Summary of Contents for Royalcraft Onyx

  • Page 2 Onyx 150 x 80cm Rectangular Table Assembly Instructions Before you start Don’ts Warnings Do not stand or climb onto the product. IMPORTANT, RETAIN FOR FUTURE REFERENCE READ CAREFULLY Do not use power tools to construct this product. Do not sit or lean onto the rims of this product.
  • Page 3 Onyx 150 x 80cm Rectangular Table Assembly Instructions Components, fixtures & fittings (not actual size) Parts List Part Part Diagram Qty. Diagram Qty. 1 PC 2 PCS Table Top Frame 1 PC 2 PCS Connecting Bar Bottom Base 2 PCS...
  • Page 4 Onyx 150 x 80cm Rectangular Table Assembly Instructions Step by step assembly instructions All Bolt Head Caps should not be attached before finally tightening all Bolts with Spanner. Step One Open the packaging carefully. Leave the glass on the carton until the rest of the table is fully assembled.
  • Page 5 Onyx 150 x 80cm Rectangular Table Assembly Instructions Step Three There is a movable bar in the bottom base (D) that acts as a support bar when rising from a Coffee to Dining Table height. To use in the raised dining table function, let the movable supports at both ends be in the outer position.
  • Page 6 Onyx 150 x 80cm Rectangular Table Assembly Instructions Step Four To use its Coffee Table Function, take out the Table Top, let the movable supports be in its central position, insert the Table Legs into the slots of the movable supports.
