Cause Remedy Cut circuit or loosing Check battery cable. Weak battery or insufficient power Recharge or replace battery Damaged over load protector Replace over load protector Loose connection of wirings...

  • Page 9: Parts List & Assembly Diagram

    PARTS LIST & ASSEMBLY DIAGRAM Part Description Quantity Part Description Quantity Motor Cover Drum Motor Shell Plastic Plate Rotor Triangle Plate Bear ing Base Motor Base Clutch Planetary Gear Steel Cable Static Ring Gear Mounting Plate Plastic Plate Roller Fairlead Tie Rod Hook Shaft...
  • Page 10 Limited Manufacturer Warranty North American Tool Industries (NATI) makes every effort to ensure that this product meets high quality and durability standards. NATI warrants to the original retail consumer a 1-year limited warranty from the date the product was purchased at retail and each product is free from defects in materials.
