Summary of Contents for Topaz Systems T-LBK750
- Page 1 Installation Guide Right-Angle Strain Relief Cable Copyright © 2020 Topaz Systems Inc. All rights reserved. For Topaz Systems, Inc. trademarks and patents, visit www.topazsystems.com/legal.
- Page 2 Right-Angle Strain Relief Cable Installation Guide Overview This manual will help you install your right-angle strain relief USB cable. This cable can be used with model numbers T-LBK750, T-LBK755, T-LBK766, and T-LBK57GC with model suffixes “-BHSB-R”, “-BBSB-R”, or “-BHSX-R.” Steps 1.
- Page 3 Right-Angle Strain Relief Cable Installation Guide 3. Fasten the strain relief in place with the 2 screws provided (4-40 x 3/16” flat head). 4. Re-attach the vertical pen holder removed in step 2. www.topazsystems.com...
