Thank you for purchasing
Before using the unit for the first time, please be sure to read this instruction manual
carefully and use the unit properly. Please keep this instruction manual on hand for
future reference.
ScaleTelligence
®
Bluetooth
Smart Scale
Sync your progress wirelessly to any Bluetooth
device.
Smartphone not required for scale use.
Works with: iOS7.0 and above with Bluetooth
Android 4.3 and above with Bluetooth
App is compatible with iPhone Health and Google Fit.
®
ScaleTelligence
T and R International, LLC
1 - 18
®
Scale.
®
smart ready
®
4.0 and above
®
4.0 and above
Advertisement
Table of Contents
Summary of Contents for T&R ScaleTelligence
- Page 1 ® ScaleTelligence ® Bluetooth Smart Scale ® Sync your progress wirelessly to any Bluetooth smart ready device. Smartphone not required for scale use. Works with: iOS7.0 and above with Bluetooth ® 4.0 and above ® Android 4.3 and above with Bluetooth 4.0 and above...
-
Page 2: Table Of Contents
Contents (English) 1 Safety Information – Page 3 ® Smart Scale Care • Bluetooth • How to Ensure Accurate Readings 2 Product Description – Page 4 • Specification • Software • Adding the batteries ® • How does the Bluetooth Smart Scale work •... -
Page 3: Safety Information
Safety Information Warning This product should not be used by individuals with a pacemaker or other implanted medical devices as it passes a low level electrical signal through the body which may interfere with its operation. This product is also not suitable for women during pregnancy! This body scale is intended for adults (ages 18-100) with inactive to moderately active lifestyles. -
Page 4: Product Description
Product Description Specification: Display: All data displayed when power on Capacity: 3kgs-180kgs/6.6lbs-396lbs Division: 1D=100g/0.2lb Unit: KG/LB/ST Voltage: 4.5V Battery: 3 *AAA battery Display: 84mm/3.3 inches Blue backlit LCD screen Low battery indication: 2.4V±0.2V, display “Lo” and power off Current: ≤25mA Standby current: ≤10μA Overload indication: overload more than 2.5kgs, total 182.5kgs display “Err”... -
Page 5: How Does The Bluetooth ® Smart Scale Work
Remove the batteries if you are planning to store the device for a long period of time. We hope you use your device for many years of course, but long periods of storage with the batteries in place may damage the device and will cause the batteries to discharge. Replace the set of batteries (3x AAA) in the right direction when the LCD words twinkling and further show "LO". -
Page 6: Getting Started
Getting Started ® This following steps will instruct you how to use the Bluetooth Smart Scale: 1) Install the Free OKOK International App to Your iOS or Android Smartphone or Tablet, register as user. ® 2) Pair the Bluetooth Smart Scale to your Smartphone or tablet and start measuring and start measuring. -
Page 7: Register As A User
1) Install Free OKOK International App to Your iOS or Android Smartphone or Tablet, register as a user. ® Note: The Bluetooth Smart Scale uploads your data directly to your Free OKOK International account via your Smartphone or tablet which must be Bluetooth ®... - Page 8 Register for a Free Account Once you have installed the OKOK International App, open the App making sure your phone or tablets is connected to the internet or web for the first time. If you have already registered, you can login to your account. Click Login. If you have not previously registered, then follow below procedure: Join Us --->...
- Page 9 2) Pair the Bluetooth ® Smart Scale to your Smartphone or tablet and start measuring. To start taking measurements first, you need to pair the scale and phone or tablet. Insert/replace the batteries. Please remove the battery cover underneath the scale and insert 3 AAA batteries (included) into your device.
- Page 10 or you can click the left corner “ ” icon. Click “Settings”, then click “My Scale”. Click “Bind/Pair OKOK Bluetooth ® Scale”. Either way will pop up following user interface. Follow it, stand on the scale to wake up scale (the Bluetooth for the scale will function automatically when the scale is pressed), ensuring the LCD display is always lit when you pair the devices.
- Page 11 Note: You only need to pair the device the first time, once paired all subsequent usage should automatically pair to the device as long as the device Bluetooth ® and scale is both ON. You may encounter the situation that data can not been synced to smartphone/tablet though paired or paired a long time ago.
-
Page 12: How To Take Routine Reading And Explore The Functions
3) How to take routine readings and explore the App functions Understanding your information The information for each person that can be uploaded is: Weight (kg or lb), Fat (%), Bone Mass, Muscle (%), Water (%), Visceral Fat (%), BMR and BMI. You can then view these data. - Page 13 Water % Total Body Water (TBW) as a percentage gives us an understanding of our hydration level. Water is a vital element in the majority of the body’s functions and can be found in every cell, tissue, and organ. A healthy TBW% needs to be maintained to ensure that we are operating at maximum efficiency.
- Page 14 App Functions: (New features added and amended continuously, please subject to newest APP. ) Click the left corner " " icon to direct to Navigation Menu: Displaying weight and body fat, you can scroll down to see histories. A single tap on “weight” or “fat” area will pop up the automatically generated report, scoring your body health status and giving you advice.
- Page 15 It will display you maximum, minimum, and average weight, body fat percentage, water percentage, muscle mass percentage, bone mass percentage in certain Week, month, quarter periods. The generated curves help you easily see the trend of these data. Select family members Share with Facebook, Twitter Slide left/right to view curves of weight, BMI, body fat, muscle, bone,...
-
Page 16: Declaration
Settings Change password / Log out Pair Scale to smartphone or tablet Set height unit: meter/inch, set weight unit: kg/lb Remind you to have a measurement at certain time Leave your comments Official website for OKOK International Agreement and license Software information and updates Expend mobile data or not Save harddrive space... -
Page 17: Health Disclaimer And Warranty
Stepping off scale after or during usage will safely terminate usage session immediately. Warranty ScaleTelligence ® scale is warranted against defects in materials or workmanship for one year of the original purchaser from date of retail purchase. - Page 18 This device complies with CE EN60950 EN62479 EN301489 EN300328 Manufactured in P.R. China ® ScaleTelligence ©2016 T and R International, LLC and its affiliated companies. All rights reserved. iPad, iPhone, iPod touch are trademarks of Apple Inc. Android is a trademark of Google Inc.
