Teletask AURUS-4S Quick Start Manual

APPLICATION

AUTOBUS compatible touch panel
CHARACTERISTICS
General
Solid safety-glass front plate, ceramic background printed and
thermal hardened.
4 capacitive sensitive buttons.
1 hidden "CLEAN" button.
Build-in infrared receiver for remote control (TDS12503).
Build-in temperature sensor for room temperature control (floor
heating, ventilation heating, traditional heating and air-
conditioning).
Buzzer.
Order numbers
TDS12024WH white
TDS12024BL black
TDS12024AU gold
TDS12024LG aluminium-grey
Cleaning
To temporary disable the touch buttons, press long in the
centre of the upper side.
Use only dry microfiber cloth. Never use liquids or solvents!
SETTINGS
Button functions
Via PROSOFT Suite V3.4.8 or higher
AUTOBUS address
Via two rotary switches "Tens" & "units"
Jumpers
Terminating resistor (supplied with the interface). To be used
when the interface is at the physical end of the AUTOBUS
cable.

INSTALLATION

Standard mounting
To be mounted with included wall bracket in about any
standard single wall box.
Or order the TELETASK standard single wall box for brick walls
ref. TDS90000AT. For plaster board or other hollow walls order
ref. TDS90000PB.
To remove the AURUS-4S after installation, place a flat-head
screw driver in the provided slot at the back of the housing. A
standard flat-head screw driver of 5x100mm (3/16x4in.) is
recommended.
©, TELETASK, GENT, 2018
TELETASK can't be responsible for potential errors in the data sheets and technical documentation. Changes in the product features can be made at any time, without prior notice
TDS12024xx
The AURUS-4S features a hardened glass touch panel with 4 capacitive buttons. These
buttons consist of 4 feedback LED lights (with soft night light) and a click sound for clear and
instant feedback.
On top of that the AURUS-4S comes with a IR-receiver for the TELETASK remotes, a buzzer
and a temperature sensor for room temperature control.
The AURUS-4S is available in white, black, aluminium-grey and gold version and can be
mounted in about any standard single wall box.
TELETASK only uses exclusive safety-glass with ceramic printing, hardened at 800°C for all
AURUS family members.
32
Flush mounting
Use Flush mounting box TDS90032 for flat mounting. For
hollow walls this has to be combined with Alu frame TDS90031.
Rem.: Normal operation of the temperature sensor will be
disturbed with flush mounting.
On-wall mounting
Use the TDS90035 on-wall box in case of concrete, marble, ...
walls, if the standard in-wall solution is not possible.
Sealed on-wall box
TDS90037 is to be used as a preventive action to discourage
unauthorized use of the touch panel and to protect against dust,
waterdrops, water sprays, ....
Supply voltage
12V (supplied by the AUTOBUS - minimum 9V).
CONNECTIONS
AUTOBUS
With dedicated connection set (included with the package).
POWER CONSUMPTION
Max. 32 mA
DIMENSIONS
Front plate
90W x 90H x 13D (mm) thickness on wall
NET | GROSS WEIGHT
0,130 kg | 0,235 kg
PACKAGING CONTENT
TDS12024xx
AUTOBUS connection set + terminating resistor
Wall bracket

ENVIRONMENTAL CONDITIONS

Storage (with no condensation or icing)
Temperature: -20°C to +65°C max.
Relative humidity: 5% to 85% max.
Operation (with no condensation or icing)
Temperature: 0°C to +50°C max.
Relative humidity: 5% to 80% max.
IP PROTECTION RATE
IP20
EN
Touch panels
AURUS-4S Touch panel
Version April 2018
