- Page 1 Vivid™ PRO Fogger INSTRUCTION MANUAL SF-FG03-220 SF-FG03-024 Checked By Date Checked...
- Page 2 VIVID™ PRO FOGGING MACHINE INSTRUCTION MANUAL...
- Page 3 PRO Fogging Machine Effective & portable infection control system. STREAMLINE® disclaims all liability for damage or injury as a result of improper or unreasonable use or failure to follow operating instructions of the Vivid™ PRO. Main Power Switch LED Control Panel...
- Page 4 VIVID™ PRO Vivid™ PRO Fogger...
- Page 5 INSTRUCTION MANUAL Warning: 1. Charge battery before operating. 5. Do not splash any liquid on machine. 2. If your Fogger is the Li-ion battery 6. Avoid spraying strongly-corrosive version, To maintain battery health: chemicals if possible. Otherwise, Every 2 months, drain and then immediately spray clean water.
- Page 6 Vivid™ PRO Fogger Operation Manual 1. Fill solution tank and ensure the tank cap is screwed on securely. If your fogger is the Li-ion bat tery version, ensure the battery is charged. 2. Turn on main power switch. (Main power switch)
- Page 7 INSTRUCTION MANUAL 3. Press ON/OFF button. (ON/OFF button) 4. Open flow rate knob. “0” is off Flow rate knob...
- Page 8 VIVID™ PRO Vivid™ PRO Fogger 5. Pull trigger to spray, release to stop spraying. Trigger Press Trigger Release...
-
Page 9: To Stop Spraying
INSTRUCTION MANUAL 6. To spray continuously, use the Lock Up button to lock the trigger Lock up button 7. To adjust flow rate or droplet size, use the flow rate knob. Turn flow rate knob counter-clockwise to increase flow rate and droplet size. To stop spraying: 1. - Page 10 VIVID™ PRO Vivid™ PRO Fogger 2. Dial down the flow rate knob. 3. Press ON/OFF button. ON/OFF button 4. Turn off main power switch on handle. Main power switch...
- Page 11 INSTRUCTION MANUAL Charging the battery (This is only applicable if you have the Li-ion battery version) 1. Push locker button Locker Button 2. Remove battery. 3. The battery can be charged after it is removed. 4. A green indicator light means charge is complete.
- Page 12 Vivid™ PRO Fogger VIVID™ PRO 5. Reinsert battery Attention: Upper side is with groove.
-
Page 13: Troubleshooting
INSTRUCTION MANUAL Adjusting the speed of the motor: Press twice to select the desired time limit. Press and you have set the new speed. Once speed is selected, press Activating the timer and setting a time limit for fogging: Press once Press to select “Timing”. - Page 14 Vivid™ PRO Fogger VIVID™ PRO Vivid™ PRO Fogger Setting Up the Vivid™ PRO Fogger before use: Firstly ensure you’re using the correct PPE for the environment you’re working in. e.g. facemask, eye goggles, gloves and body coverall. If you’re using Vivid™ SENSE solution this can be poured straight into the solution tank without being diluted.
- Page 15 INSTRUCTION MANUAL Warning: 1. Charge battery before operating. 2. To maintain battery health: Every 2 months, drain and then fully charge the battery. Do not charge for more than 10 hours. 3. Do not turn the machine upside down while it contains solution.
- Page 16 Replacement parts will only be supplied This warranty constitutes the exclusive under warranty, upon the inspection and remedy of any purchaser of a STREAMLINE® approval of the defective parts by unit and is in lieu of all other warranties, STREAMLINE®.
- Page 17 • We insist on sourcing brand name products from around the world, only of a reputable quality, and bring them together under the STREAMLINE® name • All STREAMLINE® products carry a full one year’s warranty, according to the manufacturers’ standard terms and conditions of sale.
- Page 18 Notes...
- Page 20 Vivid™ PRO Fogger Varitech Systems Hamilton House, 8 Fairfax Road Heathfield Industrial Estate, Newton Abbot Devon, TQ12 6UD United Kingdom Telephone +44 (0) 1626 830 830 Email sales@varitechsystems.co.uk Visit www.varitechsystems.co.uk...
