Amwell Minima Fixing Instructions

Hide thumbs

Advertisement

Quick Links

Download this manual
Delivery Note Number:
Fixing Instructions
Minima

Advertisement

loading
Need help?

Need help?

Do you have a question about the Minima and is the answer not in the manual?

Questions and answers

Summary of Contents for Amwell Minima

  • Page 1 Delivery Note Number: Fixing Instructions Minima...

  • Page 2: Cleaning And Maintenance

    It is imperative that the as required. General Comments: In order to avoid water marks/ lime scale build up, standing water should be removed from horizontal surfaces. Any water that has splashed onto a panel edge should be removed immediately. Minima Page 2...
  • Page 3 • In order to eliminate machine-cutting imperfections created at the edges of the Compact, sand with a 300 • To obtain darker edges, rub the edge with a cloth soaked in linseed oil or wax. Leave to dry for 30 minutes and wipe off. Sharp edges must be smoothed to avoid injury. Minima Page 3...
  • Page 4 Typical Cubicle Layout Minima Page 4...
  • Page 5 1. T-Section 1. Channel bracket 2. Drill to suit wall type 2. Drill to suit wall type 3. No. 8 x 2” csk screws 3. No. 8 x 2” csk screws Minima Page 5...
  • Page 6 Pedestal Fixing Details iii) 1. Pedestal body 2. Pedestal base 4. Rawl plug 5. 50mm x 5mm csk screw 6. Cover rose Minima Page 6...
  • Page 7 1. T-section 2. Partition 3. Channel bracket 4. Pedestal body 5. Drill 4.5mm dia. through hole Minima Page 7...
  • Page 8 6. Drill 5mm dia. holes 13mm deep (to line up with holes in t-section) 7. M5 x 12mm snake eye screws 8. Drill 8mm dia. through holes 9. M6 x 14mm csk socket stainless steel screw 10. Multirol barrel 11. T-nut screw 12. Allen key Minima Page 8...
  • Page 9 7. Drill 4.5mm dia. holes 13mm deep (to line up with holes in T-section) 8. M5 x 12mm snake eye screws 9. Drill 8mm dia. through holes 10. M6 x 14mm csk socket stainless steel screw 11. Multirol barrel Minima Page 9...
  • Page 10 Wall End Pilaster Extrusion Fixing Details A = 100mm support block (supplied by others) 1. Wall end pilaster block 2. Wall end pilaster extrusion 3. Drill to suit wall type 4. No.10 x 3” screws Minima Page 10...
  • Page 11 If possible always ensure that cut end is positioned against wall iii) 1. Headrail 2. Circular Saw 3. Pilaster 4. Partition 5. Drill 4mm dia. hole into pilaster wooden insert 6. No. 10 x 75mm round head screw Minima Page 11...
  • Page 12 For Inward Opening Doors: For Outward Opening Doors: Fig B. Outward Opening Door Hinge Please Note: Left & Right Hinge Variant 1. Door 2. Hinge top 3. Drill 2mm dia. pilot holes 4. No.8 x 1” csk screws Minima Page 12...
  • Page 13 Fix hinge to outside face of door 4. M5 x 10mm snake eye screws Door Fixing Details 1. Pilaster 5. No.8 x 2” csk screws 2. Partition 6. Hinge top 3. Hinge body 7. HPL/SGL door 4. Drill 3mm dia. holes Minima Page 13...

  • Page 14: Important Note

    1. Back base plate 2. Indicator turning thread 3. Front base plate 4. Screws 5. Back cover plate 6. Front cover plate 7. Indicator bolt 8. Grub screw 9. Allen key Minima Page 14...
  • Page 15 1. Inward opening door pilaster 2. Assembled indicator bolt 3. Keep for intermediate pilasters 4. Partition 5. Outward opening door pilaster 6. Drill dia. 3mm pilot holes 7a. 19mm torx head screws (HPL only) 7b. 12mm torx head screws (SGL only) Minima Page 15...
  • Page 16 I n s f a c i d e I n s 1. Wall end pilaster 2. Keep for wall end pilasters 3. Assembled indicator bolt 4. Drill 2.5mm dia. hole 5. No.8 x 1” csk screw Minima Page 16...
  • Page 17 In-Line Cubicle Variation Minima Page 17...
  • Page 18 3. Drill to suit wall type 4. No. 8 x 2” csk screws 5. Intermediate pilaster 6. Intermediate t-section 7. Intermediate channel bracket 8. Drill 3mm dia. pilot hole 9. No. 8 x 1” csk screws 10. In-line partition 11. Pedestal Minima Page 18...
  • Page 19 (to line up with holes in T-section) 3. M5 x 12mm snake eye screws 4. Drill 8mm dia. through holes 5. M6 x 14mm csk socket stainless steel screw 6. Multirol barrel 7. Intermediate pilaster 8. T-section 9. Channel bracket Minima Page 19...
  • Page 20 Amwell Systems Ltd Buntingford Business Park Baldock Road Buntingford Herts SG9 9ER England T +44 (0)1763 276200 F +44 (0)1763 276222 contact@amwell-systems.com 629-24-04...
