CAT BOX FX STARTER GUIDE
Congratulations on your purchase of the high quality SoundTools CAT Box.
The CAT Box is designed to help simplify your stage wiring system with its compact,
reliable and disconnectable design. Here are some tips to get you started.
Step 2:
Insert a shielded CAT5e
cable into either etherCON
receptacle and connect the
other end of the cable to an
additonal CAT box, CAT Tails
or other SoundTools RATCAT
unit.
Step 1:
Use channels 1
thru 4 to connect
your XLR lines
Advertisement
Table of Contents
Summary of Contents for SoundTools CAT BOX FX
- Page 1 CAT BOX FX STARTER GUIDE Congratulations on your purchase of the high quality SoundTools CAT Box. The CAT Box is designed to help simplify your stage wiring system with its compact, reliable and disconnectable design. Here are some tips to get you started.
- Page 2 4 Female XLR connectors You can run different types of signals simultaneously over the same shielded CAT5e cable. The most common types of signals include analog audio, AES3, DMX and COM etherCON IN/OUT and THRU Using shielded CAT5e cable will minimize noise and interference and is required when using phantom power.
