FASANO TOOLS FG 700/OZ3.5 Quick Start Manual

3.5 g/h ozone generator air purifier machine
Hide thumbs
1
2
3
4
5
6
7
8
Table of Contents

Advertisement

Quick Links

Download this manual
OZONE GENERATOR AIR PURIFIER
MACHINE
FG 702/OZ3.5
FG 700/OZ3.5
REV.0 052020
The reproduction of this document (even in partial form) is prohibited without the Fasangas S.r.l. authorization

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FG 700/OZ3.5 and is the answer not in the manual?

Questions and answers

Summary of Contents for FASANO TOOLS FG 700/OZ3.5

  • Page 1 OZONE GENERATOR AIR PURIFIER MACHINE FG 702/OZ3.5 FG 700/OZ3.5 REV.0 052020 The reproduction of this document (even in partial form) is prohibited without the Fasangas S.r.l. authorization...

  • Page 2: Important Warnings

    IMPORTANT WARNINGS Before using this ozone generator machine, carefully read the warnings and instructions contained in this manual. The improper or unsafe use of this product can be dangerous or cause death or serious bodily injury. This manual of warnings and instructions is an integral part of the product and must be kept by the user for any future consultations.
  • Page 3 OZONE Generality Ozone is a molecule made up of three oxygen atoms (its molecular formula is O It has a characteristic pungent odor (the same that sometimes accompanies thunderstorms due to the ozone produced by electrical discharges of lightning). Its name derives from the Greek "ozein" which means "smell".

  • Page 4: Technical Features

    TECHNICAL FEATURES MODELS FG 700/OZ3.5 FG 702/OZ3.5 OZONE PRODUCTION: 3.5 g/h with ambient air (20°C; RH 50%) VOLTAGE AND FREQUENCY OF THE OZONE 3.0 ~ 3.5kV 16kHz GENERATOR: OZONE GENERATION SYSTEM: corona discharge AVERAGE OZONE CONCENTRATION: 1 ppm OZONE EMISSION / CONCENTRATION CONTROL:...
  • Page 5 8. Select the work program according to the volume of the environment to be treated using the programming keyboard located on the top panel of the device. FG 700/OZ3.5 and FG 702/OZ3.5 models KEY 1: up to 10 m KEY 2: up to 25 m...
  • Page 6 10. The place can be occupied again once the ozonator finishes all the work phases. It will be possible to notice this as it will no longer emit the sound signal, the LEDs inside will turn off and you will no longer see their light coming out from the front panel. Furthermore, for the versions with printer, the device will automatically issue the receipt in which the total time and the maximum concentration peak reached in the ozonation phase will be reported.
  • Page 7 The catalization times are indicatively the following: FG 700/OZ53.5 and FG 702/O3.5 models Up to 10 m : maximum time about 12 minutes fino a 25 m : maximum time about 32 minutes Fino a 50 m : maximum time about 1 h and 4 minutes NOTE: the catalization times shown are indicative and refer to environments with a temperature of about 21°C and relative humidity of about 50%.

  • Page 8: Maintenance

    MAINTENANCE To clean the device, use a soft, dry cloth. Never use aggressive cleaning agents or water. Pay attention to the ozone sensor on the top of the device. It is recommended to replace the filter kit once a year (if the device is used very frequently, it may be necessary to replace the filter kit before a year).

This manual is also suitable for:

Fg 702/oz3.5
